CSP SERIES STOCK POT STOVES
For Your Safety
Do NOT store or use gasoline or other
flammable vapors and liquids in the
vicinity of this, or any other
equipment.
11990 Rivera Rd. Santa Fe Springs, CA 90670
Telephone: : (714) 547-9218 (562) 464 - 9901
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read the installation, operation and maintenance instructions
thoroughly before installing or servicing this equipment.
www.connertoncooking.com
Installation,
Operation &
Maintenance
Instructions
Warning!
Advertisement
Summary of Contents for Connerton CSP Series
- Page 1 Installation, Operation & Maintenance Instructions CSP SERIES STOCK POT STOVES For Your Safety Warning! Do NOT store or use gasoline or other Improper installation, adjustment, alteration, service or flammable vapors and liquids in the maintenance can cause property damage, injury or death.
- Page 2 To Purchaser After installation of your stove, immediately contact your local gas supplier to obtain information in the event the user of your equipment smells gas. This information must be posted in a prominent location. To User RETAIN THIS MANUAL FOR FUTURE USE Upon receipt of this stove, inspect it thoroughly for any damage which may have occurred during shipment.
-
Page 3: Care And Maintenance
Gas Piping: Make sure the gas pressure regulator supplied with the stove is installed correctly. Connect outlet side of regulator to stove. The regulator is set at 4 inches w.c. on natural gas and 11 inches w.c. on propane gas. A 1/8” pressure tap is provided on the gas manifold at the front of the stove for checking the gas pressure. - Page 4 CSP STOCK POT STOVES 40-350-01 Pilot w/tubing – inner ring 40-100-DS top grate 40-400-DS body 40-350-02 pilot stem & tip 40-425-DS front panel 00-225-00 pilot valve (straight) 40-450-DS drip pan 00-250-00 manual gas valve 40-300-00 gas manifold pipe 00-500-00 chrome knob 40-150-00 3 ring burner (complete) 13a 15-251-02 **brushed s/s knob...
-
Page 5: Troubleshooting Guide
Effective January 2020 CONNERTON (Company) warrants to the original owner that the product be free from defects in materials and/or workmanship. This warranty shall apply to units properly installed in a static location only and be in effect for two (2) years from the date of purchase but shall not exceed 30 months from the date of shipment from the Company. - Page 6 The use of only authorized servicers for needed repairs. PROCEEDURES FOR REQUESTING WARRANTY SERVICE All services must be prearranged by the Company prior to works being performed. Contact CONNERTON service department at (714)-547-9218 furnish complete model and serial numbers and a copy of the purchase invoice and describe nature of the problem.
