FOLLOW SAFETY INSTRUCTIONS
Carefully read all safety messages in this manual and in the
Gator's operators manuals for any instructions and
safety messages.
Do not let anyone install or use without proper
installation.
1
9/16" wrench and/or socket
3/4" wrench and/or socket Drill
(cordless recommended)
WARNING
This product can expose you to chemicals which are known to the State of California
to cause cancer, birth defects, or other reproductive harm.
For more information, go to www.P65Warnings.ca.gov
GT1MK CANOPY KIT
Tools NEEDED
3/8" Drill bit Level
HOW TO GET HELP
Call us at 855-398-6540 (8 AM - 4 PM)
Email us at support@thunderbirdaz.com
Contact your local dealer where you purchased
this product.
By Thunderbird Industries
Two Person Assembly
Recommended
WARNING!
Canopy Support Structure
is NOT a ROPS rollbar and
will NOT provide passenger
roll-over protection.
GT1MK INSTALLATION
Advertisement
Summary of Contents for Thunderbird TRACTOP GT1MK
- Page 1 By Thunderbird Industries GT1MK CANOPY KIT Tools NEEDED 9/16” wrench and/or socket 3/4” wrench and/or socket Drill Two Person Assembly (cordless recommended) Recommended 3/8” Drill bit Level WARNING! Canopy Support Structure is NOT a ROPS rollbar and will NOT provide passenger roll-over protection.
- Page 2 By Thunderbird Industries GT1 CANOPY KIT INSTALLATION GUIDE for John Deere T-Series Gators CANOPY ASSEMBLY 1. U-bolt Installation and Rod Securing 3. Attaching the 39” Cross Strap Position the upright and insert a U-bolt, loosely attaching Attach the 39” x 3/4” cross strap as shown in Diagram 3. It is the flange nuts (see Diagram 1).
