GHT -S7415H2 User Manual

Any issues,like tech-support,please feel
free to contact us,we will try our best to
help you solve the problem.
Warm Tips
1. Please keep this manual in a safe and conspicuous place for easy
reference when needed.
2. If you encounter any problems when using the product, please contact
us so that we can provide you with friendly after-sales support.
HDMI 4*1 KVM SWITCH
Model:GHT-S7415H2
The HDMI 4*1 KVM switcher can freely switch four sets of high definition audio and video
signal sources and USB signals. It supports EDID adaptive function that can adapt to a variety
of complex application environments. The device has excellent image processing and
transmission capabilities, making the output signal more smooth and stable. It is a reliable,
high-performance and efficient switching device.
Support free switching between four high definition audio and video signal sources and USB
signals;
Support HDMI 2.0, HDCP 2.2 standard and USB 3.0 protocol;
Support resolution up to 3840*2160@60Hz, backward compatibility;
Support HDMI dual display (this function is only used on the host that supports dual display
or multi display);
Support maximum data transfer rate 5 Gbps for USB 3.0;
Automatic adaptation of EDID, adapt to a variety of complex application environments;
Automatically identify and configure various display modes;
Built-in automatic equalization system, making the picture smoother, clearer and more stable;
Simple and easy to install, plug and play, no need any drivers.
① ② ③ ④
①
HDMI 4*1 KVM Switcher Host
②
USB-A to USB-A USB 3.0 Cable
③
HDMI2.0 Cable
④
USB-A to USB-C Power Cable
⑤
User Manual+Warranty Card
⑥
Foot Pad
Standards
Maximum Pixel Clock
Maximum Data Rate
Video
Maximum Resolution
Connector
Impedance
HDMI Cable Range
Interface Protocols
USB
Maximum Data Transfer Rate
PC Input Interface Type
Output Interface Type
Power Supply
Power Dissipation
Temperature
Other
Humidity
Dimension
The Warranty
HDMI 4*1 KVM SWITCH HDMI 4*1 KVM SWITCH
Model:GHT-S7415H2 Model:GHT-S7415H2
Warranty
Card
⑤ ⑥
1 Pcs
4 Pcs
2 Pcs
1 Pcs
1 Set
4 Pcs
HDMI 2.0, HDCP 2.2
600 MHz
18 Gbps
3840*2160@60Hz,
Backward compatibility
HDMI-A Interface
100Ω
<5M( Resolution: 1920*1080@60Hz)
USB 3.0
5 Gbps
USB-A
USB-A
5V power supply
MAX 3W
Operating: -5℃ ~ +70℃
Operating: 5% ~ 90%
202*76*33mm
1 year free warranty
