Item #000-000
Model #FHTS85122
USE AND CARE GUIDE
NEWBURY WOOD FIREPIT
Questions, problems, missing parts? Before returning to the store,
call Gluckstein Elements Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
888-628-1888
HOMEDEPOT.CA
GLUCKSTEINELEMENTS.COM
THANK YOU
We appreciate the trust and confidence you have placed in Gluckstein Elements through the purchase of this firepit. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement
needs. Thank you for choosing Gluckstein Elements!
Advertisement
Table of Contents
Summary of Contents for GLUCKSTEIN ELEMENTS FHTS85122
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Gluckstein Elements through the purchase of this firepit. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Hardware Included ..............Product Caution ..............2 Package Contents ..............Safety Warnings ..............2 Assembly ............... 5 Warranty ................ 2 Care and Cleaning ............ -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Cover Handle Barbecue Grate Barbecue Holder Main Body Drawer Table Top Table Leg 1 Table Leg 2 Parcel Shelf Table Leg 3 Poker... -
Page 5: Assembly
Assembly Connecting the Table Legs to the Table Top Place the table top (G) on a soft surface. Attach the table legs (H&I&K) to the table top (G) using M6x15 combination bolts (AA). Do not tighten all bolts at this step. NOTE: Loosely tighten all the bolts using the hex wrench (FF). - Page 6 Assembly (continued) Connecting the Upper Baf e Plate and the Lower Baf e Plate to the Main Body Place the main body (E) on a soft surface. Attach the upper baf e plate (DD) and the lower baf e plate (EE) to the main body (E) using M6x15 combination bolts (AA). Tighten all bolts using the hex wrench (FF).
- Page 7 Assembly (continued) Pushing the Drawer to the Main Body and Putting the Barbecue Grate to the Barbecue Holder Push the drawer (F) to the main body (E). Put the barbecue grate (C) to the barbecue holder (D). Loosen/tighten the barbecue holder (D) by counter-clockwise/ clockwise the M8x10 butter y bolt (CC). Connecting the Handle to the Cover, Putting the Cover on the Main Body, Putting the Table and the Firepit Together Counter-clockwise rotate the handle (B) to the cover (A) as shown below.
-
Page 8: Care And Cleaning
Care and Cleaning For best results, clean the fire pit with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. Do not clean with abrasive materials, bleach, or solvents. Store the fire pit in a dry, sheltered place when not in use. Keep the fire pit away from freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind. - Page 9 Questions, problems, missing parts? Before returning to the store, call Gluckstein Elements Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 888-628-1888 HOMEDEPOT.CA GLUCKSTEINELEMENTS.COM Retain this manual for future use.
