Original user manual

CLAMPS

AND

COUPLERS

Manufacturer:

Rolight Theatertechniek B.V.

Josink Kolkweg 10

7545 PR Enschede , The Netherlands

Phone (+31)53 432 06 44

info@rolight.nl

www.rolight.nl

Distributed by ADMIRAL

www.admiralstaging.com

VERSION 01

October 2023

Table of Contents

Need help?

Do you have a question about the RIHAHCA10 and is the answer not in the manual?

Questions and answers

Summary of Contents for Admiral Staging RIHAHCA10

Page 1 Original user manual CLAMPS COUPLERS Manufacturer: Rolight Theatertechniek B.V. Josink Kolkweg 10 7545 PR Enschede , The Netherlands Phone (+31)53 432 06 44 info@rolight.nl www.rolight.nl VERSION 01 October 2023 Distributed by ADMIRAL www.admiralstaging.com...
Page 2: Table Of Contents
CONTENTS LEGEND 1. INTRODUCTION DANGER 2. SAFETY INSTRUCTIONS 3. SCOPE 4. LIMITATIONS OF USE DANGER: Indicates a hazardous 5. TECHNICAL DATA & LOADCHART situation which, if not avoided, will result in 6. IDENTIFICATION death or serious injury. 7. EXPLANATION OF THE TÜV-STICKER This signal word is to be limited to 8.
Page 3: Scope
4. LIMITATIONS OF USE CAUTION DO NOT lift or load above people without the following precautions: WARNING • The CLAMPS must be taken out of service immediately if, during use, repair Exceeding the limitations of use can seve- or maintenance damages are discovered. rely endanger the audience and users.
Page 4 product shall be rinsed regularly with fresh water WARNING to avoid corrosion. • solely apply vertical loads unless It is also imperative to observe the local accident approved by a competent person prevention regulations and/or occupational health and safety regulations. •...
Page 5: Quick Coupler
TECHNICAL DATA Quick coupler Article code: RIHAHCA10 EAN: 8720094421285 WLL: 250 kg Material: aluminium alloy Colour: silver Diameter tube: 48-51 mm Weight: 0.47 kg DIMENSIONS 95.9 64.9 17.5 M10*1.5P...
Page 6 TECHNICAL DATA Quick coupler Article code: RIHAHCA12 EAN: 8720094421292 WLL: 250 kg Material: aluminium alloy Colour: black Diameter tube: 48-51 mm Weight: 0.47 kg DIMENSIONS 95.9 64.9 17.5 M10*1.5P...
Page 7 TECHNICAL DATA Selflock coupler easy Article code: RIHAHCA14 EAN: 8720094421308 WLL: 250 kg Material: aluminium alloy Colour: silver Diameter tube: 48-51 mm Weight: 0.50 kg DIMENSIONS 84.7 17.3 M10*1.5P...
Page 8 TECHNICAL DATA Selflock coupler easy Article code: RIHAHCA16 EAN: 8720094421315 WLL: 250 kg Material: aluminium alloy Colour: black Diameter tube: 48-51 mm Weight: 0.47 kg DIMENSIONS 84.7 17.3 M10*1.5P...
Page 9 TECHNICAL DATA Halfcoupler Article code: RIHAHCA22 EAN: 8720094429779 WLL: 10 kg Material: aluminium alloy Colour: silver Diameter tube: 18-21 mm Weight: 0.031 kg DIMENSIONS 56.2 M6*1.0P 28.4...
Page 10: Technical Data & Loadchart
TECHNICAL DATA Halfcoupler with 25 mm halfcone Article code: RIHAHCA26 EAN: 8720094429762 WLL: 50 kg Material: aluminium alloy Colour: silver Diameter tube: 32-35 mm Weight: 0.15 kg DIMENSIONS 56.2 28.4 24.5...
Page 11 TECHNICAL DATA Halfcoupler Article code: RIHAHCA30 EAN: 8720094421339 WLL: 75 kg Material: aluminium alloy Colour: silver Diameter tube: 32-35 mm Weight: 0.15 kg DIMENSIONS 56.2 M10*1.5P 28.4...
Page 12 TECHNICAL DATA Halfcoupler Article code: RIHAHCA32 EAN: 8720094421346 WLL: 75 kg Material: aluminium alloy Colour: black Diameter tube: 32-35 mm Weight: 0.15 kg DIMENSIONS 56.2 M10*1.5P 28.4...
Page 13 TECHNICAL DATA Halfcoupler Article code: RIHAHCA35 EAN: 8720094421353 WLL: 100 kg Material: aluminium alloy Colour: silver Diameter tube: 48-51 mm Weight: 0.16 kg DIMENSIONS M10*1.5P...
Page 14 TECHNICAL DATA Halfcoupler Article code: RIHAHCA37 EAN: 8720094421360 WLL: 100 kg Material: aluminium alloy Colour: black Diameter tube: 48-51 mm Weight: 0.16 kg DIMENSIONS M10*1.5P...
Page 15 TECHNICAL DATA Halfcoupler Article code: RIHAHCA40 EAN: 8720094421384 WLL: 200 kg Material: aluminium alloy Colour: silver Diameter tube: 48-51 mm Weight: 0.38 kg DIMENSIONS M10*1.5P...
Page 16 TECHNICAL DATA Halfcoupler Article code: RIHAHCA41 EAN: 8720094421391 WLL: 200 kg Material: aluminium alloy Colour: black Diameter tube: 48-51 mm Weight: 0.37 kg DIMENSIONS M10*1.5P...
Page 17 TECHNICAL DATA Halfcoupler Article code: RIHAHCA42 EAN: 8720094421407 WLL: 500 kg Material: aluminium alloy Colour: silver Diameter tube: 48-51 mm Weight: 0.55 kg DIMENSIONS M10*1.5P...
Page 18 TECHNICAL DATA Halfcoupler Article code: RIHAHCA44 EAN: 8720094421414 WLL: 500 kg Material: aluminium alloy Colour: black Diameter tube: 48-51 mm Weight: 0.55 kg DIMENSIONS M10*1.5P...
Page 19 TECHNICAL DATA Halfcoupler Article code: RIHAHCA48 EAN: 8720094421421 WLL: 200 kg Material: aluminium alloy Colour: silver Diameter tube: 48-51 mm Weight: 0.37 kg DIMENSIONS M10*1.5P...
Page 20 TECHNICAL DATA Halfcoupler Article code: RIHAHCA50 EAN: 8720094421438 WLL: 200 kg Material: aluminium alloy Colour: black Diameter tube: 48-51 mm Weight: 0.37 kg DIMENSIONS M10*1.5P...
Page 21 TECHNICAL DATA Halfcoupler Article code: RIHAHCA52 EAN: 8720094421445 WLL: 750 kg Material: aluminium alloy Colour: silver Diameter tube: 48-51 mm Weight: 0.55 kg DIMENSIONS 104.1 M12*1.75P...
Page 22 TECHNICAL DATA Halfcoupler Article code: RIHAHCA54 EAN: 8720094421452 WLL: 750 kg Material: aluminium alloy Colour: black Diameter tube: 48-51 mm Weight: 0.55 kg DIMENSIONS 104.1 M12*1.75P...
Page 23 TECHNICAL DATA Halfcoupler with spigot mount Article code: RIHAHCA56 EAN: 8720094429786 WLL: 100 kg Material: aluminium alloy Colour: silver Diameter tube: 48-51 mm Weight: 0.33 kg DIMENSIONS 129,2 88,3 195,7...
Page 24 TECHNICAL DATA Swivel coupler Article code: RIHAHCA60 EAN: 8720094421469 WLL: 500 kg Material: aluminium alloy Colour: silver Diameter tube: 48-51 mm Weight: 1.07 kg DIMENSIONS M10*1.5P...
Page 25 TECHNICAL DATA Swivel coupler Article code: RIHAHCA62 EAN: 8720094421476 WLL: 500 kg Material: aluminium alloy Colour: black Diameter tube: 48-51 mm Weight: 1.06 kg DIMENSIONS M10*1.5P...
Page 26 TECHNICAL DATA Swivel coupler Article code: RIHAHCA64 EAN: 8720094421483 WLL: 100 kg Material: aluminium alloy Colour: silver Diameter tube: 48-51 mm Weight: 0.25 kg DIMENSIONS M10*1.5P...
Page 27 TECHNICAL DATA Swivel coupler Article code: RIHAHCA66 EAN: 8720094421490 WLL: 100 kg Material: aluminium alloy Colour: black Diameter tube: 48-51 mm Weight: 0.25 kg DIMENSIONS M10*1.5P...
Page 28 TECHNICAL DATA Swivel coupler Article code: RIHAHCA67 EAN: 8720094421506 WLL: 200 kg Material: aluminium alloy Colour: silver Diameter tube: 48-51 mm Weight: 1.07 kg DIMENSIONS M10*1.5P...
Page 29 TECHNICAL DATA Swivel coupler Article code: RIHAHCA69 EAN: 8720094427768 WLL: 200 kg Material: aluminium alloy Colour: black Diameter tube: 48-51 mm Weight: 1.07 kg DIMENSIONS M10*1.5P...
Page 30 TECHNICAL DATA Halfcoupler Article code: RIHAHCA70 EAN: 8720094421513 WLL: 750 kg Material: aluminium alloy Colour: silver Diameter tube: 58 - 61 mm Weight: 0.73 kg DIMENSIONS 111.2...
Page 31 TECHNICAL DATA Halfcoupler Article code: RIHAHCA72 EAN: 8720094421520 WLL: 750 kg Material: aluminium alloy Colour: black Diameter tube: 58 - 61 mm Weight: 0.73 kg DIMENSIONS 111.2...
Page 32: Identification
7. EXPLANATION OF Applicable Directives, Regulations, Standards and Information Papers THE TÜV-sticker The following directive is applicable 2006/42/EC Machinery directive RIHAHCA10 WLL 250 kg QC 48-51mm The following regulation is used DGUV 17/18 DGUV regulation 17 Regulations for stages and...
Page 33: Disassembly Instructions
Step 3a Step 3b Tighten the wingnut. Tighten the wingnut. Step 3 Step 4 Remove the clamp from Remove the clamp the supporting structure. from the load. 10. STORAGE The CLAMPS must be stored in a dry, non-aggressive environment. • Make sure the parts cannot bend.
Page 34: Warranty
12. WARRANTY WARNING • For a period of 24 months we will repair, free of charge, any damage attributable to faulty If damaged, mark the item clearly and take it out of service. materials or workmanship under the condition that the equipment is forwarded, freight paid, to our warehouse or one of the ADMIRAL •...
Page 35: Tüv Certificate
13. TÜV CERTIFICATE RIHAHCA10, RIHAHCA10, RIHAHCA12 RIHAHCA12 250kg 250kg RIHAHCA14, RIHAHCA14, RIHAHCA16 RIHAHCA16 250kg 250kg RIHAHCA22, RIHAHCA22, 10kg 10kg RIHAHCA26, RIHAHCA26, RIHAHCA32 RIHAHCA32 50kg 50kg RIHAHCA30, RIHAHCA30, 75kg 75kg RIHAHCA35, RIHAHCA35, RIHAHCA37 RIHAHCA37 100kg 100kg RIHAHCA40, RIHAHCA40, RIHAHCA41 RIHAHCA41 200kg...
Page 36: Ec Declaration Of Conformity
14. EC DECLARATION OF CONFORMITY EC-DECLARATION OF CONFORMITY FOR MACHINERY (2006/42/EG Annex II) Rolight Theatertechniek Josink Kolkweg 10 7545 PR Enschede  The Netherlands Herewith declares that: ADMIRAL “CLAMPS & COUPLERS”; all codes starting with RIHAHCA*** - is in compliance with the Machinery Directive 2006/42/EwC annex II - the following harmonized standards have been applied (or parts/clauses of): EN 12100-1-2010 - Part/clauses of the following technical regulations , standards and information papers have been used: German DGUV 17-18, German DGUV 215-313,...
Page 37 | www.admiralstaging.com | Josink Kolkweg 10 | 7545 PR Enschede | | The Netherlands | Tel: +31 53 4 301 201 |...

This manual is also suitable for:

Rihahca12 Rihahca14 Rihahca16 Rihahca22 Rihahca26 Rihahca30 ... Show all
