- Page 2 Information contained in this document is subject to change without prior notice. Pumatronix reserves the right to modify or improve this material without obligation to notify the changes or improvements. Pumatronix grants permission to download and print this document, provided that the electronic or physical copy of this document contains the full text.
- Page 3 Installation Guide ITSCAMPRO NM1 Summary ITSCAMPRO NM1 Installation Steps ..........................3 Data Network Setting ................................3 2.1. Network Interface Parameterization ..................................4 Mounting the Devices ................................5 3.1. Mounting the Devices on the Pole ..................................5 3.2. Mounting the ITSLUX Illuminator ................................... 6 Electrical and Data Installations ............................
- Page 4 1. ITSCAMPRO NM1 Installation Steps Once the Installation Pre-Requirements and the Necessary Conditions for Installation have been met, as indicated in the ITSCAMPRO NM1 Product Manual, the initial installation steps must be carried out and are presented in the ideal sequence of execution: Data Network Setting;...
- Page 5 Installation Guide ITSCAMPRO NM1 Figure 2 - Setting options for the selected eth0 network 8) To set up a Static IP, mainly enter the IP Address, Subnet Mask and Gateway; 9) To set up the DHCP, click on DHCP and enter the details of the primary DNS and the alternative DNS;...
- Page 6 3. Mounting the Devices 17) Check the Positioning Requirements for the type of violation to be monitored, detailed in the ITSCAMPRO NM1 Product Manual; 18) Select the type of structure to mount the components on, considering the flexibility of the ITSCAMPRO NM1 installation, which allows the use of existing structures on a road, for example: Posts, Road Signs and Structures or Gantries;...
- Page 7 Installation Guide ITSCAMPRO NM1 Item Description ITSCAM VIGIA+ ITSCAM 411 with Protection Box, model PTX12 NM1 Frame or NM1 Compact Frame ITSLUX Illuminator Figure 4– Mounting the Devices on the Pole 3.2. Mounting the ITSLUX Illuminator 23) Assemble the ITSLUX NEVADA Bracket by inserting the ITSLUX illuminator and closing it with the Protective Acrylic indicated, using the parts shown in the image: www.pumatronix.com...
- Page 8 Installation Guide ITSCAMPRO NM1 Item Description Quantity Protective Acrylic ITSLUX NEVADA Bracket M5 x 16 stainless steel hex. bolt M5 stainless steel flat washer M5 stainless steel hex. nut M5 stainless steel spring washer Bracket base Figure 5 - ITSLUX Bracket Parts...
- Page 9 Diagram, which specifies the functions of the connections made between the modules and the local connections of the Tertiary Module: Figure 7 - ITSCAMPRO NM1 General Connection Diagram: 1) Main Module; 2) Secondary Module; 3) Tertiary Module Control Switchboard 28) Connect the traffic light signal to the Surveillance Board on the Tertiary Module switchboard. Consider...
- Page 10 30) Power the ITSCAMPRO NM1 system by connecting it via the Surveillance Board, as indicated in Surveillance Board Installation; 31) To carry out the electrical installation of the ITSCAMPRO NM1 system, you will need electrical conduits and cables of varying lengths, following the steps for connecting the installed assembly to a monitoring point: a) Divert electricity from the road's transmission lines to the Tertiary Module;...
- Page 11 Installation Guide ITSCAMPRO NM1 Figure 10 – Tertiary Module General Connector Diagram 4.1. Connections to the Surveillance Board (NM1 Switchboard) 32) Fasten the NM1 Switchboard to the road structure (Poles, Road Signs and Sign Structures or Gantries); 33) Carry out the electrical connections by connecting the cables numbered 1 to 5 on the Surveillance...
- Page 12 Processing Unit (LPU), which ensures data communication between the devices; Figure 11 - Connection diagram with the Surveillance Board (when 220 Vac Traffic Light) 34) Connect the power supply to the ITSCAMPRO NM1 system by connecting the cable numbered 1 (0.75 Pp 3-way cable) to the existing power grid.
- Page 13 Installation Guide ITSCAMPRO NM1 4.2. Connections to the Surveillance Board (Compact NM1 Switchboard) 35) Fasten the Compact NM1 Switchboard to the road structure (Poles, Road Signs and Sign Structures or Gantries); 36) Carry out the electrical connections by connecting the cables numbered 1 to 5 on the Surveillance...
- Page 14 Figure 12 - Connection diagram with the Surveillance Board on the Compact NM1 Switchboard (when 220 Vac Traffic Light) 37) Connect the power supply to the ITSCAMPRO NM1 system by connecting the cable numbered 1 (0.75 Pp 3-way cable) to the existing power grid.
- Page 15 Installation Guide ITSCAMPRO NM1 Figure 13 – Module Connections Diagram 39) Carry out the electrical connections of the Secondary Modules and Main Module with the Surveillance Board in the Tertiary Module Control Switchboard; 40) Carry out the data connections from the Secondary Modules and Main Module to the Switch on the Tertiary Module Control Switchboard;...
- Page 16 Installation Guide ITSCAMPRO NM1 Figure 14- Connections to the Main Module Device: 1) Ethernet cable; 2) 8-way sleeve cable ITSCAM terminal Signal Main Module Connection 1 (red) Power Supply: Positive Voltage: 12 or 24VDC 2 (brown) Power Supply: Ground 3 (green)
- Page 17 Installation Guide ITSCAMPRO NM1 Figure 15- Connections to the Secondary Module Device: 1) Ethernet cable; 2) 8-way sleeve cable ITSCAM terminal Signal Secondary Module Connection 1 (red) Power Supply: Positive Voltage: 12 or 24VDC 2 (brown) Power Supply: Ground 11 (orange)
- Page 18 44) Check that all equipment is energized; Access ITSCAMPRO NM1 installed; Register the devices of the Main and Secondary modules in ITSCAMPRO NM1; Set the violations that will be inspected at the monitoring point; Adjust image framing of the vehicle in each Secondary Module and the panoramic image in the Main Module.
