Page 1: Table Of Contents
USER MANUAL 36" 5-Burner Griddle Model: TDN-571-0101 CONTENTS Safety Warnings Package Contents Assembling Your Griddle Disassembling Your Griddle Using Your Griddle Cooking With Your Griddle Checking for Gas Leaks Purging Air / Resetting Regulator 20 Cleaning & Maintaining Your Griddle Frequently Asked Questions Specifications &...
Page 2: Safety Warnings
Free Help From the Griddle Experts Your Element griddle is designed for quick assembly and ease of use. If you have problems, DO NOT RETURN THIS GRIDDLE TO THE STORE. We’re experts on this product and are trained to help you with assembly questions, griddle operation, and replacement of damaged or missing parts.
Page 3 WARNINGS Before each use of your griddle, inspect An appliance is considered to be outdoors the grease cup and the inside of the griddle if installed with shelter no more inclusive bowl to be sure there is no excessive grease than within a partial enclosure that includes and debris buildup.
Page 4 SAFETY WARNINGS CAUTION Failure to comply with these instructions may result in a hazardous situation which may result in injury. Spiders and small insects can spin webs and nest in the grill burner tubes during transit and warehousing which can lead to a gas flow obstruction, resulting in a fire in and around the burner tubes.
Page 5 Element. Do not use your griddle as a heater. Contact Element Customer Support for This griddle is not intended to be installed in more information.
Page 6 SAFETY WARNINGS WARNING A. DO NOT store a spare propane gas tank under or near this appliance. B. NEVER fill the tank beyond 80 percent full. C. If the information in “(A)” and “(B)” are not followed exactly, a fire causing death or serious injury may occur.
Page 7: Package Contents
PACKAGE CONTENTS Remove your griddle from the packaging, and make sure that your griddle is not damaged and that you have all the parts. Gas Griddle Left Side Shelf Right Side Support Shelf Support Griddle Plate Center Shelf Grease Cup Gas Tank Bracket Trash Can Locking Casters...
Page 8: Assembling Your Griddle
ASSEMBLING YOUR GRIDDLE BEFORE ASSEMBLING YOUR GRIDDLE Make sure that you have assistance from another person to handle the griddle box and other large, heavy parts. Use the “Package Contents” on page 6 and “Specifications & Parts Diagram” on page 25 to ensure all items are included and free of damage.
Page 9 STEP 2 Expand the Cart Unfold the cart by expanding the cart bars and lock into place. STEP 3 Attach Casters Install four locking casters into each corner of the cart bottom by rotating into the socket. ELEMENTELECTRONICS.COM...
Page 10 ASSEMBLING YOUR GRIDDLE STEP 4 Install Center Shelf Insert shelf into position by aligning cutouts over screws and push into place. STEP 5 Mount Gas Tank Bracket Mount the gas tank bracket to the left side of the cart using two thumb screws. The gas tank bracket should face the outside of the cart.
Page 11 STEP 6 Install Burner Box A. Position the burner box next to the cart. B. Lock the caster wheels. C. With another person, lift the burner box onto the cart and align the four latches. Lock the four latches to secure the burner box to the cart. STEP 7 Install Side Shelf Supports A.
Page 12 ASSEMBLING YOUR GRIDDLE STEP 8 Install Grease Catch On the right side of the burner box, insert the grease catch into the burner box as shown. STEP 9 Install Trash Bin Install the collapsible trash bin onto the cart by sliding the locking holes onto the two bolts. 36"...
Page 13 STEP 10 Install Griddle Plate Fold the griddle lid out onto the shelf supports. The lid doubles as side shelves for your griddle. Install the griddle plate into the burner box as shown. STEP 11 Towel Holder Place a paper towel roll on the paper towel holder. ELEMENTELECTRONICS.COM...
Page 14: Disassembling Your Griddle
ASSEMBLING & DISASSEMBLING YOUR GRIDDLE STEP 12 Connect the Propane Tank A. From the side of the cart, place the foot ring of the tank into the gas tank bracket. B. Attach the hook ring to the lip of the propane tank. C.
Page 15: Using Your Griddle
USING YOUR GRIDDLE Before lighting or using your griddle, familiarize yourself with the safety guidelines at the front of this manual. See “Safety Warnings” on page 1. WARNING: Do not smoke while lighting the griddle or checking gas supply connections. LIGHTING YOUR GRIDDLE NOTE: If your griddle does not light properly, see "What Should I Do if My Griddle Won't Light?"...
Page 16 USING YOUR GRIDDLE Manually Lighting with a Match Insert a match into the manual lighting stick (included in the bag with this User Manual). 2. Make sure that your propane gas tank is filled. Make sure that the end of each burner tube is properly located over each valve orifice. 4.
Page 17 MONITORING FLAMES You can monitor flames from under and/or behind the griddle burner box. See images below. ELEMENTELECTRONICS.COM...
Page 18: Cooking With Your Griddle
COOKING WITH YOUR GRIDDLE WARNING: Your griddle will get very hot. NEVER lean over the cooking area while using your griddle. Do not touch cooking surfaces, griddle housing, lid, or any other parts while the griddle is in operation or until the griddle has cooled down after use. Failure to comply with these instructions may result in serious bodily injury.
Page 19: Checking For Gas Leaks
This purging procedure should be done every time a new propane gas tank is connected to your griddle. For help call the Element Customer Support at (888) 842-3577 for assistance. ELEMENTELECTRONICS.COM...
Page 20: Purging Air / Resetting Regulator
PURGING AIR / RESETTING REGULATOR PURGING AIR FROM THE GAS LINE/RESETTING THE REGULATOR Turn the control knob OFF. 2. Turn off the gas at the tank valve. Disconnect the regulator from propane tank. 4. Let the gas line and regulator stand for five minutes to allow air to purge. 5.
Page 21: Cleaning & Maintaining Your Griddle
CLEANING & MAINTAINING YOUR GRIDDLE WARNING: Always wear protective gloves and safety glasses when cleaning your grill. Turn off the gas supply at the source and disconnect the unit before servicing. To avoid the possibility of burns, maintenance should be done only when the griddle is cool and off. Keep your outdoor cooking area clear and free from combustible materials, gasoline, and other flammable vapors and liquids.
Page 22 CLEANING & MAINTAINING YOUR GRIDDLE BURNER TUBES AND BURNER PORTS To reduce the chance of a flashback fire you must clean the burner tubes before initial use, at least once a month in the summer and fall (or when spiders and other insects are active in your area), and if your griddle has not been used for an extended period of time.
Page 23: Frequently Asked Questions
Reinstall all orifices, burners, screws, and cooking components. If you suspect an obstruction in the gas valves or manifold, call the Element Customer Support at (888) 842-3577. Check for obstructions in the burner tubes. See “Burner Tubes and Burner Ports” on page 21 for cleaning instructions.
Page 24 Close off the gas supply at its source and reconnect fuel line to the griddle. If an obstruction is suspected in the orifice or gas valves, call the Element Customer Support at (888) 842-3577.
Page 25 What causes griddle parts to rust, and what effect does it have on my grill? Rusting is a natural oxidation process and will not affect the short-term performance of your griddle. To slow the rusting process on cooking grids, grease the grates before and after each use. Use a brush to apply a thin layer of cooking oil or vegetable shortening onto each grate.
Page 26: Specifications & Parts Diagram
SPECIFICATIONS & PARTS DIAGRAM DIMENSIONS MATERIALS Assembled Width 60 inches Griddle Material Oil Coated Steel Assembled Depth 23 inches Finish Gunmetal Gray Assembled Height 38 inches Main Cooking Area 600 sq. inches (W & D) (35.3" by 17") PARTS DIAGRAM 36"...
Page 27: Parts List
PARTS LIST PARTS LIST Part # Description Part # Part # Description Part # Griddle Plate DJ25001-01-01-00 Bottle Opener DJ24020S-04-03 Burner DJ24004-01-10 Right Leg DJ24004-02-03-00 Burner Electrode DJ24003-02-28 Regulator with Hose DJ42002 Assembly Ignition Wire DJ24004-01-11 Center Shelf DJ25001-02-04 Heat Shield Pane DJ25001-01-07 Gas Tank Bracket DJ24003-03-04-00...
Page 28: Warranty
Customer, or (iii) refund the documented purchase price paid by the Original Customer (excluding tax) to the Original Customer upon return of the defective Product as directed by Element. After the Warranty Period expires, the Original Customer must pay for all parts, components, shipping and handling, labor, and replacement costs associated with the Product or any part or component thereof, regardless of any defects in the Product or any part or component thereof.
Page 29 United States. The addition of equipment or features to the Product that are not manufactured or recommended by Element could affect the intended function of the Product, and therefore may void the Warranty. Furthermore, the exposure of the Product to...
Page 32 Element, the Element logo, and Bring it home are trademarks of Element Brand Holding, LLC. © 2024 Element Brand Holding, LLC. All rights reserved. Distributed by Element Appliance Company, LLC. Agusta, GA 30909.
