Summary of Contents for TE Connectivity HumPRC
- Page 1 HumPRC 868MHz Long-Range Handheld Transmitter Data Guide...
- Page 2 Table of Contents Warning: Some customers may want Linx radio frequency (“RF”) products to control machinery or devices remotely, including machinery or devices that can cause death, bodily injuries, and/or property Description damage if improperly or inadvertently triggered, particularly in industrial Features settings or other applications implicating life-safety concerns (“Life and Property Safety Situations”).
-
Page 3: Data Guide
(0.20 in) (0.60 in) and operating environment. Figure 1: Package Dimensions The transmitter incorporates the HumPRC Series transceiver module. This module uses an Adaptive Frequency Agility (AFA) protocol to achieve longer range and higher noise immunity than narrowband radios. An... -
Page 4: Ordering Information
Series Master Development System required by the application. Figure 3: Ordering Information The transmitter is compatible with the HumPRC and HumPRO product families. Ranges of up to 0.8 mile (1,300m) are possible with good antennas and a quiet, line-of-sight environment. Applications operating over shorter distances also benefit from the increased link reliability and... -
Page 5: Button Assignments
Figure 5: Button Assignments to a module that has been configured as an administrator. Assembly Diagram The schematic for a HumPRC Series transceiver configured as a receiver is shown in the Typical Applications section. The transceiver is set as an Administrator by pressing and holding the PAIR button for 30 seconds. -
Page 6: Regulatory Considerations
Regulatory Considerations All Linx products are designed with the approval process in mind and thus much of the frustration that is typically experienced with a discrete design The handheld transmitter has been tested and conforms to the is eliminated. Linx Technologies has aided many customers through the requirements of the current Radio Equipment Directive (RED) standards. -
Page 7: Typical Applications
Additional features can be enabled through the module's Command Data Interface. The data guide and additional documentation for the HumPRC Series transceiver can be found on the Linx Technologies website at www. -
Page 8: Transmitter Schematic
Series transceiver. The transmitter should be joined to the Transmitter Schematic HumPRO Series module in the same manner as it would be joined to a HumPRC Series module. The transmitter sends a Remote Activation ANT1 ANT-fff-PW-LP command and accepts a Remote Confirm command. - Page 9 TE Connectivity product is installed. Useful lifetime of the original end product may vary but is not warrantied to exceed one (1) year from the original date of the end product purchase.
