Summary of Contents for Foamit GK2T-24VAC
- Page 1 USER MANUAL MODEL NUMBER: GK2T-24VAC AND RELATED UNITS Doorway Central Station English (Original Instructions)
-
Page 2: Protect The Environment
Always remember to recycle. *Specifications and parts are subject to change without notice. Model Number: GK2T-24VAC AND RELATED UNITS Page 2 of 7 | 20250414... -
Page 3: Specifications
*Dilution rates and flow rates given are based on chemical with viscosity of water and factory air pressure settings. **Foam pattern dimensions provided were measured with nozzle assemblies mounted 6 in. (15 cm) above the floor. Model Number: GK2T-24VAC AND RELATED UNITS Page 3 of 7 | 20250414... -
Page 4: Installation Instructions
Connecting the inlet to the stem Connecting the inlet to one of the tee creates even discharge side of the tee creates uneven from each side discharge Model Number: GK2T-24VAC AND RELATED UNITS Page 4 of 7 | 20250414... -
Page 5: Maintenance Instructions
A solenoid valve may need to be replaced. • If no liquid discharges out of the fan tip: a. Verify there is adequate liquid being supplied to the control box. Model Number: GK2T-24VAC AND RELATED UNITS Page 5 of 7 | 20250414... -
Page 6: Control Box Assembly
CONTROL BOX ASSEMBLY QF1212 SSA1412 FW14NPT AG100 NV14 SN1414 FCV14-24VAC WC1012-FSPD14 TSW-BDY, TSW-PLT, and TSW-BT CV1438 WC1416-FSPD14 SSC38 TMR-RPT-24VAC H38BL-F (Available per .) HBEL1238 PS120VAC-24VAC-1.2A PB12117-BOX CGRP12-NUT CGRP12 QF1212 Model Number: GK2T-24VAC AND RELATED UNITS Page 6 of 7 | 20250414... - Page 7 STAINLESS STEEL HINGE PIN FOR PB16138 AND WMS14A WALL MOUNT SCREW ANCHOR -#14 X 1 1/4IN - PB12117 PLASTIC - 5/16IN DRILL SIZE PS120VAC-24VAC-1.2A PLUG-IN VOLTAGE TRANSFORMER - 120VAC INPUT - 24VAC 1.2A OUTPUT Model Number: GK2T-24VAC AND RELATED UNITS Page 7 of 7 | 20250414...
