NEEWER QPro-F Manual

Trigger is designed for neewer speedlites to be compatible with fujifilm cameras
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Product overview
The QPro-F trigger is designed for NEEWER speedlites to be compatible with Fujifilm
cameras, when used in conjuction with speedlite flashes equipped with the NEEWER
Q wireless system. The QPro-F trigger features mult-channel control, stable signal
transmission, quick response, and a compact design. It is aimed at photographers
seeking flexible flash lighting control and adapts well to various shooting conditions.
Compatible with Fujifilm cameras with a hotshoe, it can also be connected to cameras
which have a PC port. Supports TTL flash and high speed sync (HSS).
Package contents
QPro-F flash trigger ×1
Product diagram
Flash Trigger Front
Group buttons Press
to select Double-press
to expand
Back button
(Back to previous)
Dial: Turn clockwise for +
Counterclockwise for -
Function buttons
(defined by UI)
Short-press
R ST
the menu button
Test button
Short-press to switch modes
Long-press for 3 seconds
to lock
01
Manual ×1
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QPro-F and is the answer not in the manual?

Questions and answers

Related Manuals for NEEWER QPro-F

Summary of Contents for NEEWER QPro-F

  • Page 1 Product overview The QPro-F trigger is designed for NEEWER speedlites to be compatible with Fujifilm cameras, when used in conjuction with speedlite flashes equipped with the NEEWER Q wireless system. The QPro-F trigger features mult-channel control, stable signal transmission, quick response, and a compact design. It is aimed at photographers seeking flexible flash lighting control and adapts well to various shooting conditions.

  • Page 2: Product Diagram

    Product diagram Battery compartment USB Type-C firmware (back) upgrade port 2.5mm sync jack Autofocus-assist beam switch Autofocus-assist beam Power switch Hot shoe Hot shoe quick lock LCD Display ② ③ ④ ⑤ ① ⑥ ⑦ ⑧ 1/ 128+0.3 +0.3 +0.3 1/ 128+0.3 1/ 128+0.3 ⑨...
  • Page 3 Product diagram A TTL 1/ 128+0.3 +0.3 + 3.0 +0.3 1/ 128+0.3 1/ 128+0.3 Zoom Zm/CH Zm/CH Multiple Group Display Single Group Display Zoom AUTO STBY Zoom BEEP Zoom LIGHT Zoom SYNC Zoom Ver:XX.X Zm/CH CLEAR Menu Display Multiple Group Zoom Display...

  • Page 4: Battery Installation

    Set-Up Battery Installation Slide open the battery compartment cover on the back of the flash trigger and insert 2 AA batteries (sold separately), ensuring that the positive and negative polarity markings are respected. Battery Level Remaining battery level indicator shown on LCD display during use. LCD screen battery indicator Indicates 4 bars...

  • Page 5: Turning On/Off

    Set-Up ② Slide the trigger's base into your camera hot shoe as shown in the figure. ③ After mounting on your camera, ④ Turn the hot shoe quick lock turn the hot shoe quick release clockwise to the unlocked lock counterclockwise to the position and slide the hot shoe locked position to use.
  • Page 6 4. Press your camera shutter to trigger the Z2 flash, and the trigger's "Status Indicator" will flash red. ※ After ensuring that the on-camera flash's channels <CH> and wireless <ID> match those of the QPRO-F trigger, the trigger can fire the flash. Wirelessly trigger a Fujifilm on-camera Speedlite flash There follows an illustration to show how to connect an EF-X500 flash with the trigger:...
  • Page 7 3. Place the original Fujifilm flash on the QR receiver, then press and hold the <M> button to set the same channel and ID on the QPro-F trigger. 4. Turn on the Fujifilm flash and set it to on-camera flash mode (Note: please refer to the manual of your Fujifilm flash about this setting).
  • Page 8 4. Press the camera shutter to activate the flash. The "status indicator" of the flash unit will flash red. ※ When the <CH> channel setting and the <ID> setting are the same for both the external flash and the QPRO-F, the QPRO-F can control the external flash. Wirelessly triggered camera shutter How to connect:...
  • Page 9 How to Use the Trigger 3. Set the Qpro-F transmitter and the receiver on the same channel and under the same wireless ID. Long press <Zm/CH> button to change channel. Short press <MENU> and choose <ID> to set wireless ID. (To set mode and other settings, please check the "Trigger Settings"...

  • Page 10: Trigger Settings

    Trigger Settings Trigger Settings Auto Sleep Mode 1. If no operation is performed within 90 seconds, the STBY trigger will automatically enter standby mode and the LCD display will go dark. BEEP 2. Press the < > button to activate the trigger system. LIGHT When mounted on a Fujifilm...

  • Page 11: Mode Setting

    Trigger Settings Wireless ID Setting In addition to pairing transmission channels, it is also possible to match the wireless ID to avoid signal interference. A TX unit and a RX unit have to be on the SHOOT same channel and set to the same wireless ID to trigger. DIST Press <MENU>...
  • Page 12 Trigger Settings Group Highlighting Highlight multiple groups or one single group: in multiple group setting, choose a group and press its group letter twice to highlight this group and change +3.0 settings for this single group. ※ Press the Back button to exit group highlighting page. Zoom Zm/CH Set Flash Output...
  • Page 13 The flash output is the sum of the two FEC values. (For example, the FEC value of Qpro-F is -2, and the FEC value of the speedlite is +3, then the total flash output is +1.) Multi Flash Setting (Flash Output,...
  • Page 14 NOTE: The strobe models that support the turning +0.3 on/off of the modelling lamp in one, single group 1/128+0.3 include the Z2, Q200, S101 PRO series. The future NEEWER flash strobes that feature a modelling lamp 1/128+0.3 will all support this function. Zm/CH...

  • Page 15: Zoom Setting

    Trigger Settings Zoom Setting Short press the <Zm/CH> button until the display shows AUTO Zoom the Zoom value. Select a particular group, then rotate Zoom the dial to change its Zoom value from AUTO, 18 to 133. After setting the value required, press the < >...

  • Page 16: Restore Factory Settings

    Trigger Settings Sync Port Setting 1. Press the <MENU> button to enter C.Fn SYNC page, STBY rotate the dial to choose <SYNC>, then, press the <SET> button. You can now rotate the dial to BEEP choose "IN" or "OUT". Short press the <MENU> LIGHT button to return to the menu page.
  • Page 17 Trigger Settings C.Fn: Set Custom Functions The different custom functions of this product are categorised below. Please check the table to change the settings as required. Settings Custom functions Functions Settings and meanings symbol symbol Sleep STBY ON/OFF Enable/disable Buzzer BEEP ON/OFF Enable/disable...

  • Page 18: Compatible Flash Models

    Compatible models 1. Compatible flash models Compatible with NEEWER 2.4G flashes with built-in Q wireless control system, including Z2-F、 S101-300W Pro、 Q4、 Q6、 Q200、 S101-400W Pro、 S102-400W Pro、 QR(off camera trigger), and later flash models with built-in Q wireless control.
  • Page 19 Causes for misfires and solutions 1. External environment 2.4GHz signal interference (such as wireless base station, 2.4GHz Wi-Fi router, Bluetooth device, and others)— Please adjust the channel ("CH") settings of the flash trigger (recommended +10), find a channel without interference, or turn off other 2.4GHz devices while using this product.

  • Page 20: Specifications

    Specifications Model QPro-F Built-in Wireless 2.4GHz frequency System Modulation Mode Channels 01-99 Wireless ID A, B, C, D, E (5 groups) Group TTL Autoflash Power Supply 2 AA batteries Manual/ Stroboscopic Flash High-speed/ Second-curtain sync Exposure compensation Focus Assist Modeling Lamp The modeling lamp of the flash is controlled by the trigger...
