User Manual

AMTL-RAD-10

Date: March 2025

Version: 1.1

P a g e

| 1

Table of Contents

Need help?

Do you have a question about the AMTL-RAD-10 and is the answer not in the manual?

Questions and answers

Summary of Contents for ARMATURA AMTL-RAD-10

Page 1 User Manual User Manual AMTL-RAD-10 Date: March 2025 Version: 1.1 P a g e...
Page 2 ARMATURA supplied equipment vests in and is the property of ARMATURA. The contents hereof should not be used or shared by the receiver with any third party without express written permission of ARMATURA.
Page 3 ARMATURA shall in no way be responsible (i) in case the machine/unit/equipment malfunctions due to any non-compliance of the instructions contained in this manual (ii) in case of operation of the machine/unit/equipment beyond the rate limits (iii) in case of operation of the machine and equipment in conditions different from the prescribed conditions of the manual.
Page 4: Table Of Contents
8.3 Set Parameter for Radar ....................... 14 8.4 Background Recording ......................16 8.5 Display of Target Information....................17 9 DEBUG RADAR WITH SOFTWARE ................... 19 10 FAQ ............................21 11 PACKING LIST .......................... 21 P a g e Copyright © 2025 ARMATURA LLC. All rights reserved.
Page 5: Product Introduction
Through the joint optimization design of software and hardware, this product can accurately identify and distinguish between pedestrians and vehicles passing through the barrier area, and prevent the barrier from hitting people and cars. Also, users could set parameters of AMTL-RAD-10 with a mobile app (Radar Assistant) when connected it to Bluetooth.
Page 6: Appearance And Dimensions
4 Parameters Model AMTL-RAD-10 Detection Distance 3.28ft to 19.69ft (1m to 6m) Operating Frequency 79GHz Operating Voltage DC 10V to 16V Operating Current 0.2A Power Consumption ≤ 2.5W P a g e Copyright © 2025 ARMATURA LLC. All rights reserved.
Page 7: Installation Instruction
If there is a misrecognition due to radar causing opening the gate or not closing, please re-learn the background. P a g e Copyright © 2025 ARMATURA LLC. All rights reserved.
Page 8: Product Installation
Drilling Use an electric drill to drill a fixed hole suitable for M16 at the selected position of the barrier box. The recommended drill bit diameter is 16mm. P a g e Copyright © 2025 ARMATURA LLC. All rights reserved.
Page 9 M16 screws to fix it, then insert the end of the wire harness into the radar in the correct direction and lock the metal buckle to complete the installation. P a g e Copyright © 2025 ARMATURA LLC. All rights reserved.
Page 10: Wiring
When the radar is connected to the P15, PB4000, CMP200, BG1000 barrier gate, the normally open signal wire of the radar, that is, the blue and green wires, are connected to the ground sense coil P a g e Copyright © 2025 ARMATURA LLC. All rights reserved.
Page 11 (no distinction between positive and negative). AMTL-RAD-10 Radar connected to P15 barrier gate AMTL-RAD-10 Radar connected to PB4000 barrier gate AMTL-RAD-10 Radar connected to CMP200 barrier gate P a g e | 10 Copyright © 2025 ARMATURA LLC. All rights reserved.
Page 13: Debug Radar With App (Radar Assistant)
QR code for android phone If the system of phone is iOS, go to the App Store and search "Radar Assistant" for downloading it. P a g e | 12 Copyright © 2025 ARMATURA LLC. All rights reserved.
Page 14: Connect To Bluetooth
Click the [Once] or [Allow only while using the app] button to access the application. Open the Bluetooth of the phone, and click [CONNETING DEVICE] to connect the Bluetooth of radar. P a g e | 13 Copyright © 2025 ARMATURA LLC. All rights reserved.
Page 15: Set Parameter For Radar
8.3 Set Parameter for Radar Enter the parameter setting interface of anti-smash mode, select the straight boom gate type first, as the pictures shown below. P a g e | 14 Copyright © 2025 ARMATURA LLC. All rights reserved.
Page 16 Use the left and right button to adjust the parameter value. Long press the button can quickly adjust the parameter value. Brake Type: There are three types of boom, straight boom, advertising boom and fence boom, by default, we choose the straight boom. P a g e | 15 Copyright © 2025 ARMATURA LLC. All rights reserved.
Page 17: Background Recording
Restart the radar and disconnect the Bluetooth. The boom type is a fence boom/advertisement boom/airborne gate, and the background learning steps are as follows: Keep the barrier boom in a raised state; P a g e | 16 Copyright © 2025 ARMATURA LLC. All rights reserved.
Page 18: Display Of Target Information
After the background learning is completed, you can click to display the target information. During this process, please do not perform other operations except stop the display. P a g e | 17 Copyright © 2025 ARMATURA LLC. All rights reserved.
Page 19 If there is false alarm on the interface, click [STOP DISPLAY] and then click [ELIMINATE FALSE ALARM]. After Eliminate false alarm, it can be used normally. P a g e | 18 Copyright © 2025 ARMATURA LLC. All rights reserved.
Page 20: Debug Radar With Software
Threshold: Set the detection sensibility. High Sensibility supports anti-smashing and dropping boom (When people and vehicles leave the  radar detection area) for people and vehicles. P a g e | 19 Copyright © 2025 ARMATURA LLC. All rights reserved.
Page 21 The radar can be used after power off and restart. Note: During background learning, ensure that there are no movable targets (vehicles, people) other than the fixed environment within the radar detection range. P a g e | 20 Copyright © 2025 ARMATURA LLC. All rights reserved.
Page 22: Faq
Possible cause: It is recommended to connect an external 12V-1A power adapter. 11 Packing List Number Accessories Quantity AMTL-RAD-10 Radar M16 Nut Gasket Rubber Waterproof Ring Wiring Harness User Manual P a g e | 21 Copyright © 2025 ARMATURA LLC. All rights reserved.
