OPERATING AND ASSEMBLY INSTRUCTIONS DE

Models VAIO IQ 33 + XL

Attention: please note!

Heavy natural stone panels are fitted to the VAIO IQ

Stein stove. These must be carefully secured and all

brackets must be firmly screwed in place to prevent

dangerous tilting of the panels.

VAIO IQ 33 Steel

VAIO IQ 33 Natural Stone

VAIO IQ 33 XL Steel

VAIO IQ 33 XL Natural Stone

Stand: 02-2025

Table of Contents

Need help?

Do you have a question about the VAIO IQ 33 and is the answer not in the manual?

Questions and answers

Summary of Contents for CB-tec VAIO IQ 33

Page 1 OPERATING AND ASSEMBLY INSTRUCTIONS DE Models VAIO IQ 33 + XL Stand: 02-2025 VAIO IQ 33 Steel VAIO IQ 33 Natural Stone VAIO IQ 33 XL Steel VAIO IQ 33 XL Natural Stone Attention: please note! Heavy natural stone panels are fitted to the VAIO IQ Stein stove.
Page 2: Table Of Contents
14. Maintenance 15. Malfunctions Note: Warranty claims are void if the operating and installation instructions are not observed. Technical changes and errors excepted. CB-tec GmbH | Behaimweg 2 | D – 87781 Ungerhausen VAIO IQ | Operating and assembly instructions...
Page 3: General Information
Before the received goods are unpacked, they must be visually inspected for damage in their packaged state. For any warranty claims against the delivering forwarding agent, it is imperative that any damage is noted on the delivery note/forwarding bill and documented by means of photos. CB-tec must be notified immediately of any damage.
Page 4 Combustion air supply The stove may only be installed in rooms with a sufficient supply of combustion air. This is guaranteed in rooms that have at least one door to the outside or a window that can be opened, or that are directly or in- directly connected to other rooms in a combustion air network.
Page 5: General Warranty Conditions
CB-tec reserves the right to either rectify the defect or replace the device free of charge within the scope of this guarantee promise. The elimination of defects has priority.
Page 6: Warranty Exclusion
Warranty exclusion The warranty does not cover: The wear and tear of the product ƒ Fireclay/vermiculite/thermoconcrete: are a natural product that is subject to expansion and contraction with ƒ every heating process. This can lead to cracks. As long as the linings retain their position in the combustion chamber and do not break, they are fully functional.
Page 7: Declaration Of Performance
5. product data sheets in accordance with Regulation EU 2015/1186 Name or trademark of the supplier: CB-tec GmbH Model of the supplier: VAIO IQ 33 VAIO IQ 33 XL Energy efficiency class of the model: Direct heat output [kW]: Energy Efficiency Index EEI: 112,5...
Page 8: Technical Data
1. BlmSchV. | 2. BlmSchV.  Room air-independent * The height of the VAIO IQ 33 steel version with a stone top panel is 118.50 and 158.10 (XL). The weight is 210 kg and 310 kg (XL). Italy ** The VAIO IQ models have a connection socket at the bottom.
Page 9: Dimensional Drawings And Type Plates
Natural stone finish approx. in mm Nameplates VAIO IQ 33 Steel VAIO IQ 33 Natural Stone VAIO IQ 33 XL Steel VAIO IQ 33 XL Natural Stone CB-tec GmbH CB-tec GmbH CB-tec GmbH CB-tec GmbH VAIO IQ 33 VAIO IQ 33...
Page 10: Stove Installation
9. stove installation Requirements for the installation site Subject to errors and misprints. All information and The stove may only be installed in rooms and places where no danger can arise due to the location, struc- tural conditions and type of use. For proper operation of the stove, the floor space of the installation room must be designed and large enough to ensure that sufficient combustion air can flow into the room at all times.
Page 11: Assembly Instructions
10. Variant: VAIO IQ Steel is delivered fully assembled. 10.1 Detailed assembly of the VAIO IQ (natural stone cladding) Watch the assembly video Contents Heating technology incl. door handle ƒ Side panels (natural stone) ƒ TOP plate (natural stone) ƒ Oven glove ƒ...
Page 12: Unpack The Stove
Unpack the stove Carefully unpack the heating element and transport it to the installation location. Preparation of connections If a rear connection for the combustion air and/ or for the flue pipe is desired, the pre-perfo- rated holes in the metal rear panel must be removed.
Page 13 Installing and aligning heating technology Position and align the heating technology at the installation site. Ensure the correct wall distances. Variant A) Stone covers Mounting side panels Carefully lift the right side panel up to Device the oven so that the claws fit into the device.
Page 14 Variant B) 45-degree block holder Watch the assembly video Dismantling the upper stone holder Unscrew the upper brick holders. Dismantling the lower stone holder To open the storage compartment door, unscrew the lower stone holder. Attaching and fixing the side stone slabs Position the stone slabs on the side of the stove.
Page 15 Insert the lower stone holders into the recess in the natural stone and loosely screw them on (not too tight – the side panels must be able to slide for final alignment). Stone cladding Storage Stone holder ATTENTION Conflict when opening the door. Please be careful not to align the side panels too far forward, as this may damage them when opening the door.
Page 16 Mounting storage block – only variant The storage block is delivered in the lower part of the furnace. The storage block consists of three parts. Starting at the bottom, insert the first unit of the storage block into the upper fixture.
Page 17 Variants of TOP panels Base plate with a TOP plate (total approx. 40 kg). Place 7 silicone spacers so that the second TOP plate (with insert) cannot wobble. Position the spacers halfway on the TOP plate at the insert. Place the second TOP plate on top (total approx. 80 kg). Place 7 silicone spacers so that the second TOP plate (with insert) cannot wobble.
Page 18: Commissioning Report
11. Commissioning report Datum: Serien-Nr.: (siehe Typenschild) Installation company: Has the actual delivery  Yes  No pressure been checked? Pressures greater than 20-25 Pa can affect correct operation. In this case, window contamination or noise can be increased. Test burn carried out: ...
Page 19: First Heating
How to open the firebox door correctly Grip Grip haul haul   The firebox door is opened correctly by pulling the handle to the left. Ash container Pull the ash container handle up and remove it towards the front. Do not forget that glowing ash can remain in the ash container for several days.
Page 20: Insufficient Heating
Storage of firewood A residual moisture content of max. 20% can be achieved by storing the wood outside for at least a year (two years is better), with a roof provided over it. Wood stored indoors tends to dry out too much and therefore burns too quickly.
Page 21: Cleaning
Heat through Do not add firewood or restrict the air supply before going to bed. This would cause a lot of unhealthy smo- ke. Furthermore, soot can build up in the chimney, which in turn can lead to a chimney fire. The VAIO IQ fireplace must not be operated in continuous burning mode.
Page 22: Maintenance
Cleaning natural stone cladding The natural stone elements may only be cleaned using the specially developed CB-tec natural stone cleaning and care materials. CB Spray Care should be used for maintenance care. CB Spray Care also ensures lasting impregnation of the natural stone cover.
Page 23: Malfunctions
Maintenance The fireplace should be thoroughly inspected at least every two years. The inspection includes, among other things: • Thorough cleaning of the fireplace. • The seals must be checked and replaced if they are damaged or no longer soft. •...
Page 24 Q U A L I T Y M E E T S D E S I G N CB-tec GmbH Behaimweg 2 DE-87781 Ungerhausen Tel.: +49 (0) 83 93 9469 - 0 info@cb-tec.de www.cb-tec.de www.vaio-iq.de Subject to errors and misprints. All information and statements in the catalog as of 02-2025. We expressly point out that natural stone is a natural product.
