Sawyer 255H Manual

About Us
We appreciate your business!
Congratulations on your new SAWYER product. We are proud to
have you as our customer and will strive to provide you with the best
service and reliability in the industry. This product is backed by our
extensive warranty and world-wide service network. To locate your
nearest distributor or service agency, please contact us at the phone
number and address listed on the bottom of each page.
You are in good company!
Sawyer Manufacturing Company is the world leader in the design
and manufacture of pipeline and welding equipment and has been
since 1948. Sawyer equipment has become a standard in the industry
and continues to set the benchmark for quality and durability.
This user operation manual has been made to instruct you for the best
use and operation of your Sawyer product. Your satisfaction with our
products is our main goal. Please read this entire manual carefully,
noting all tips, notes and warnings. Safety always comes first.
H
Record the following information for warranty purposes:
Where purchased:________________________________________________
Purchase date:___________________________________________________
Equipment Serial #:_______________________________________________
B
A
G
D
F
Sawyer Manufacturing Company
7799 S. Regency Dr., Tulsa, OK 74131 USA
P 918.834.2550 Email
sawyermfg.com
Operation Diagram
A. Cage Clamp Handle
B. Hydraulic Cylinder
C
C. Hydraulic Valve
D. Release Valve
E. Hydraulic Handle
F. Tension Rod
G. Clamp End
H. Tack Bar
E
I. No Tack Bar *not pictured*
The components shown are not
available for individual purchase.
For a parts diagram or replacement part
information, please contact Sawyer.
CAUTION
!
CAUTION:
Sawyer Manufacturing offers a line of easy to use
cage clamps for the purpose of welding two pipes together. We
recommend two people for the installation of the clamp. The
cage clamps are not intended to be used as sole support of the
pipe nor to lift the pipe. These clamps are not designed for the
use of tees, elbows, valves or other fittings. After each use clean
and store in a warm, dry area.
Warranty
All products manufactured by or for Sawyer Manufacturing Company are
guaranteed against defects due to faulty workmanship or materials for twelve
months from the date of purchase.
This guarantee is limited to the repair or replacement of any parts found to be
defective, and no other liability–expressed, implied, or contingent–is assumed.
info@sawyermfg.com
Hydraulic
Cage Clamp
Manual
Model 255H
