LDU21C Closed Circuit Axial Piston Transmission
General Description
Schematic Diagram
MB1
MA1
*L1, L2, L3 and L4 are (Case) Drain ports.
*E1 and E2 are Charge Inlet ports.
©
Danfoss | April 2025
Customer should
provide external
charge circuit.
L1
E1
L2
L3
E2
MB2
MA2
L4
P400548
AX342138485422en-000102 | 9
