UNILITE HT-1600R Manual

PRODUCT FEATURES
● Super bright 1600 lumen 6500k white LEDs
● Easy twist smooth dimming switch
● White spot beam & flood beam LEDs
● Red LEDs for night vision & emergency/signalling
● 60˚ Rotating head angle
● Adjustable non-slip silicone lined headbands
● Smart Memory - remembers last white mode used
● IPX5 water resistant
● Hard-shell protective zipped storage case included
● 1m High quality USB-C Charging cable included
● 2 x 21700 5000mAh Li-ion batteries
● Parallel circuitry (can run on 1 or 2 batteries)
● Useful battery level & charging indicators
● Fast 5V-3A USB-C charging - 5 hr charge time
● Battery pack can be completely detached & used as an independent
powerbank (5V-3A output)
● Each 21700 battery is also its own independent power bank
BATTERY - 2 x 3.7v 21700 5000mAh Li-ion
DIMENSIONS - Headtorch: 40 x 65 x 35.5 mm
Battery Pack: 50 x 106 x 30 mm
WEIGHT - 392g (with 2 batteries)
OPERATING INSTRUCTIONS
Head Strap Buckle
Floodlight
0 1600
Lumens Lumens
White Mode Smart Memory - if left ON in any white MODE for 5+
seconds, then turned OFF, next time it's turned on it will return to
Smooth Twist Dimming Option
Off To High the last MODE used.
| EU Responsible Contact:
Aspen Pumps France, 353 Allee des Vergers, 76360 Barentin
Tel: +33 (0) 1 78 95 88 82 Email: ventes@aspenpumps.com
English
Red On / Off & White Mode Selector
Red Light
Spotlight
Red Light
www.unilite.co.uk
ANSI FL1 Standard
SPOT & FLOOD
- HIGH
SPOT & FLOOD
- LOW
SPOT - HIGH
SPOT - LOW
FLOOD - HIGH
FLOOD - LOW
RED - HIGH
RED - FLASHING
*These runtimes are based on using 2 x Unilite 21700 5000mAh li-ion batteries. Using 1 battery will
reduce runtimes.
RECHARGING THE BATTERY PACK / POWERBANK
1. Only use a 5V USB-C cable (max 3A)
2. Lift the charging port cover on the top of the battery pack.
3. Plug the USB-C end of the cable into the charge port.
4. Plug the USB-A end of the cable into a USB charging source (do not
exceed 5V 3A charging input or damage may occur).
5. 4 x Blue LEDs will flash to indicate charging status. All 4 LEDs will light
up constantly to confirm the batteries are fully charged.
6. Charge Time: 5 hrs
**Warranty void if not used with the specified cable & max input**
Power Connection To Headlamp Unit
USB-A Output & USB-C Input
Power & Recharging Indicators
RECHARGING THE 21700 BATTERIES
You can recharge the 21700 batteries outside of the lamp. This enables
spares to be kept on hand if you require light for an extra long period.
Once plugged in, a Red light will appear on the top of the battery to
confirm charging. Once fully charged it will turn Green.
USB-C Bi-Directional Port
- End
HT-1600R
1600
125M 8H
Lumen
150
41M 25H
Lumen
900
128M 11H
Lumen
85
40M
38H
Lumen
700
35M 11.5H
Lumen
65
11M 38H
Lumen
10
8M 28H
Lumen
10
- 32H
Lumen
Battery Level Battery Compartment
Display Button With Locking Mechanism
+ End
