Jr. MARCHING BASS DRUM STAND

Congratulations on your purchase! To get optimum performance of your MJBS-1420 Junior Marching Series

Bass Drum Stand, please read this Instruction Manual completely before attempting to assemble or use.

Basket Section

Base Section

PEARL

MJBS-1420

Instruction Manual

Upper Tube

Pipe Joint

Note

This

product

designed to work with all sizes of

Pearl Junior Marching Series

Bass Drums only.

Basket Arms

Adjustment Nut

Stop Lock

Wing Bolt

(for Height Adjustment)

Wing Bolt

(for Tripod Adjustment)

specifically

Need help?

Do you have a question about the Junior Marching MJBS-1420 and is the answer not in the manual?

Page 1 PEARL Jr. MARCHING BASS DRUM STAND MJBS-1420 Instruction Manual Congratulations on your purchase! To get optimum performance of your MJBS-1420 Junior Marching Series Bass Drum Stand, please read this Instruction Manual completely before attempting to assemble or use. Note This product specifically designed to work with all sizes of...
Page 2 Base Section Assembly Stop Lock Loosen the Wing Bolt for Tripod Adjustment and extend The Stop Lock provides maximum security for the height the legs to make it free-standing. For optimum stability, adjustment by preventing any chance of slipping. In adjust the leg stance to a minimum of 26"...
Page 3 While supporting the Bass Drum with one hand, tighten Mounting the Bass Drum the Adjustment Nut so that all four of the Basket Arms Loosen the Adjustment Nut to fully open the Basket. firmly grip the Bass Drum at the Hoops (Fig.4). Gently place the Bass Drum onto the Basket and position the Green Dots on the Basket Arms to the Important...
Page 4 CAUTION Remove the bass drum when making any stand height adjustments. Use one hand to support the stand to prevent it from falling, and use your other hand to loosen or tighten the Wing Bolts/ Key Bolts. Keep your fingers clear of folding parts to avoid pinching or bodily harm. When handling tubular hardware, never put your fingers into the tubes;...
