Himel HDM3SV User Manual

Moulded case circuit breaker
Hide thumbs

Advertisement

Table of Contents

HDM3SV
Moulded Case Circuit Breaker
User Manual
Detailed manual, please scan the code
Standard: IEC/EN 60947-2
□Please carefully read the user manual before installing
and operating the products, and then keep it properly
for further reference.
Apr.2025 Ver.01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDM3SV and is the answer not in the manual?

Questions and answers

Summary of Contents for Himel HDM3SV

  • Page 1 HDM3SV Moulded Case Circuit Breaker User Manual Detailed manual, please scan the code Standard: IEC/EN 60947-2 □Please carefully read the user manual before installing and operating the products, and then keep it properly for further reference. Apr.2025 Ver.01...

  • Page 2: Safety Notice

     If the product is damaged or makes any abnormal noises when unpacking, it should be immediately stopped from use and the supplier should be contacted.  Please handle the discarded products properly. Thank you for your cooperation. Packing list HDM3SV Phase HDM3SV Phase Name Screw.Nut...
  • Page 3 Know HDM3SV Protection class: 125AF-IP30; Others IP20  Pollution class: 3  Allowable ambient temperature range(-20~+60 ), relative humidity (at an ambient  °C temperature of 25 )≤95%, 24h average temperature is not exceeding 35 °C °C The altitude at the installation site cannot be higher than 2000m; otherwise, degrade ...
  • Page 4 HDM3SV Safety clearance Model A(mm) B(mm) C* (mm) HDM3SV-125 HDM3SV-160 HDM3SV-250 HDM3SV-630 Note: 1) Please take care cable isolation to make sure enough safety distance. 2) Please make sure to provide additional insulation protection between the products, if the distance needs to be...
  • Page 5 HDM3SV Installation Mounting the MCCB Torque Model (N.m) HDM3SV-125 1.2(M4) HDM3SV-160 1.2(M4) HDM3SV-250 1.2(M4) HDM3SV-630 3.0(M6) Dimension of the Mounting Holes Model Poles A 110 25 HDM3SV-125 110 25 25 4.5 132 30 HDM3SV-160 132 30 30 4.5 126 35...
  • Page 6 HDM3SV Installation Fixed Rear Mounting Hole Drawing Note: X-X and Y-Y is the center of the three-pole break Model Poles A D1 H1 H2 D3 110 25 4.5 114 10.5 51 81 Ø8 HDM3SV-125 110 25 25 4.5 114 25 10.5 51 81 Ø8 132 30 4.5 134...
  • Page 7 HDM3SV Installation Plug-in Rear Installation Dimension Hole size Model Poles A4 A5 A6 H B1 B2 B3 B4 130 50.6 114 160.5 50.6 27 88 56 35 25 4.5 HDM3SV-125 130 50.6 114 160.5 50.6 27 88 56 35 100 75 100 50 4.5 155 54 132 181.5...
  • Page 8 HDM3SV Installation Plug-in Front installation Dimension Note: 400A, 630A don't need insulating plate. Hole size Model Poles Ød B1 Ød1 W 4.5 160 152 182 198 50.5 50 HDM3SV-125 4.5 160 152 182 198 50.5 50 4.5 100 4.5 182 172 200 216 61.5 30...
  • Page 9 HDM3SV Wiring Torque (mm) Model (N.m) 160/250 9.5-10.5 9.5-20.5 Conductor Current Copper busbar Quantity cross Rating(A) size:mm section(mm 30/32 35/40/50 70/80 140/150 180/200/225 30x5 600/630 40x5 Dimension (mm) Model 13.4...
  • Page 10 HDM3SV Operation Main Switch Operation 1.CLOSE 2.ON 3.TRIP Interphase Barrier Operation Installation Removal...
  • Page 11 HDM3SV Dimension HDM3SV-125 3P HDM3SV-125 4P...
  • Page 12 HDM3SV Dimension HDM3SV-160 3P HDM3SV-160 4P...
  • Page 13 HDM3SV Dimension HDM3SV-250 3P HDM3SV-250 4P...
  • Page 14 HDM3SV Dimension HDM3SV-630 3P HDM3SV-630 4P...

  • Page 15: Care And Maintenance

    Care and Maintenance It must be maintained and serviced by personnel with professional qualifications. It must ensure that the product is not electrified under normal operating conditions, the product should be maintained and serviced once a year. The maintenance content is as follows: Appearance: No dust, no condensation, and no damage to the shell.
