RAB MSR1 Instructions

INSTRUCTIONS
MSR1 REMOTE
RAB Lighting is committed to creating high-quality, a ordable, well-designed and energy-e cient LED lighting and controls that make it easy for electricians to install
and end users to save energy. We'd love to hear your comments. Please call the Marketing Department at 888-RAB-1000 or email: marketing@rablighting.com
Buttons
1.Turn on or o light
2.Exit sensor mode and enter into ON/OFF mode.
ON/OFF
Press the button to enter into factory settings, means sensor starts to detect
Reset Reset
motion and turn on light automatically and only keep 5S holdtime
then turn o the light.
Press the button to start programming; the S icon will appear on the
LCD screen, and disappear if no action within 10S, need to press it again.
Reset Start
Press the button to deliver the saved parameters to target sensors.
Apply
Press the button to deliver the last parameters, instead of
"START-MEMORY-APPLY"
Send
Press the button, the icon will flick on LCD screen display, then use +/-
buttons to choose the wanted daylight level; the max level is 400lux, ---
means diasble, LEN means learning ambient brightness.
Press the button, the icon will flick on LCD screen display, then use +/-
buttons to choose the wanted holdtime.
Press the button, the icon will flick on LCD screen display, then use +/-
buttons to choose the wanted standby period; the min is 0S,
the max is infinite.
Press the button, numbers on LCD screen display gets lower till the
-
wanted one appears.
Make parameters according to daylight harvesting conditions, then press
this button to activate this function; DH-ON will show on LCD screen display.
Description
100 188
% %
K 8888 88
S
k m
A M
88
DH- ON
%
OFF
SC- SK- 88 S
0 1 0 1
m
P
H ---
S M
lux
ON/OFF Auto Reset
Scenes Start Memory
Apply M H Send
Mounting Height
Detection range Daylight sensor Stand-by dimming
+
Hold time Stand-by period
-
CCT POWER
Test
Reserved Daylight Harvesting
LCD Screen Display IR Remote Contro
Model:MSR1
Buttons
Press this button, enter into sensor mode and perform the last parameter,
press this button and Auto Mode will show on LCD screen display,
Auto
means commands received successfully.
Press the button to enter into factory settings, means sensor starts to detect
motion and turn on light automatically and only keep 5S holdtime
Scenes
then turn o the light.
Press the button to save the parameters, the M icon will appear on the
LCD screen, means parameters saved succesfully.
Memory
Press the button to relatively adjust sensitivity from the sensor according to
real Pinstallation height, make sensors working more perfectly
M H
in the environment.
Press the button, the icon will flick on LCD screen display, then use +/-
buttons to choose the wanted parameters.
Press the button, the icon will flick on LCD screen display, then use +/-
buttons to choose the wanted standby dim level.
Press the button, numbers on LCD screen display gets higher till the
wanted one appears.
+
(Only supporting sensors with CCT tunable feature)
Press the button, then icon will flick on LCD screen display, then use +/-
CCT
buttons to choose from the saved CCT options
This is a reserved button for future updates with unexpected feature.
Press the button to quickly perform testing function, keep only 2S ON
then OFF, till motion gets detected and turn on light again.
Test
Description
