NEVOKS FEELIN POD KIT Manual

EXPLODED VIEW

SPECIFICATIONS

PACKING LIST

.Feelin Device X1
.Feelin Empty Pod(2.8ml) X1
.SPL-10 Mesh Coil 0.6Ω X1
.SPL-10 Mesh Coil 1.0Ω X1
.Type-C cable X1
.User manual X1
.Warranty Card X1

USE INSTRUCTION

1. Install the Coil
   Take out the coil from the package, and insert the coil firmly into the pod.
2. Replace the Coil
   1. Please confirm the POD is empty before replacing coil.
   2. Pull out the used coil
   3. Install a new coil firmly
3. Fill the E-liquid
   • Uncover the silicone plug at the side of POD.
   • Gently insert the e-liquid filling bottle tip to the filling slot and press down to squeeze the e-liquid through the slot.
   • Please wait for 5 minutes for the e-liquid to soak into the coil.
4. Power on the Device
   Click the power button 5 times in 2 seconds to power on (the LED indicator will be flash from the L1 to L3) then press the key button to start vaping or just inhale directly.
5. Start Vaping
   Pressing the firing button or just inhaling both can enjoy the extremely smooth vaping experience. The auto-draw function and firing button could be switched freely and no button pressing.
6. 3 Levels Voltage adjustable
   Within the power on status, continuously pressing the firing button 3 times to enter the voltage adjustment status. The L3 light will be on when the voltage is in 3.1V, the L3 and L2 light will be on when the voltage in 3.4V, all the 3 LED lights will be on when the voltage is 3.7V.

7. Charging the Battery
   After connecting the Type-C cable to the battery, the LED indicator will flash from L1-L2-L3 when the power is 0-30%, the L1 light will be firmly on and the L2 and L3 will be flash when the power is 30%-70%, L1 and L2 will be firmly on but the L3 will be flash when the power is 70%-90%, All the 3 LED lights will be on once the power reaches 90%-100%. Once fully charged, the LED lights will be off. You could enjoy vaping during the charging
8. Power status
   When vaping, all the 3 LED indicators will be on when the power is 70%-100%, the L1 and L2 will on when the power is 30%-70%, the L1 will be on when the power is 0-30%.
9. Settings
   1. Power on/off: Press the button 5 times in 2 seconds to power on(the LED indicator will be flashed from L1-L2-L3) or power off(the LED indicator will be flashed from L3-L2-L1) the device.
   2. Adjust the airflow: Pull out the cartridge and rotate it 180 degrees to change the airflow.
   3. 3 Levels voltage adjustment: Continuously pressing the firing button 3 times to adjust the voltage, total 3 levels voltage adjustment: 3.1V, 3.4V and 3.7V and the related LED lights will be on to show it when adjusting.
   4. Dormant state: Without operation for 1 seconds, press any key to wake up.

PROTECTIONS

1. Overtime Protection: Intelligent overtime protection will avoid atomizer's coil and cotton being burned.
2. Short-circuit Protection: When the short-circuit is detected, the mod will protect the battery by preventing the circuit from returning.
3. Overcharge Protection: With dedicated lithium battery protection components, the battery will be protected against battery overcharge and damage.
4. Low Voltage Protection: When the output is below 3.3V, the 3 LED lights will flash 15times to remind you to charge the device.
5. Over Discharge Protection: With dedicated lithium battery protection components, the battery will be protected against battery discharge and harm.
6. Over-temperature Protection: TC mode assures the mod and battery work properly within safe temperature range.

CAUTIONS

*Please turn off the device when it is not in use.
*Do not leave the charging device unattended.
*Do not drop, throw or abuse your device, which may cause damage.
*Keep away from the water or any flammable gas, liquid.
*Do not expose the device to direct sunlight, dust, moisture or mechanical shock.
*Do not expose the device to extreme temperature.
*Battery Recycling: The product battery should not be treated as household waste, instead, it should be handed over to the applicable used battery collection point for recycling.

WARNINGS

This refillable electronic cigarette is intended for use with compatible e-liquid, which may contain nicotine. Nicotine is an addictive substance and it is not suitable or recommended to use in following cases:

1. This device is not suitable for:
   *Persons under the legal smoking age.
   *Persons experiencing heart disease, stomach or duodenal ulcers, liver or kidney problems, long-term throat disease or difficult breathing due to bronchitis, emphysema or asthma.
   *Persons with an overactive thyroid gland or experiencing phaeochromocy toma (a tumour of theadrenal gland that can affect blood pressure).
   *Persons taking certain medications like Theophylline, Ropinirole or Clozapine and etc...
2. This device is not recommended for:
   *Non-smokers
   *Pregnant or breastfeeding women.
3. You may experience the following results if you use nicotine containing e-liquid with this product. If it happens, please consult a healthcare professional and show them this leaflet if possible:
   *Feel faint-Nausea-Dizziness-Headache-Coughing-Irritation of the mouth or throat
   *Stomach discomfort –Hiccups-Nasal congestion-Vomition
   *Chest palpitation/pain or an irregular heart rate

This device should not be used by persons under the legal smoking age.

If there is any additional requirement about the product, please consult the local agent or contact us through our website: www.nevoks.com

www.nevoks.com
Shenzhen Nevoks Technology Co., Ltd.
INS@nevokstech
FB@nevoks
Youtube@nevokstech
