Roger RLK-1 Operating Manual

RLK-1 Operating Manual Rev. A.docx
P
URPOSE
The RLK-1 network license key is used when licensed versions of Roger software (VISO, RCP
Master) are used. Communication with the RLK-1 key is encrypted using the AES128b CBC EtM
method. The configuration of the computer network in which the key works and the License Server
must ensure the possibility of communication via the TCP/IP protocol. RLK-1 is typically used when
installing licensed software on virtual machines.
Note: The RLK-1 is supported starting from VISO v2.0.8 or RCP Master v4.0.10.
I
NSTALLATION
1. Connect the RLK-1 to power and Ethernet.
2. In your web browser, enter http://rlk1 or the default IP address 192.168.0.240.
3. Select Configuration at the top of the screen and configure parameters such as IP address, port,
etc.
4. Download and install the RogerSVC software package from www.roger.pl.
5. During the installation, select the License Server component and, depending on the given
system's requirements, other components of the package.
6. Start RogerSVC and click its icon in the Windows tray.
7. In the opened window, select the License service tile and configure the settings for the RLK-1
key by entering the address and port.
8. In the main window, select Load license file and indicate the previously ordered license file.
9. In the case of a multi-user system, additionally configure the IP address and port of the License
Server itself so that it can be accessed by all workstations in the network.
10. Select the Start or Restart command.
D S
EVICE ETTINGS
The configuration of the hardware license key is performed via a web browser and includes the
following settings:
Network Section Parameters
• Host Name: individual key name in the computer network
• DHCP: the option enables support for dynamic address allocation protocol
• IP Address: network address of the device
• Net Mask: network mask of the device
• Default Gateway: The gateway address of the device
License Server Section Parameters
• License Port: License Server port (RogerSVC)
• Enabled Client IP: IP address of the License Server (RogerSVC)
Web Section Parameters
• User Name: user login for logging in via the browser
• Web Port: port for logging in via the browser
• Web Password: the user's password for logging in via the browser
• Disable Web: the option disables logging in via a web browser
Roger Access Control System
Network License Key RLK-1
Operating Manual
Product hardware version: v1.0
Firmware version: v1.0.0.13
Document version: Rev. A
2023-09-01
1/4
