Summary of Contents for Datron WNCJC76AB
- Page 2 INSTRUCTION MANUAL Compressor Wine Cooler 22 Bottles MODEL: WNCJC76AB WNCJC76AW Please read carefully and follow all safety rules and operating instructions...
-
Page 3: Table Of Contents
Content 1. Your Wine Cooler…………………………………………………………………………………………3 2. Technical Data……………………………………………………………………………………………3 3. Safety Precautions…….……………………………………………………………………………………4 4. Important Precautions……………….……………………………………………………………………5 5. Installation Instructions………………………………………………………………………………….6 6. Operating Your Wine Cooler………………………………….…………………………………………..7 7. Care and Maintenance………………………………………………………………………………….8 8. Trouble Shootings………………………………………………………………………………………….9 - 2 -... -
Page 4: Your Wine Cooler
Your Wine Cooler Technical Data Model No. WNCJC76A WNCJC76AW Capacity Voltage 220-240V 220-240V Rated Current 0.8A 0.8A Frequency 50Hz 50Hz Protection Class Climate Class T/ST/N/SN T/ST/N/SN Input Power Power Consumption (KW.h/24h) 0.41 KW.h/24h 0.41 KW.h/24h Temperature Control Range 5~18°C 5~18°C Refrigerant R600a R600a... -
Page 5: Electrical Circuit Diagram
Electrical Circuit Diagram Safety Precautions To reduce the risk of fire, electrical shock, or injury when using your appliance, follows these basic precautions; PLEASE READ all instructions before installing, operating, or servicing the appliance. Danger and Warning: Failure to follow this safety statement will result in severe personal injury or death, ... -
Page 6: Important Precautions
Important Precautions Do not lift unit by door handle. Do keep the door closed before installing into cabinet. Be sure the kick-plate on the front bottom is free from obstruction. Obstructing free airflow can cause the unit to ... -
Page 7: Installation Instructions
Installation Instructions Before using your wine cooler: Remove the exterior and interior packing Before connecting the appliance to the power outlet, let it stand upright for approximately 2 hours. This will reduce the possibility of malfunction in the cooling system from handling during transportation. Clean the interior surface with lukewarm water using a soft cloth. -
Page 8: Operating Your Wine Cooler
Operating Your Wine Cooler The Control Panel: ANTI-CONDENSATOIN: Touch it and the icon light will light up to turn on the anti-condensation function of glass; Touch it again and the icon light will go out and the anti-condensation function is off. When it is off, the icon light keeps going out LIGHT: Once touched, the icon light will light up and the LED light inside the cabinet will be turned on;... -
Page 9: Care And Maintenance
Care And Maintenance Cleaning your wine cooler Unplug the wine cooler and remove the bottles. Wash the inside with warm water or baking soda solution. The solution should be about 2 tablespoons of baking soda to a quart of water. The outside of wine cooler should be cleaned with mild detergent or warm water. -
Page 10: Trouble Shootings
Trouble Shootings You can solve many common wine cooler problems easily, saving you the cost of a possible service call. Try the suggestion below to see if you can solve the problem before calling the service center. PROBLEM POSSIBLE CAUSE Wine cooler do not operate. - Page 11 B.03.021...
