Gas Convection Oven CNCGD
For Your Safety
Do NOT store or use gasoline or
other flammable vapors and liquids
in the vicinity of this, or any other
appliance.
11990 Rivera Rd. Santa Fe Springs, CA 90670
Telephone:(714) 547-9218 (562) 464 - 9901
Installation, Operation &
Maintenance Instructions
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read the installation, operation and maintenance
instructions thoroughly before installing or servicing this
equipment.
www.connertoncooking.com
Warning!
Advertisement
Table of Contents
Summary of Contents for Connerton CNCGD Series
- Page 1 Installation, Operation & Maintenance Instructions Gas Convection Oven CNCGD For Your Safety Warning! Improper installation, adjustment, alteration, service or Do NOT store or use gasoline or maintenance can cause property damage, injury or death. other flammable vapors and liquids Read the installation, operation and maintenance in the vicinity of this, or any other instructions thoroughly before installing or servicing this appliance.
- Page 2 Thank you for purchasing and using our product. All the information and guidelines in this user’s manual come from our long-term accumulated knowledge and experience in product design and development and compliance with applicable regulations. Limited to some special structures, additional specified items or new technology changes, the actual usage situation might be different from what is stated in this user’s manual.
- Page 3 Warning ◆ Any self-modification, wrong installation, adjustment or maintenance can lead to property loss or casualty. Please contact the manufacturer for any adjustment or maintenance, and have the work done by a trained & qualified person. ◆ For your safety, please keep the machine away from any liquid, gas or other object which is flammable or explosive.
-
Page 4: Table Of Contents
CONTENTS 1. Functional Introduction…………………………………………………….5 2. Structure Schematic Diagram…………………………………………….5 3. Basic Features & Parameters……………………………………………..7 4. Precautions & Recommendations………………………………………..8 5. Working Instructions & Operation Flow………………………………...11 6. Control Panel Functions……………………………………………….…12 7. Controller Module…………………………………………………………13 8. Oven Operating Instructions……………………………………………..13 9. Preset Recipes and their Parameters…………………………………..14 10. -
Page 5: Functional Introduction
1. Functional Introduction Sturdy steel structure with 4 legs that can be adjusted in height. Equipped with built-in convection fan(s), ensuring the temperature uniformity in the chamber. Also, provided with an automatic ignition system in the case of flameout, and a shutdown device which will stop igniting the burner(s) after 3 attempts, so as to guarantee the safe use of gas. - Page 6 CNCGD-100 Gas Convection Oven...
-
Page 7: Basic Features & Parameters
CNCGD-200 Gas Convection Oven 3. Basic Features & Parameters CNCGD-100 CNCGD-200 Model Parameters Gas Convection Oven Gas Convection Oven Dimension（Inches） 39 x 42 x 57 77 x 84 x 63 Rated Power（BTU） 54000 108000 LP(Propane) 10’’ 10’’ 10’’ Gas type 4’’... -
Page 8: Precautions & Recommendations
4. Precautions & Recommendations Installation Before beginning the installation, remove the packaging. A few parts are protected with an adhesive film, which should be removed carefully. Remove any glue residual with the proper substances, such as petrol. Never use abrasive substances. Mount the unit feet. - Page 9 Running the appliance on other types of gas To change over to another type of gas, for example from methane to liquid propane, use the correct type of orifice for the burner in accordance to the “Burners” table. The burner orifices for different types of gas, marked in 10,000ths of an inch, are in a case supplied with the appliance.
- Page 10 All pipe joints and connections must be tested thoroughly for gas leaks. Use only soapy water for testing on all gases. Never use an open flame to check for gas leaks. All connections must be checked for leaks after the unit has been put into operation. 4.3 Electrical Connection 1.
-
Page 11: Working Instructions & Operation Flow
4.5 Warnings 1. Always supervise the appliance while being used and never let it run while empty. 2. The appliances do not require special adjustment assistance from specialized personnel if the adjustments are carried out by the user during the use of the appliance. 3. -
Page 12: Control Panel Functions
LCD Display Time and Temperature Button Oven Interior light button: Press to turn on light. Selector Knob: Turn to adjust and press to select Fan Speed Button: Use to select Preset Recipes Button: fan speed ( High (H) Low (L). The Press select preset... -
Page 13: Controller Module
Controller Module Light Button Time & Temperature Editing Button Selector Knob – Turn to adjust and press to select Fan Speed Button Preset Recipes Button Oven Operating Instructions 1. Turn the oven on by pressing the POWER Switch. 2. After “rEAdy” is displayed, press the Time and Temperature Editing Button. “PrH”... -
Page 14: Preset Recipes And Their Parameters
13. Once the cooking has completed, the system will beep while displaying “End”, waiting for the operator to press the Selector Knob to end or to start the hold process, if the “Hold” option was selected. IMPORTANT: Pressing and holding the Selector Knob will cancel the operation. IMPORTANT: To cool the oven, the doors can be opened and the COOK/COOL Switch set to COOL. -
Page 15: Electrical Diagram
Electrical Diagram 7. Cleaning & Maintenance Before cleaning, switch off the unit and let it cool down. Carefully clean daily the appliance to guarantee its proper operation and long life. Steel surfaces must be cleaned with a dish washer detergent diluted in hot water by using a soft cloth. - Page 16 If the appliance is not used for long period of time, please clean the equipment and the surrounding areas properly. Pour a small quantity of cooking oil on the stainless steel surfaces. Carry out all maintenance operations. Cover all appliances with a suitable material and leave a few openings to allow air to circulate.
-
Page 17: Gas Convection Oven Components
Gas Convection Oven Components For Control Panel Assembly and its Components details, see page 20. -
Page 18: Gas Convection Oven Parts List
Gas Convection Oven Parts List Item Number Part Number Description FGC100-16-00 REAR FLUE ASSEMBLY FGC100-15-00 TOP COVER ASSEMBLY FGC100-00-01 LEFT SIDE PANEL 302110578 RACK FGC100-00-07 RACK HOLDER FGC100-30-00 CONVECTION/HOT AIR COMPARTMENT ASSEMBLY FGC100-47-00 DOOR STOPPER ASSEMBLY FGC100-40-03 DOOR SHAFT BUSHING FGC100-42-00 LEFT DOOR ASSEMBLY FGC100-41-00... - Page 19 Gas Convection Oven Parts List (Cont.) Item Number Part Number Description FGC100-62-01 MANIFOLD 301080079 TRAVEL SWITCH 302150212 ORIFICE, NATURAL GAS 302150169 ORIFICE, LIQUID PROPANE 301130140 INDICATOR LIGHT 301130151 LAMP FGC100-00-02 RIGHT SIDE PANEL 302220079 VALVE 302060152 ELBOW 302060040 CONNECTOR 302060046 CONNECTOR 302050076 BALL VALVE...
-
Page 20: Control Panel Assembly & Components
Control Panel Assembly & Components Item Number Part Number Description GGC100-102 CONTROL PANEL ASSEMBLY 301150304 IGNITION CONTROLLER SPM-634 TERMINAL BLOCK 301100149 TRANSFORMER HMC-12 MICROCONTROLLER + BUZZER UCM-203 CONTROLLER MODULE UCM-203-KNOB CONTROLLER KNOB... - Page 21 Effective January 2020 CONNERTON (Company) warrants to the original owner that the product be free from defects in materials and/or workmanship. This warranty shall apply to units properly installed in a static location only and be in effect for two (2) years from the date of purchase but shall not exceed 30 months from the date of shipment from the Company.
- Page 22 PARTICULAR PURPOSE. Non-Commercial Warranty Restriction CONNERTON Appliances are only fully warranted for COMMERCIAL USE. When installed and/or used in other applications, such as but not limited to Residential / Household applications, the warranty covers parts only, for 1 (one) year from the original...
