- Page 1 OWNER’S MANUAL MANUALE UTENTE HIGH DEFINITION LINE ARRAY MODULES...
-
Page 3: Table Of Contents
RIGGING THE SYSTEM ................................9 INSTALLATION ..................................10 CONNECTING THE FRONT SIDE | MODELS GTX 10i - GTX 10Pi - GTX 10Wi ...............10 CONNECTING THE REAR SIDE | MODELS GTX 10i - GTX 10Pi ....................11 CONNECTING THE REAR SIDE | MODEL GTX 10Wi ......................13 CONNECTING DIFFERENT MODELS ............................15... -
Page 4: Safety Precautions And General Information
1. SAFETY PRECAUTIONS AND GENERAL INFORMATION 1. SAFETY PRECAUTIONS AND GENERAL INFORMATION The symbols used in this document give notice of important operating instructions and trolleys and carts, where necessary, that are recommended by the manufacturer. warnings which must be strictly followed. The equipment / support / trolley / cart assembly must be moved with extreme caution. -
Page 5: Operating Precautions
1. SAFETY PRECAUTIONS AND GENERAL INFORMATION 1. SAFETY PRECAUTIONS AND GENERAL INFORMATION SUSPENDED DEVICES CARE AND MAINTENANCE Suspending any object is a potentially dangerous operation and should only be To ensure a long-life service, this product should be used following these advices: attempted by individuals who have a thorough knowledge of the techniques and If the product is intended to be set up outdoors, be sure it is under regulations of rigging objects overhead. -
Page 6: Description
0° to 10° angles between modules, with 1° steps. Up to 16 modules can be fastened on a single fly-bar. These systems are specifically designed to integrate seamlessly with the XPS 16K four- channel DSP amplifiers (6 modules per unit). GTX 10i GTX 10Pi GTX 10Wi 2 x 10”... - Page 7 Frequencies and the right carriers are for the High Frequencies. To connect GTX 10i, GTX 10Pi and GTX 10Wi speakers, it is possible to use cables with a section up to AVG 9. WARNING! CAUTION! Loudspeaker connections should be only made by qualified and experienced personnel having the technical know-how or enough specific instructions (to ensure that connections are made correctly) in order to prevent any electrical danger.
-
Page 8: Connections
3. CONNECTIONS Each XPS 16K amplifier can drive up to six modules at the the same time, three for each pair of amplification channels. Refer to the scheme below for speakers connection. LF/HF INPUT AMPLIFIER 1 LF/HF LF/HF LINK INPUT GROUP 1 LF/HF LINK... - Page 9 3. CONNECTIONS In order to match with XPS 16K speaker’s preset, GTX 10i must be connected to the amplifier on specific channels pairs, as shown in the picture. CHANNELS PAIR AB A 1+ A 1- B 2+ B 2- CHANNELS PAIR CD...
-
Page 10: Software Manuals For Gtx Systems
Within EASE, each loudspeaker is described by a system definition profile, known as a GLL file, containing the loudspeaker system’s mechanical, electronic, and acoustic properties. TT+ AUDIO provides GLL files for all TT+ Audio loudspeakers. These GLL files can be... -
Page 11: Rigging The System
It is responsibility of the owner or rigger to make sure the system is properly rigged in accordance with Country and local laws and regulations. Always check that all the parts of the rigging system that are not provided from TT+ Audio are: Appropriate for the application... -
Page 12: Installation
6. INSTALLATION 6.1 CONNECTING THE FRONT SIDE - MODELS GTX 10i GTX 10Pi GTX 10Wi To connect two modules together (either one of the three models) place one on top of the other making the front brackets match eachother and fix them by screwing two 41 mm M8 screws on both sides. -
Page 13: Connecting The Rear Side - Models Gtx 10I Gtx 10Pi
6. INSTALLATION 6.2 CONNECTING THE REAR SIDE - MODELS GTX 10i GTX 10Pi Fix the rear connection bracket on the cabinet rear bracket with a 49 mm M8 screw through the Rear Link Bracket hole and secure it with its nut. - Page 14 6. INSTALLATION Place a module over the lower one and connect the front side as described on chapter 7.1. Lift up the upper cabinet to the desired angle and fix the connection bracket through the corresponding hole by inserting a 49 mm M8 screw On the other side secure the screw with its nut.
-
Page 15: Connecting The Rear Side | Model Gtx 10Wi
6. INSTALLATION 6.3 CONNECTING THE REAR SIDE - MODEL GTX 10Wi Fix the rear connection bracket Fix the rear connection bracket on the cabinet rear bracket with a 49 mm M8 screw on the cabinet rear bracket with a 49 mm M8 screw through the Rear Link Bracket hole. - Page 16 6. INSTALLATION Place a module over the lower one and connect the front side as described on chapter 7.1. Lift up the upper cabinet to the desired angle and fix the connection bracket through the corresponding hole by inserting a 49 mm M8 screw On the other side secure the screw with its nut.
-
Page 17: Connecting Different Models
6. INSTALLATION 6.4 CONNECTING DIFFERENT MODELS When connecting a GTX 10Wi module to GTX 10i or GTX 10Pi, follow the instructions described on chapter 7.3. Whether GTX 10Wi is placed above or below, always use GTX 10Wi rear connection bracket. -
Page 18: Connecting The Flybar
6. INSTALLATION 6.5 CONNECTING THE FLYBAR REAR CONNECTION BRACKET SUSPENSION SUSPENSION POINT POINT SUSPENSION POINT REAR CONNECTION BRACKET FRONT CONNECTION BRACKET FRONT CONNECTION BRACKET... - Page 19 6. INSTALLATION The flybar connects the same way to GTX 10i, GTX 10Pi and GTX 10Wi. Place the flybar over the module making the front brackets match eachother and fix them by screwing two 41 mm M8 screws both sides. Once the screws have been tightened, insert a double cotter pin on both sides as shown in the picture.
- Page 20 6. INSTALLATION On the rear side, lower the flybar until the rear bracket matches the Rear Link Bracket hole; insert a 49 mm M8 screw and tighten it to its nut on the other side . USE THESE COMPONENTS FOR REAR LOCKING 49 mm screw Single cotter pin 49 mm...
-
Page 21: Top Mounting
6. INSTALLATION In case of large configurations the flybar can be fixed on the cabinet bottom the same way it is fixed on top. TOP MOUNTING BOTTOM MOUNTING TURN THE SHAKLES UPSIDE DOWN WHEN USING THE FLYBAR ON BOTTOM CONFIGURATION... -
Page 22: Examples Of Configurations
6. INSTALLATION EXAMPLES OF CONFIGURATIONS SINGLE FLYBAR CONFIGURATION SUSPENSION POINTS DOUBLE FLYBAR CONFIGURATION SUSPENSION POINTS SUSPENSION POINT... - Page 23 6. INSTALLATION DOUBLE FLYBAR CONFIGURATION SUSPENSION POINTS SUSPENSION POINTS SUSPENSION POINTS SUSPENSION POINTS TRIPLE FLYBAR CONFIGURATION SUSPENSION POINT...
-
Page 24: Gtx 10I - Gtx 10Pi Dimensions
GTX 10i - GTX 10Pi DIMENSIONS... -
Page 25: Gtx 10Wi Dimensions
GTX 10WI - DIMENSIONS... -
Page 26: Specifications
SPECIFICATIONS GTX 10i GTX 10Pi GTX 10Wi Acoustical specifications 42 Hz ÷ 20000 Hz Frequency Response (-10dB) 42 Hz ÷ 20000 Hz 42 Hz ÷ 20000 Hz Max SPL @ 1m 143 dB 143 dB 143 dB Horizontal coverage angle 110°... - Page 28 RCF S.p.A. Via Raffaello Sanzio, 13 - 42124 Reggio Emilia - Italy 10307825 RevB Tel +39 0522 274 411 - Fax +39 0522 232 428 - e-mail: info@rcf.it - www.rcf.it...
