Summary of Contents for Ascent Communication Technology A1600E
- Page 1 A1600E DCI OA Module Installation Manual Revision 1B...
- Page 2 A1600E DCI OA Module QRG ACT A1600E DCI Optical Amplifier Module Installation Manual ACT Document Number: ACT A1600E DCI Optical Amplifier Module Installation Manual Revision 1B Copyright © 2024 Ascent Communication Technology Limited. All rights reserved. Reproduction in any manner whatsoever without the express written permission of Ascent Communication Technology is strictly forbidden.
- Page 3 A1600E DCI OA Module QRG Contents Precautions ..........................4 1. Product Overview........................5 2. Card Introduction ........................5 3. Product Features ........................5 4. Indicator Description ......................6 5. Transmission Principle ......................7 6. Typical Application Diagram ....................9 7. Technical Parameters ......................11 8.
- Page 4 A1600E DCI OA Module QRG The device's transmitting port outputs invisible laser radiation. When the device is connected to work, the connector end face should not be directly viewed under any circumstances to avoid Warning burning eyes and skin. The device contains precision optics to avoid damage caused by severe impact. Avoid arranging vibrations and collisions.
- Page 5 A1600E DCI OA Module QRG The A1600E DCI OA card is an erbium-doped fiber amplifier. It can directly regenerate muti-wavelength optical signals without the need for optical-electrical-optical conversion, thereby extending the signal transmission distance. With DWDM multiplexer/demultiplexer to realize WDM transmission, especially suitable for long- distance trunk networks, metropolitan area networks, access networks, and various SDH/PDH transmission systems.
- Page 6 A1600E DCI OA Module QRG Interface Description Green: The board is powered on Off: The board is not powered on STAT Green: The board is in normal state Red: The board is faulty Light off: The board is not powered on...
- Page 7 A1600E DCI OA Module QRG a. Schematic Diagram MON(DWDM) SIN(1510) SOUT(1510) IN(DWDM) OUT(DWDM) Optical EDFA Filter Filter splitter module 1510 1510 VIN(DWDM) Driver and Power performance supply +12V DVOA detection module module VOUT(DWDM) Control and communication module Data bus Equipment backboard b.
- Page 8 A1600E DCI OA Module QRG a. Schematic Diagram SOUT(1510) MON(DWDM) SIN(1510) IN(DWDM) EDFA Optical Filter Filter module splitter OUT(DWDM) VIN(DWDM) Driver and Power performance supply +12V DVOA detection module module VOUT(DWDM) Control and communication module Data bus Equipment backboard b. Signal Trend Diagram...
- Page 9 Remarks: The parameter indicators of the EDFA card are for reference only, and the specific parameters will depend on the actual application requirements to choose the gain level for each type of card. Including, the signal gain level of the Pre AMP card type (A1600E-EDFA-P-V-M) is 25dB, and the Booster AMP card type (A1600E-EDFA-B-V-M) is 16dB.
- Page 10 Remarks: The parameter indicators of the EDFA card are for reference only, and the specific parameters will depend on the actual application requirements to choose the gain level for each type of card. Including, the signal gain level of the Pre AMP card type (A1600E-EDFA-P-V-M) is 25dB, and the Booster AMP card type (A1600E-EDFA-B-V-M) is 16dB.
- Page 11 A1600E DCI OA Module QRG BA Parameters Parameter Min. Typ. Max. Unit Remarks Working Wavelength 1527.9 1565.6 Input Optical Power Range Gain Output Optical Power Range -10 Gain Flatness @In=4dBm，G=16dB Noise Figure @Gain=16dB Polarization Dependent Gain - Input/Output Return Loss...
- Page 12 A1600E DCI OA Module QRG Parameter Description Card Size 100 (W) × 40 (H) ×266 (D) (mm) Environmental Requirements Operating Temperature -5°C to 45°C Storage Temperature -40°C to 80°C Relative Humidity 5 % to 95 % non-condensing Safety and EMC...
- Page 13 A1600E DCI OA Module QRG Basic information: You can view the card unit model, unit SN, manufacturer name, software and hardware version, production date, unit type, temperature(℃), power consumption(W), voltage(V), current(A), etc. Soft/hard reset button RST, perform software/hardware reset on the OA card. Soft reset does not affect service communication, and hardware reset will power off and restart the card.
- Page 14 A1600E DCI OA Module QRG Click to edit, and click to confirm. Modify the target gain value and set the corresponding value ; Modify the EDFA-PA VOA adjustable target attenuation(set the step size to 0.1dB) and check the actual VOA attenuation value.
- Page 15 A1600E DCI OA Module QRG OSC information: You can view the OSC optical module port number, port name, SN, transmission distance, wavelength, rate, receiving status, and sending mode. DDM information: You can view the OSC optical module port number, port name, optical power, module bias current, voltage, module temperature, and add port description.
- Page 16 Phone: +84-24-37955917 WEB: EMAIL: www.ascentcomtec.com sales@ascentcomtec.com Specifications and product availability are subject to change without notice. Copyright © 2024 Ascent Communication Technology Limited. All rights reserved. Ver. ACT_A1600E_DCI_OA_Module_Installation_Manual_V1b_Feb_2024 Solutions Provider for FTTx, RFoG, and HFC www.ascentcomtec.com Page 16 of 16...
