Cafe BELLISSIMO C7CESAS3RD3 Owner's Manual page 16

Care and Cleaning
Cleaning the Grinder
1. Make sure the unit is off.
2. Remove the bean hopper by rotating counterclockwise to unlock from the
machine (figure 1).
3. Empty all beans from the bean hopper.
4. Scoop out any loose coffee beans from the burr grinder.
5. Replace the empty bean hopper back on the machine, twist clockwise
to lock.
6. Be sure to place a cup or container under the grinder when completing this
next process to collect loose grounds of coffee.
7. Place grind setting to the "Fine" (0) and then Turn the machine ON by
pressing the Power button.
8. Press the "Grind" button until there are no beans left in the machine.
9. After grinding is done, remove the bean hopper just like step 2.
10. Remove the upper burr by pulling the wire arm up and twisting
counterclockwise.
Use a stiff bristled brush to clean the upper and lower burrs.
11. Use the same brush to clean the grind outlet.
12. Place the upper burr and bean hopper back on by locking it in place,
clockwise (figure 3).
13. Grinder is ready for use.
Note: The burrs and bean hopper are not dishwasher safe.
Cleaning the Steam Wand
To clean the steam wand, remove the tip by unscrewing. Use the cleaning pin
provided to clear the tip of any debris.
Cleaning the Portafilter and Filters
To clean the portafilter and filters, dispose of coffee grounds then rinse with
water. Allow the portafilter and filters to dry completely before using again.
System Emptying
The System Emptying process empties the system of all water. Use this
function when storing the machine for long periods.
■ Empty the water tank.
■ Press and hold the Power and Double button together for 3 seconds to put the machine into
system emptying mode.
■ The machine will beep once and Power and Double will flash to confirm the action.
■ The system will empty water into the drip tray and return to idle when complete.
Checking Your Water Hardness
Included with the machine is a Water Hardness Test Kit. Please follow the instructions on the
package using the same water that will be used to make espresso. Once results are gathered,
please refer to the SmartHQ app to set the water hardness level.
16
Figure 1
Figure 2
Figure 3
