Summary of Contents for Brain Bee ST-PRINTER 6000
- Page 1 ST-PRINTER 6000 PORTABLE THERMAL PRINTER ST-PRINTER 6000 CAP. 1 - INDEX 1 / 30 ENGLISH...
-
Page 2: Table Of Contents
BATTERIES REPLACEMENT .......... 19 6.1.3 BATTERIES DISPOSAL ..........19 CAP. 7 - MAINTENANCE ............20 PAPER ROLL CHANGE ............20 CLEANING ............... 21 CAP. 8 - CONFIGURATION............22 ST-PRINTER 6000 ........22 ONFIGURATION PRINTABLE CHARACTERS SETE RRORE SEGNALIBRO È DEFINITO CAP. -
Page 3: Cap. 2 - General Information
All rights reserved. Total or partial reproduction of this manual in any form is forbidden, be it in paper or digital format. BRAIN BEE SPA and the resources involved in the making of this manual disclaim all responsibility in relation to the use of the manual itself, guaranteeing that all information contained therein has been accurately verified. -
Page 4: Cap. 3 - Safety Conditions
ST-PRINTER 6000 CAP. 3 - SAFETY CONDITIONS IMPORTANT INFORMATION ON PERSONAL SAFETY 3.1.1 DEFINITIONS DANGEROUS AREAS: Any area within or close to the equipment implying risk for the safety and health of exposed persons. EXPOSED PERSON: Any person completely or partially standing in a dangerous area. -
Page 5: Precautions For Operators Safety
ST-PRINTER 6000 3.1.2 PRECAUTIONS FOR OPERATORS SAFETY GENERAL PRECAUTIONS • All the operators shall not be under the effect of tranquillizers, drugs or alcohol when performing their job • Before starting their job, operators shall be perfectly aware of the position and operation of all the controls indicated on the use manual. -
Page 6: Gasoline Engines
ST-PRINTER 6000 RISK OF ASPHYXIA GASOLINE ENGINES Exhaust gases of gasoline vehicles contain carbon monoxide, a colourless and odourless gas which, if inhaled, can cause serious physical problems. Special attention is always required when working within pits, as exhaust gases components are heavier than air and consequently deposit on the bottom of the pit. - Page 7 ST-PRINTER 6000 RISK OF INJURY Engines, both working and in standstill, include moving parts (belts or other parts) which might injure hands and arms. In the vehicles, the cooling fan starts automatically by means of a temperature sensor even when the engine is off;...
- Page 8 ST-PRINTER 6000 SAFETY MEASURES: Disable start. Let the engine cool down. Do not use free flames or sparks sources. Do not smoke. Collect the outflowing fuel. Start the aspiration units in closed premises. RISK RELATING TO NOISE LEVEL During measurements on the vehicle and use, noise levels can exceed 90dB. Such noise levels can be reached with ultrasonic cleaning or with the vehicle’s engine high...
- Page 9 ST-PRINTER 6000 RISK OF INTOXICATION The pipes that are used for exhaust gases sampling if subject to high temperatures (exceeding 250 °C or due to fires) release a highly toxic gas which, in case of inhalation, can be harmful for health.
-
Page 10: Important Information On Tool Safety
ST-PRINTER 6000 IMPORTANT INFORMATION ON TOOL SAFETY When using the tool, the following operations are not allowed as they might cause, under certain circumstances, danger for persons and cause permanent damage to the tool itself - Do not remove or make unreadable labels, signs and/or dangers signs placed on the tool and in the area nearby. -
Page 11: Cap. 4 - Manual Structure And Use
ST-PRINTER 6000 CAP. 4 - MANUAL STRUCTURE AND USE MANUAL USE Carefully read this manual before starting the equipment. • This manual is aimed at providing the user with all the information required for a correct use of the equipment and to enable the user to manage it in the safest and most independent way. -
Page 12: Simbols
ST-PRINTER 6000 The operations that might result in situations potentially harmful for the operators are highlighted by means of the symbol alongside Such operations can cause serious physical damage. Operations requiring particular attention are highlighted by means of the symbol alongside. -
Page 13: Cap. 5 - General Features
Size and weight are extremely limited. The ST-PRINTER 6000 printer is power supplied by means of batteries (5 rechargeable batteries, size AA) with RS232 serial interface and is provided with a 203 dpi thermal printing system, employing paper having a width of 57,5 mm in rolls and printing 24 characters per line. -
Page 14: The Multifunction Key
ST-PRINTER 6000 THE MULTIFUNCTION KEY This key allows for several printer functions, according to the duration of the pressure on the key. If the printer is turned off (red led off), by pushing the key, the printer is power supplied (red led blinking). To turn off the printer, push the key twice (the led starts blinking faster and the printer turns off). -
Page 15: Cap. 6 - Connections
ST-PRINTER 6000 CAP. 6 - CONNECTIONS POWER SUPPLY For batteries recharge and for serial connection, the printer is provided with a connection cable, contained in the printer packaging, consisting in a double interconnection system. On one side there is a 9-pin connector that can be connected to the scantool serial port;... - Page 16 ST-PRINTER 6000 For a correct recharge, a 2-hour recharge is recommended. NOTE During the recharge phase the printer does not turn off. WARNING An erroneous battery recharge voltage (differing form the one indicated on the table ) might cause serious damage to the printer.
-
Page 17: Notes For The Use Of Batteries
ST-PRINTER 6000 6.1.1 NOTES FOR THE USE OF BATTERIES Please note that a new NiMH battery reaches its best performance after being completely run down and then recharged for at least two or three times. The battery autonomy can vary remarkably, for instance, according to the printing density and the text to the printed. - Page 18 ST-PRINTER 6000 CHARGE: When charging rechargeable batteries, use exclusively the battery-charger provided with the equipment and recharge in premises with a temperature ranging between 10 °C and 45 °C. The use of a battery- charger different from the recommended one can lead to batteries overload.
-
Page 19: Batteries Replacement
ST-PRINTER 6000 6.1.2 BATTERIES REPLACEMENT Cannot be used in place of the rechargeable batteries pack supplied with the printer, 5 batteries ALKALINE type, size AA. WARNING In case batteries ALKALINE type, size AA are used , that is NON RECHARGEABLE batteries, this might lead to the ST-PRINTER printer explosion and subsequent serious damage of the Scantool . -
Page 20: Cap. 7 - Maintenance
ST-PRINTER 6000 CAP. 7 - MAINTENANCE PAPER ROLL CHANGE To change the paper roll comply with the following: Open the printer cover levering on the cover side projections and position the paper roll following the paper rotation direction as shown in the figure;... -
Page 21: Cleaning
ST-PRINTER 6000 CLEANING CLEANING: equipment cleaning can be carried out by personnel without specific technical knowledge, provided they have been previously informed on the main controls for the equipment to be unplugged from the mains. When needed, clean the external surfaces without using alcohol- , ammonia- or gasoline-based detergents. -
Page 22: Cap. 8 - Configuration
ST-PRINTER 6000 CAP. 8 - CONFIGURATION Configuration ST-PRINTER 6000 The printer signals the operation conditions in the configuration printout where some indications are outlined. SETUP DEFAULT HEAD TEMP. [°C] =22.5 BATT TEMP. [°C] =25.0 HEAD VOLT. [V] =6.3 Interface :RS232... - Page 23 ST-PRINTER 6000 The settable printer parameters are the following: • Interface: RS232 , Infrared. • IR Protocol: Enable, Disable • Baud Rate: 38400, 19200, 9600 , 4800, 2400, 1200, 600. • Data length: 7, 8 bits/car. • Parity: None , even or odd.
-
Page 24: Cap. 9 - Interface
ST-PRINTER 6000 CAP. 9 - INTERFACE RS232 SERIAL The printer is equipped with an RS232 serial interface with an RJ11 connector placed beneath the printer. For the serial connection, a connection cable is provided, within the printer packaging, consisting in a double interconnection system. -
Page 25: Cap. 10 - Technical Specifications
ST-PRINTER 6000 CAP. 10 - TECHNICAL SPECIFICATIONS 10.1 PRINTER TECHNICAL SPECIFICATIONS The tables indicate the main technical features of the ST-PRINTER 6000 printer 203 DPI (8 dot/mm) Resolution Paper roll size 57.5 mm ± 1 mm Paper run out Sensors... -
Page 26: Power Supply Unit Technical Specifications
ST-PRINTER 6000 10.2 POWER SUPPLY UNIT TECHNICAL SPECIFICATIONS Technical specifications of the power supply unit present inside the ST- PRINTER 6000 printer box. Input specifications Input voltage 230 Vac 50 Hz Input frequency Output specifications 18 Vdc Output voltage ENGLISH 26 / 30 CAP. -
Page 27: Cap. 11 - Accessories
ST-PRINTER 6000 CAP. 11 - ACCESSORIES 11.1 ACCESSORIES PROVIDED WITH THE TOOL The printer packaging includes a support kit made up of a belt hook and relative fixing screw. The following figure shows how the belt hook shall be assembled beneath the printer CAP. -
Page 28: Cap. 12 - Printing With St-Printer
CAP. 12 - PRINTING WITH ST-PRINTER 12.1 CONNECTION WITH SCANTOOL To print the values obtained through the vehicle diagnosis (for ex. Errors, parameters), the ST-PRINTER 6000 printer shall be connected to the tool. Comply with the following: • Take the cable supplied with the tool and connect the 9-pin connector to the serial port of the scantool. -
Page 29: Printing
ST-PRINTER 6000 12.2 PRINTING Push the F7 key, where enabled, to save the parameter and errors values. Once all the required data have been saved, they can be printed by going back to the general selection page and pushing the F2 key. - Page 30 ST-PRINTER 6000 The display shows all the values previously saved; by means of the F1 and F2 keys, up to eight saved items can be displayed Push the F3 key to erase all the saved data concerning the vehicle. Push the F4 key and a selection window opens with two options: printing by through SERV8000 and printing through RS232.
