Ryobi STM200K Operator's Manual

STM200K
3 4
OPERATOR'S MANUAL
QUICK RELEASE HANDLE PINS
For use with RYOBI STM201
rolling tool box.
The quick release handle pins allow
the user to quickly remove the
telescoping handle from the tool
box. To install the quick release
handle pins:
(1) Loosen and remove the two
T25 bolts securing the telescoping
handle on the back of the tool box.
(2) Install quick release handle pins
2
into the holes where the bolts were
removed.
1
(3) To remove the telescoping
handle, remove the quick release
handle pins. Pull telescoping handle
up and out of tool box.
(4) To r e a s s e m b l e , s l i d e t h e
telescoping handle into the box
and reinstall quick release handle
pins.
NE VE R roll toolbox wit hout
handle secured by bolts or pins
installed in handle.
