INSTRUCTIONS

INSTALLATION / USE / CARE / MAINTENANCE /

SAFETY ADVICE

AUTOMATIC SAFETY COVER

ABOVE GROUND MODEL

SVELTÉA

NF P 90-308

compliant manufacturing

Read carefully and keep for future reference

FLUIDRA INDUSTRY FRANCE

Series number

105 Rue Henry Potez

66000 Perpignan - FRANCE

Tel : 04.68.61.75.30

Revision index : A-01-2021

Table of Contents

Need help?

Do you have a question about the SVELTEA and is the answer not in the manual?

Questions and answers

Summary of Contents for fluidra SVELTEA

Page 1 SAFETY ADVICE AUTOMATIC SAFETY COVER ABOVE GROUND MODEL SVELTÉA NF P 90-308 compliant manufacturing Read carefully and keep for future reference FLUIDRA INDUSTRY FRANCE Series number 105 Rue Henry Potez 66000 Perpignan - FRANCE Tel : 04.68.61.75.30 Revision index : A-01-2021...
Page 2 • This cover has been manufactured following accurate measurements taken and included on the purchase order delivered by Fluidra to the installer or retailer. • The total distance between the edge of the pool and the cover must be less than 70 mm.
Page 3: Necessary Tools
UNLOADING 30 mins 80cm 60cm ≈ 350kg for a 4 x 8m pool NECESSARY TOOLS Ø 5 Ø 8 Ø 10 10 m N°3 N°4 N°5 17 mm ELEMENTS RECEIVED Revision index : A-01-2021...
Page 4 PREPARATION OF POOL SQUARING The edges of the pool must be parallel in order to prevent the cover rubbing. (Sauf forme particulière du bassin compatible avec une couverture automatique). Run a conduit from the machine CABLE CONDUIT room to the pool in order to provide the power supply to the roller.
Page 5 CUTTING OF POOL COPING ROUNDED POOL COPING 23 cm 11 cm PROJECTING POOL COPING Cut the coping so that the cover can fit through it. < 4 < 5 < 6 < 8 < 10 (cm) Revision index : A-01-2021...
Page 6 DÉMONTER LE CAPOT N°4 Disassemble the printed circuit board’s protection plate. CABLE DUCT SHEATH Revision index : A-01-2021...
Page 7 ASSEMBLY MOTOR SIDE Feed the cable through the hole Insert the motor's cable as far as it will go into the stand to prevent all contact with the slats or the shaft. ASSEMBLY BEARING SIDE Rest on 4 rollers. 2,5cm max Revision index : A-01-2021...
Page 8 POSITIONING L+14cm Place the roller perpendicular to the lengths of the pool shell by measuring the diagonals. Revision index : A-01-2021...
Page 9 CONTROLS 906377 If necessary, adjust the level with the help of the accordion spacers supplied. FASTENING 17 mm Ø10 14,5 cm 6 cm Revision index : A-01-2021...
Page 10 CONNECTING OF SLATS • The straps must be attached when the limit switches are being set. • The slats should go down from the front of the roller. • If there are skimmers along the length of the pool we would advise you to replace the flanges provided with 2mm stainless steel flanges to prevent the slats becoming blocked.
Page 11 SLAT CONNECTION STEPS Do not perforate the slat Adjust the notch to the width ≈ 1,5cm of the cap. Revision index : A-01-2021...
Page 12 CONNECTIONS • Electric installation must be carried out to comply with current standards, in particular NF C 15-100. • The power supply unit must be installed at least 3.5 meters away from the pool in a dry, well- ventilated machine room, protected from bad weather and out of the sun. •...
Page 13: Limit Switches Adjustment
LIMIT SWITCHES ADJUSTMENT STOP Turn the key to the motor’s stop position The straps must not be attached to shaft. through the limit switches. Configuration A Configuration B STOP STOP Pre-set the limit-switches to stop the motor just before the cover has been completely rolled Fine tune the limit switches to complete rolling process.
Page 14 POSITIONING AROUND THE POOL The safety straps are positioned on the cover in accordance with the instructions stipulated on the purchase order. It is the responsibility of the installer or the retailer to provide accurate measurements of the pool and the position of the skimmers. 1 bracket in the centre ≤...
Page 15 PLASTIC BRACKET AND CLOTH STRAP ON WALL Kit : 070316 Brackets locked Strap taut Ø8 N°5 ON FLAT Full kit: Ø10 070335 N°4 N°3 Make a groove on the bottom of the coping stone 7 – 12 cm 12 – 16 cm Revision index : A-01-2021...
Page 16 STAINLESS STEEL BRACKET ON WALL Kit : 070544 Brackets locked Strap taut Ø8 ON FLAT N°5 Ø10 Full kit: 070545 N°4 N°3 Make a groove on the bottom of the coping stone 7 – 12 cm 12 – 16 cm FASTENING Revision index : A-01-2021...
Page 17 ABS BRACKETS ON WALL Brackets locked Strap taut Kit : 060525 Ø8 ON FLAT N°5 Ø10 Full kit: 060721 Make a groove on the bottom of the coping stone N°4 Revision index : A-01-2021...
Page 18 PRESENTATION APP + WALL-MOUNTED REMOTE CONTROL Up to two wall-mounted remote controls can be paired to a receiver In compliance with standard NF P 90-308: The distance between a mobile device and the wall- mounted remote control is restricted. Therefore, placing the remote control in the right place is critical to making optimum use of the app, in addition to complying with this safety standard.
Page 19 PRESENTATION KEYRING REMOTE CONTROL Up to two keychain remote controls can be paired to a receiver Radio receiver/Bluetooth built in to the stand. In compliance with standard NF P 90-308: If only the app is used, the distance between a mobile device and the cover’s stand is restricted.
Page 20 • The user must also fit the cover with a wired key control system to operate the cover if the paired terminal is unavailable. • FLUIDRA would like to point out that technology, the services available and applicable legislation are constantly changing. Therefore, the user is hereby informed that FLUIDRA may modify the content and features of the application and services in accordance with technical and/or legislative developments.
Page 21 PAIRING • Enable Bluetooth on your mobile device, switch the app on and follow the instructions. • Read and accept the general terms and conditions of use. • Pairing: • Press the “start” or “stop” button on the wall-mounted remote control. •...
Page 22: Password Recovery
THE WALL-MOUNTED REMOTE CONTROL’S BATTERY If this pictogram appears, change the battery in the Cover control remote control. (See p.27). PASSWORD RECOVERY Enter current password Factory password. Enter a 4-digit code Please check user manual. **** 1 1 1 1 Forgot your password? Recover it Cancel...
Page 23 COMPLIANCE WITH STANDARD NF P90-308 COMPLIANT WITH THE NF P90-308 STANDARD IF: • Security code enabled Distance limitation Secure code • Distance limitation enabled Distance limitaion Secure code Activated Activated Compliant with the NF P90-308 A distance limitation is applied between standard the phone and the remote control.
Page 24 FITTING THE REMOTE CONTROL 130mm Ø5 Install the remote control at a height lower than 2 m, with a direct view of the pool and less than 5 m away from it. 111mm PAIRING Radio receiver / Long press on CONNECT Bluetooth built in until it flashes to the stand.
Page 25 Continuous for 2 seconds if: UNLOCK code valid code invalid Unlock request Unlock code In case of error, wait 10 seconds or press 4 keys to return to step 1. OPEN/CLOSE After unlocking: Check receiver Press and hold: Press and hold: pool open pool close LOCK...
Page 26: Change Mode
OPEPRATING MODES CHANGE MODE Short press for 10 s to display the mode enabled (mode 1 by default) Remove the safety device to access mode 3 Mode 3 not compliant Press again to with NF P 90-308 change the mode MODE 1: KEEP OPEN/CLOSED Press and hold: Press and hold:...
Page 27: Change Lock Code
3.6V DC power supply in the form of a SAFT-make lithium battery, model LS14500. Fluidra code: 907676 Non-rechargeable. Do not use a 1.5V alkaline battery. •If the base is reconnected the wrong way In winter, remove the battery and...
Page 28 NOT COMPLIANT KEYRING REMOTE CONTROL WITH NF P 90-308 • The keyring remote control lets you open and close the automatic cover remotely. • Portée de la télécommande porte-clé pouvant varier en fonction de l’environnement. Remote control Radio frequency Radio receiver / Bluetooth built in to the stand.
Page 29 CHANGE MODE Short press for 10 s to display the mode Mode not compliant enabled (mode 1 by default) with NF P 90-308 Remove the safety device to access mode 3 Press again to change the mode MODE 1: KEEP OPEN/CLOSED Press and hold: open cover.
Page 30 • The person opening or closing the pool must keep a careful eye on the procedure throughout and ensure there is nobody in the pool. • It is essential to open or close the cover fully. Never leave it half-open. •...
Page 31: Water Properties
CARE Care of the automatic cover is the responsibility of the user. COVER AND ACCESSORIES • Check the slats regularly to ensure that they are correctly interlocked . • Check the state of the brackets and safety straps every time the cover is used. •...
Page 32 CARE • It is essential for the pH level of the water to be correct to avoid damage to the cover and its mechanism: Threshold Frequency to Parameter To increase To decrease values be checked 2.5~4 g/L Add salt and filter constantly for 24h, Partially empty the swimming every three Salt level...
Page 33 WINTERING • It is the responsibility of the installer/retailer to recommend the best way of leaving the pool over winter. This will depend on the availability of the user and the geographical location of the pool. WARNING: Never operate the cover if caught in ice or covered with snow. •...
Page 34: Maintenance
• The colour of slats replaced may not be exactly the same as those replaced. • Replacement of motor and power supply unit: • Replacement motors and power supply units must be Fluidra products and must be replaced by a qualified technician.
Page 35 GUARANTEES • The guarantee covering a faulty product is only valid after the faults have been confirmed on our premises or in situ by the installer/retailer on the basis of information from the FLUIDRA technical service. • Expenses arising from removal, re-installation and transport are not included in the guarantee (provision of water, chemical products, damages, interest, as well as any penalization demands).
Page 36 DISENGAGEMENT • The motor can be disengaged so that the cover an be unrolled manually and the pool made secure in the event that the motor breaks down or if there is a power cut. Unplug the motor cable. Attention : Risk of sudden acceleration when cover is being unrolled due to the effect of its weight.
Page 37: Remote Control
REMOTE CONTROL APP + WALL-MOUNTED REMOTE CONTROL Press on MODE. Does the LED* light up for 10 s? Is switch 1 on OFF? Check the stand’s wiring (see p.12). Does the wall-mounted remote control work? Is the remote control’s battery level Re-pair the mobile device high enough? (see...
Page 38 MOTOR Turn the key of the switch. Is the motor running? IN THE WRONG DIRECTION Switch cables 1 and 2 (MOTOR) around on the lever Turn the key in the other direction. Is the motor running? terminal block in the roller’s stand (see p.12).
Page 39 MOTOR Blue LED MODE MODE button VACVDC Ω 20A mA VΩ Radio receiver / Bluetooth built in to the stand. Thermal Tripped circuit breaker button VACVDC Fuse Ω 20A mA VΩ VACVDC Ω 20A mA VΩ Revision index : A-01-2021...
Page 40 PVC COVER Revision index : A-01-2021...
Page 41 POLYCARBONATE COVER Revision index : A-01-2021...
Page 42 CE CERTIFICATION Revision index : A-01-2021...
Page 43 VERIFICATION OF CONFORMITY In order to ascertain that the installation complies with NF P 90-308, please ensure that: ❑ It is possible to see all the pool during operation and to ensure there is nobody in the pool when the cover is being closed. ❑...
Page 44: Safety Advice
SAFETY ADVICE GENERAL SAFETY ADVICE WARNING: The pool may expose your children to significant risk. Drowning can occur very rapidly. Children near the pool require your constant vigilance and must be supervised at all times, even if they know how to swim. Learn what you can do to save lives.
