PREFACE Thank you for choosing a Nexus EDGE. This machine uses stepping motors to achieve highspeed and high precision cutting. In addition to cutting mountboard and other media, it can also be used as a pen plotter as well as an effective tool for the cutting and creasing of cardboard.
Use of the cutting plotter in such a condition may result in a fire hazard or electric shock. After confirming that smoke is no longer being emitted, contact your sales representative or nearest Valiani vendor for repairs. Never attempt to perform repairs yourself. Repair work by inexperienced personnel is extremely dangerous.
NEXUS EDGE SAFETY PRECAUTIONS (CAUTION) Caution Do not use or store the machine in a location exposed to direct sunlight or the direct draft of an air conditioner or heater. Such locations may impair the performance of the cutting plotter.
The instructions, drawings, images and documents contained in this manual are of a technical nature and confidential property of the Valiani. They cannot be reproduced in any way, either entirely or in part, without prior written permission from the company.
Figure 1-1 1.11 WARRANTY CONDITIONS Valiani guarantees that their products are soundly made and are free of manufacturing defects. For guarantee details please refer to the specific guarantee document supplied with this manual. 1.12 GENERAL INFORMATION Carefully following the assembly, usage and maintenance standards described in this manual will ensure lasting performance and protect your investment.
NEXUS EDGE WARNINGS LABELS PRESENT ON THE MACHINE The machine is fitted with various labels to show either data or safety concern areas for the operator. Referring to the photograph below these are: Figure 2-1...
NEXUS EDGE DETTAILS OF THE VARIOUS LABELS Figure 2-2 LABEL 1: Plate showing: manufacturer data, model, year, serial number, weight, electrical and pneumatic information of the machine. LABEL 2: Adhesive label: Hand Entanglement / Rotating Gears warning (Moving parts present.
NEXUS EDGE SAFETY EQUIPMENT FITTED TO THE MACHINE The machine is equipped with various safety devices and an emergecy stop button, to the drivetrain, that protects the operator from possible injury resulting from contact with moving parts. Any mobile safety devices is fixed on the machine by screws. These devices are fitted to areas of the machine where there are moving parts, blades or sharpen tools or in any area that might generate possible danger to the operator while using the machine.
NEXUS EDGE OPERATOR SAFETY MEASURES According to the type of work conducted with the machine some maintenance work will require the operator to wear gloves and safety glasses. While servicing the machine, it is recommended to use personal protective equipment: •...
NEXUS EDGE INTRODUCTION The Nexus EDGE introduces to the world of mountboard cutting machinery a new technological resource that allows the operator to change the blade holding head to another with a different cutting angle according to requirements. Even though this is an entry level computerised mat cutting machine, it offers good production capacity and an excellent quality to price ratio whilst maintaining high levels of excellence.
Sole leather, cardboard, thin polyester. 002157 greater precision on cuts with a small radius. To make sharp edges. (25° Angle) Note: For any special need, other blades might be available. Please contact your local Valiani dealer, or the manufacturer for further information.
SCORING / CREASING TOOLS Nexus Edge allows to be integrated with a creasing tool capable to perform creasing and perforating process on packaging materials. The head has the same fastening system as the interchangeable cutting heads and it is supplied with 9 creasers.
PEN TOOL (OPTIONAL) The PEN TOOL is a tool for writing and drawing using a Valiani machine. This tool is supplied with adaptors, consisting of two interchangeable elements of different dimensions capable of holding different pens or pencils. Upon request a holder for plotter pens can also be supplied.
IMPROPER USE OF THE MACHINE Nexus EDGE is not suitable for operation in potentially explosive atmospheres (ATEX). Nexus EDGE cannot be used for processing materials other than those indicated in paragraph 3.6 BEFORE USE Before start using the machine, make sure is completely unlocked from any transportation security device, mounted...
Figure 4-1 Check that the machine has not been damaged while being transported. If there are signs of damage inform the shipping company and Valiani s.r.l. immediately and, if possible, take photographs of the damaged packaging. DANGER! Do not attempt to unload or move the machine carton manually.
Back Panel Maintenance materials (oil, the cutting head. positioning stand. etc.). Rear Bar Clamping Screws Should there be any damaged or missing parts, please notify both the forwarding company that made the delivery and Valiani or Dealers immediately.
Page 21
NEXUS EDGE Note. Concerning the machine supplied with a multi-position stand (packed in a wooden case (D)), please proceed as follows: • Unscrew side screws and take off the side panel (1). • Unscrew all perimetral screws at the bottom to remove wood cover (2).
NEXUS EDGE INSTALLATION AREA AND OPERATOR ZONE While choosing the area to be used for the installation of the machine, it will be necessary to consider the overall dimensions of the machine (see paragraph 12 14), the positioning of the various accessories for its use and the...
NEXUS EDGE MACHINE STAND ASSEMBLY The machine stand consists of the side panels (with the supports for the worktable already assembled), the front panel and the rear bars. To assemble please proceed as described below: • Place the left and right-side panels at the required distance to position the front panel and the back bars.
Page 24
NEXUS EDGE TABLE ASSEMBLY After the stand is assembled, you can mount the table, as described here below: 1. Unpack the table 2. Lift the table and position it on the stand, making sure that the four anchoring points (2) perfectly fit in the four anchoring seats of the stand (1).
NEXUS EDGE ADJUSTMENT OF MULTI -POSITION STAND (OPTIONAL ITEM) Upon request the machine can be mounted on a multi-position stand allowing the setting of table height and inclination. To adjust the height, please proceed as follows: Unpack the lifting jack supplied.
Page 26
NEXUS EDGE To adjust the inclination of the table please follow the instructions below DANGER! 2 operators are required to safely carry out this operation. • Untighten the 8 screws (Locking screws) at the top of the legs. • Release the handles •...
NEXUS EDGE PNEUMATIC CONNECTIONS Danger: it is a mandatory requirement that the pneumatic system to which the machine is connected, is equipped with a tap to shut off the air compressed and provided with a pneumatic circuit drain. Please connect the end of the pipe (1), coming from under machine table to the fitting (2) on the right side of the pressure regulator (3) to feed the pneumatic circuit.
DANGER! Before assembling the electrical panels, make sure that the power plugs are not connected to the mains. 5.7.1 ELECTRICAL PANEL ASSEMBLY NEXUS EDGE 120 Unpack the electric box and the fixing plate, then proceed as follows to fix them to the machine: •...
Page 29
NEXUS EDGE • Plug the “G” connector of the electrical panel of the vacuum pump to the connector in the junction box. • Refit the cap “F” with the screws “E” removed previously.
NEXUS EDGE 5.7.2 ELECTRICAL PANEL ASSEMBLY NEXUS EDGE 150 Unpack the electric box and fix it according to the following procedure: • Position the electric box under the table on the left side of the machine (power-on button face-out). •...
Nexus Edge: connect the supplied power cable on the back of the electric box (1). Nexus Edge V: connect the power cable coming from the vacuum pump electrical box to the main control unit (1) Note. In case the machine is equipped with a 3-ph vacuum pump, Valiani will provide a power cord for the control unit (1) similar to non-vacuum machine.
NEXUS EDGE • Turn on the machine pressing the ON button on the electric box (4), and in case of a Nexus Edge V repeat the same operation on the vacuum e-cabinet (5). • After installing V-Studio software, connect the USB cable to the PC in order to make the connection with the machine, or, if you have chosen Bluetooth you will be not required to do anything.
ON/OFF First Vacuum Zone Selector (4) (only Nexus EDGE V). • Manual TAPS Selectors for vacuum zones 1,2,3 (1-2-3) (only Nexus EDGE V). The pressure regulator (5) allows the clamping pressure to be adjusted so that it doesn’t affect the surface of material being held for cutting.
This paragraph is intended to list the important task to use the machine: • Power the machine on by turning the control unit on (4) and in case of Nexus EDGE V repeat the operation turn the small vacuum e-cabinet ON (5) Figure 5-16 Figure 5-17.
• Open the V-Studio software so that the machine automatically raises the clamps. • Position the special Valiani porous board (1) under the clamps (2). Caution: The Nexus EDGE V version comes as standard with a Forex protective board which should never be removed, the protective slip sheet/mat must placed over it.
NEXUS EDGE 6.2.2 FITTING A CUTTING BLADE Warning! Handle the blade carefully, protect it if necessary, to avoid cutting. If necessary, during reassembly using a rubber object to keep it in its housing during locking of the locking screw. •...
NEXUS EDGE 6.2.4 DISASSEMBLING THE HEAD If it is necessary to replace the head with another one, proceed as follows: • Loosen the screw (Z). • hold the release tool/fork (1) by its handle and insert it into the slot located in the top part of the head. Holding...
NEXUS EDGE 6.2.6 REPLACING BLADES ON 90° TRIMMING TOOL (OPTIONAL) In order to replace the blades on the 9°° Trimming tool procedd as follows: Note: In case there’s also the Pen Tool mounted on the machine, please remove it before doing anything. (see 6.2.6.1) DANGER: Always wear gloves when handling blades.
Page 39
NEXUS EDGE • Insert the blade holder (8) into its slot paying attention that the pin (9) goes into the groove (10), finally lock the set-screw (11). Vertical Blade Holder replacement Horizontal Blade Holder replacement Figure 6-14 Figure 6-13 •...
NEXUS EDGE 6.2.6.1 REMOVING PEN TOOL TO REPLACE BLADE ON 90° TRIMMING TOOL • Remove the tools protection by removing the 4 screws (1) • Disconnect the Pen air hose (2) by pressing the down the moveble flange (3). •...
NEXUS EDGE 6.2.8 ADJUSTING THE DOWN PRESSURE OF THE CUTTING HEAD To cut special hard materials, or to avoid the wheel on the cutting head marking soft materials, it may be necessary to adjust the pressure of the air in the cylinder controlling the head down pressure. Adjustment can be made as follows: Pull knob (1) out (on) for a short distance to release the pressure regulator.
Loosen the knob (4) in order to unlock the knob (1) of the head assembly (2). At this point the head assembly stroke adjustment knob (1) is free and you can proceed with the calibration and testing. • Place “Valiani” breathable board on the worktable (see paragraph 6.2.1). •...
Page 43
• Repeat the process until you reach the desired height and consequently a good cutting quality. Figure 6-23 Special Valiani protective porous worktable board, thickness 1.5mm (0.6”) (see paragraph 0) • When regulation is finished, tighten the knob (4). REMARK! If you change the thickness of the breathable matboard which protects the worktable,...
NEXUS EDGE 6.2.10 REGOLATION OF OVAL AND ROUD CUT If you find errors in the cut of oval or round shapes, as per figure below (1), a little calibration will be required, since the shape is not perfectly closed. This error occurs when the blade plunges into the material with a speed that does not allow the starting and ending points to match (4).
NEXUS EDGE 6.2.11 SPEED REGULATION HEAD DOWN FOR SHAPES WITH EDGES Using a slotted screwdriver adjust the screw on the flow regulator (2) to modify the speed of the cutting head when moving down. Figure 6-27 You should rotate the screw clockwise to reduce the air flow, so that the blade enters the material more slowly. Vice versa you should rotate the screw anti clockwise to increase the speed of the cutting head when moving down.
Page 46
NEXUS EDGE 6.2.13 TRIMMING TOOL’S ADJUSTMENT OF THE CUTTING DEPTH If the cutting depth of the blades is not sufficient to detach the material or is excessive, its height can be adjusted as described below: 1) Remove the casing by unscrewing the four screws (1) Figure 6-28.
Page 47
NEXUS EDGE 7) Rotate the ring nut (6) until the blade is at the desired height (clockwise to raise the blade or anti-clockwise to lower it). Attention: the absence of air from the pneumatic circuit facilitates the adjustment of the blade but at the same time does not counteract the lifting of the head.
NEXUS EDGE ROUTINE MAINTENANCE Very little maintenance is required, and it is limited to the operations detailed in the following paragraphs. Danger! Please disconnect the machine from electricity, before carrying out any maintenance operations. CLEANING One of the most important maintenance tasks is the frequent and complete cleaning of the following parts: Worktable (daily) •...
NEXUS EDGE LUBRIFICATION Cutting blade running guide (every 1 - 2 months for all cutting heads types) Remove the blade as previously described. Lubricate the guide at points (1) and (2) with a small amount of spray grease taking particular care not to allow any grease to reach the rubber roller. Carefully wipe off all excess grease before re- inserting the cuttting blade.
NEXUS EDGE 7.3.1 ADJUSTING THE RUBBER PRESSURE ROLLER The rubber roller on the 40° green cutting head will wear during normal use and its position with respect to the cutting blade needs to be adjusted periodically to ensure good quality mountboard cutting. This adjustment also needs to be made each time a rubber roller is changed.
NEXUS EDGE ADJUSTING THE PRESSURE FOOT Figure 7-7 • Loosen the set screw (1). • Turn screw 2 clockwise or anticlockwise to raise or lower the pad support. • Once you have adjusted and reached the desired position tighten the grub screw (1).
TROUBLE SHOOTING This section relates to possible problems that could occur during normal use of the machine. For any problems not covered in this manual please contact your sales representative, your nearest Valiani dealer or the Valiani technical support. CONTROL UNIT MESSAGES...
• The cutting head and blade do not descend (pneumatic or electrical problem). • The suction pump does not turn on (only Nexus Edge V). 8.3.1 THE MACHINE DOES NOT T URN ON If the machine does not turn on and the light of the switch on the electric box is not on, it means that the machine is not getting power.
NEXUS EDGE From the opposite side of the fuse holder gently press the fuses using the tip of a screwdriver to take it out of its seat. Figure 8-5 Replace the fuse with a new one (10A 250V), please repeat this operation for the second fuse.
NEXUS EDGE Electrical problem If, after checking the pneumatic system, the clamps still do not work, please proceed as follows to check the electrical system: • Switch ON the power by pushing the switch on the electrical box to ON or by turning the red EMERGENCY switch...
NEXUS EDGE • Manually check that the head command cylinders, works by pressing the orange buttons of every valves (on each solenoid valve there is a label of recognition YV1, YV2, YV3, YV4,YV5, YV6): • The YV1 valve drives the main cylinder that lowers and raises the cutting head assembly.
• Check the integrity of the power cables of the pump and the electrical panel • Reconnect the power plug and turn the pump switch-on selector to ON to check correct operation. If the vacuum pump does not turn on, contact first the Valiani Support. DECOMMISSIONING AND DISMALTING When dismantling or disposing of the machine it should always be noted that: •...
Valiani personnel sent to the site. Should this not be possible, Valiani will reimburse the price of the Product, reduced by an amount that takes Oscillating head, Router 1KW, Vacuum pump, Industrial vacuum into account its actual use starting from the time of purchase.
Via delle Regioni, 305-307 – 50052 Certaldo [FI] - ITALIA Tel. (+39) 0571 666 598 www. valiani.com – email: info@valiani.it Declares under our sole responsibility that the machine NEXUS EDGE has been made in compliance with the following directives: •...
NEXUS EDGE 13 DIMENSION WITH STANDARD STAND Nexus with flat worktable Side view Front view Nexus with angled worktable Side view Front view flat worktable angled worktable Model 1355 (53.35) 1250 (49.2) 1800 (70.86) 1295 (50.98) 1640 (64.56) 1800 (70.86) 1555 (61.22)
NEXUS EDGE 14 DIMENSION WITH MULTILEVEL STAND Nexus with flat worktable Side view Front view Nexus with angled worktable intermediate inclination max inclination Angled worktable Flat worktable intermediate inclination max inclination Model 1565 (61.61) max 1755 (69.1) max 1810 (71.26) max...
