Avtek TouchScreen Pro4K

series interactive monitor

User Manual

Before working with the device, please read this manual carefully and keep it for future reference.

Table of Contents

Need help?

Do you have a question about the Pro4K and is the answer not in the manual?

Questions and answers

Summary of Contents for Avtek Pro4K

Page 1 Avtek TouchScreen Pro4K series interactive monitor User Manual Before working with the device, please read this manual carefully and keep it for future reference.
Page 2 Warnings Before working with the device, please read this manual carefully and keep it for future reference. Placing • Do not place the device on unstable carts, bases, stands, tables or shelves. • Do not expose the device to direct sunlight or other heat sources. •...
Page 3: Table Of Contents
Table of contents Installation............................3 1. Package contents.........................3 2. Control panel ........................4 3. Terminal interface.......................5 4. Wireless remote control ......................6 Connection and settings........................9 1. Connecting an external computer and touch function............9 2. AV connector........................10 3. HDMI connector........................10 4. Coaxial connector........................11 5.
Page 4: Installation
Installation Contents package Quick reference Pens Batteries Wireless remote control guide Power cable VGA cable USB cable Headphone cable HDMI cable AV cable...
Page 5 Panel control panel Position Functional description Touch to activate the power saving function. Press for at least 2 seconds to acctivate standby mode. Button to return to the home screen. Button to return to the previous menu screen. Menu call button. A button to reduce the volume of sound.
Page 6 Interface terminal Position Functional description HDMI OUT Output connector for High Definition Multimedia Interface. For connecting devices such as portable hard drive, mouse, keyboard, flash drive, etc. HDMI IN Input connector for High Definition Multimedia Interface. A connector that communicates the touch signal with an external computer. TOUCH DisplayPort input connector AUDIO IN...
Page 7 Maintenance Troubleshooting Menu Connection and settings Installation operation...
Page 8 Description of the operation of the wireless remote control buttons Turn the screen power on and off. Mute/enable sound. Windows function key for internal PC. Space bar for programs running on the internal PC. Window switch for programs running on the internal PC. Space Key to close the window of programs running on the internal PC.
Page 9 Instructions for using the wireless remote control Battery installation: 1. Remove the flap from the underside of the remote control. 2. Then insert two AAA batteries, with the correct setting: + batteries to + on the remote control, - to -. Do not mix batteries. 3.
Page 10: Connection And Settings
Connection and settings For safety reasons: please do not connect the power supply before setting up the external device. Connecting an external computer and touch function USB cable VGA cable audio cable computer Connect the VGA cable (15 pins) to the VGA connector and the external computer. Connect a 3.5mm minijack cable to the computer and audio input on the monitor.
Page 11 Connector AV Camera Video Game Decoder VIDEO Video recorder Satellite TV receiver VIDEO Connect the AV cable to the AV-OUT port on the external device (yellow - video, red - audio-r, white - audio-l). Connect the power cord and turn on the device. Press to turn on the power.
Page 12 Connector coaxial coaxial cable amplifier/stereo sound system Connect the coaxial cable to the input port of the external device. Connect the power cord and turn on the device. Press to turn on the power. Connector VGA projector HDMI IN audio cable HDMI cable Use a VGA cable to connect the projection device to the VGA OUT connector.
Page 13 Connector LAN Network Cable Internet Connector RS232 RS232 connection cable serial computer When the monitor is connected to an external computer using a serial cable, the following screen functions can be controlled from the computer: turning the monitor on/off, adjusting the volume, etc.
Page 14: Support Menu
Support menu Touch menu operation Calling method Swipe up on the screen with your finger or pointer, starting from the center of the screen, just above the bottom frame. Settings menu Input settings • Press INPUT on the wireless remote control or on the touch-call OSD menu to call up the input setting menu.
Page 15: Brightness Settings
Brightness settings • Press INPUT on the wireless remote control or on the touch-call OSD menu to call up the input setting menu. • Use the► key on the remote control or tap the corresponding icon on the screen to select the brightness setting menu.
Page 16: Image Settings
Image settings During an active connection (other than with Android): • Press INPUT on the wireless remote control or use the touch method to call up the menu. • Use the► key on the remote control or tap " " on the screen to enable the advanced settings window.
Page 17: Troubleshooting
Troubleshooting The device is not working properly Check that the space between the remote control and the TV receiver is not occupied by an object. Check that the batteries in the remote control are inserted correctly. Remote control Check that the batteries in the remote control are in working order. doesn't work Check the sleep mode settings.
Page 18: Maintenance
Maintenance and cleaning Please stick to the following tips to maintain maximum monitor performance. Cleaning Unplug the device from the outlet before cleaning. Use only a soft, slightly damp cloth to clean the surface. Do not clean the screen with chemical cleaners. Do not directly apply cleaning agents to the surface of the device.
