Table of Contents
Dynex 400-Watt ATX Power Supply
Setup............................................................................................................................................... 1
Wire Configuration ........................................................................................................................ 4
Hardware Issues ............................................................................................................................ 4
General ........................................................................................................................................... 5
Setup
1. How do I set up my Power Supply?
Have you tried using your User Guide to help you through this process? If more
help is needed, follow the steps below.
a. Turn your computer off.
b. Unplug the power cable from your computer.
c. Remove the side panel on your computer, so you can access the power
d. Disconnect all power supply connections from the motherboard and
e. Remove the old power supply from your computer case and install your
FAQs
(DX-400WPS)
June 30, 2011
supply and connectors.
peripheral devices, such as hard drives, optical drives, video cards and
fans. Make sure to note cables you are removing for when you need
to reconnect them later.
new Dynex power supply, securing it to the computer case with the
appropriate screws.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dynex DX-400WPS
Summary of Contents for Dynex DX-400WPS
- Page 1 Make sure to note cables you are removing for when you need to reconnect them later. e. Remove the old power supply from your computer case and install your new Dynex power supply, securing it to the computer case with the appropriate screws.
- Page 2 Reconnect all power supply cables. Make sure that each connection is secure. Reference your notes from when you removed the old power supply to make sure you are making all connections which were previously in place. a. Connect the 20+4-pin main power connector to your motherboard.
- Page 3 ii. The floppy drive power connector to the floppy drive. iii. The Serial ATA connector to any devices that have a Serial ATA interface. iv. The 6-pin +12V power connector(s) to the PCI-E graphic card(s). g. Connect your case fans to the regular 4-pin peripheral connectors if you are using these fans.
- Page 4 Wire Configuration 2. What should the connectors look like? Hardware Issues 3. Nothing happens when I try to start up my computer. Make sure the computer power cable is firmly plugged into the power cord connector on your power supply. This power cable will extend out the back of your computer.
- Page 5 General 4. Where can I get more information about my power supply? Refer to your User Guide or the Dynex Website: http://www.dynexproducts.com/products/computers/DX-400WPS.html 5. Is someone available to install the power supply for me? Visit your local Best Buy Geek Squad for assistance or call Geek Squad at 1- 800-GEEKSQUAD (1-800-433-5778).
