Barth lococube KS-85 Manual

®
lococube
BAR H
Harness KS-85
Elektronik GmbH
lococube®
Harness KS-85
MANUAL
TABLE OF CONTENT
SAFETY INSTRUCTIONS �������������������������������������������������1
DESTINATED USE �������������������������������������������������������������1
DISCLAIMER ���������������������������������������������������������������������1
1 Product Features ���������������������������������������������������2
1.1 Delivery Content ......................................................2
2 Wiring ����������������������������������������������������������������������2
2.1 X1 & X2 connector: Supply & CAN ..........................2
2.2 X3 connector: Positive supply voltage ....................2
2.3 X4 connector: Ground .............................................2
2.4 X5 connector: CAN High .........................................2
2.5 X6 connector: CAN Low ..........................................2
© 2025 BARTH Elektronik GmbH | Im Depot 1-3 | D-49838 Lengerich | www.barth-elektronik.de | info@barth-elektronik.de
® BARTH and lococube are registered trademarks of BARTH Elektronik GmbH. All rights reserved to make changes without prior notice.
®
MANUAL
SAFETY INSTRUCTIONS
This manual contains notices which you should observe
to ensure your own personal safety, as well as to protect
the product and the connected equipment. These notices
are highlighted in the manual by a warning symbal and are
marked as follows, according to the level of danger:
Only qualified personnel should be
allowed to install and work on this
equipment� Qualified persons are
defined as persons who are authorized
to commission, to ground and to tag
circuits, equipment and systems in
accordance with established safety
practices and standards�
Turn off the power supply before
performing any wiring operations!
Short circuits can be harmful, critical and
can cause explosions and serious burns!
Please read this manual carefully and
observe all safety instructions!
DESTINATED USE
The lococube Harness KS-85 is designed to connect
®
two or more BARTH lococube
®
hardware�
DISCLAIMER
BARTH assumes no liability for usage and functio-
®
nality of the lococube
®
guidelines in this manual� The strict accordance of the
guidelines is important since the installation methods,
peripheal connectiongs, usage and maintenance can
not be controlled by BARTH
assumes no liability for any claims�
Seite: 1/2
Dokument: 9005-0128-A
Datum: 30.04.2025
Revision: A
products and/or other
®
when disregarding the safety
� Therefore BARTH®
®
