Summary of Contents for Outdoor Tech CHIPS ULTRA
- Page 1 CHIPS ULTRA ® TRUE WIRELESS HELMET AUDIO...
- Page 3 Good call on picking up the Outdoor Tech ® Chips® Ultra true wireless helmet audio. Your experience of the universe will soon be enhanced. This manual exists to help make sure that you use them correctly, so you’re definitely going to want to relax for a hot second and look through this.
-
Page 4: Table Of Contents
Anatomy ............2 Functions ............3 Charging The Case ..........4 Charging The Chips ..........5 Pairing ...............6 Music Functions ..........7 Phone Functions ..........8 Volume Controls ..........9 Put The Chips Ultra in Your Helmet ....10 Specs ..............11 Care And Maintenance ........12... -
Page 5: What's Inside
WHAT’S INSIDE LEFT RIGHT EAR PIECE EAR PIECE CHARGING CASE USB to Micro cable • Left and right helmet audio • Charging case • Charging cable • Instruction manual • One ODT sticker... -
Page 6: Anatomy
ANATOMY LEFT EAR RIGHT EAR BUTTON BUTTON A. Left ear button B. Right ear button C. LED light D. Microphone E. Hi-Fi Speakers... -
Page 7: Functions
RIGHT Short press three times Raise Volume LEFT Short press once Lower Volume LEFT Short press twice Siri/Voice Activation RIGHT Long press 1 sec Reset Chips Ultra/ Refer to the paper insert in Clear BT Memory the box for instructions... -
Page 8: Charging The Case
CHARGING-THE CASE Charge up the case so you always have power for your Chips ® Ultra on the go. Once the charging case is plugged into the micro- USB, the indicator light on the front will turn RED- (CHARGING). It will turn GREEN once the case is completely charged. -
Page 9: Charging The Chips
CHARGING-THE CHIPS Charge your Chips ® Ultra on the way to the hill, instead of having to plug them in the night before. Gently plug the three holes on the side of the Chips ® Ultra into the three prongs in the charging case. Be sure to put the Left Chip in the Left side and the Right Chip in the Right side in the charging case. -
Page 10: Pairing
RIGHT POWER ON THE RIGHT (long press 3 seconds) VOICE PROMPT: “power on >> battery level >> pairing” Choose: “ODT Chips Ultra” in your phone’s Bluetooth settings. VOICE PROMPT: “device connected” LEFT POWER ON THE LEFT (long press 3 seconds) -
Page 11: Music Functions
MUSIC FUNCTIONS RIGHT FUNCTION ACTION POWER ON long press 3 seconds POWER OFF Press and hold 4 seconds PLAY short press 1x PAUSE short press 1x SKIP FORWARD short press 2x SKIP BACKWARD short press 3x... -
Page 12: Phone Functions
PHONE FUNCTIONS RIGHT FUNCTION ACTION ANSWER CALL short press 1x END CALL short press 1x REJECT CALL long press 2 seconds SIRI / VOICE long press 1x ACTIVATION... -
Page 13: Volume Controls
VOLUME CONTROLS LEFT FUNCTION ACTION POWER ON long press 3 seconds POWER OFF Press and hold 4 seconds VOLUME UP short press 1x VOLUME DOWN short press 2x... -
Page 14: Put The Chips Ultra In Your Helmet
PUT THE CHIPS ULTRA IN YOUR HELMET IT’S EASY! JUST SLIDE THEM IN No wires, no cords, just slide them into your helmet ear pads and your 1. Drop the CHIPS® Ultra into the slots inside your helmet liner. ready to hit the slopes. -
Page 15: Specs
SPECS Bluetooth version: Bluetooth 5.0+ EDR Bluetooth profiles: A2DP, AVRCP, HSP, HFP Driver units: 40mm Neodymium magnet Frequency Response: 20~20,000 Hz Impedance: 32 + 32 ohms Sensitivity (1kHz): 110 dB Range: Up to 10m/33ft Microphone: Built-in microphone Battery: 3.7V, 250 mAh Charging time: About 2 hours Play / Talk time: Up to 13 hours CHARGING CASE... -
Page 16: Care And Maintenance
CARE & MAINTENANCE -Keep the Chips® Ultra away from direct sunlight or hot places. High temperatures will shorten the life of electronic devices, destroy the battery or distort certain plastic parts. -Do not try to disassemble the CHIPS® Ultra. -Do not let the Chips® Ultra fall onto the floor or other hard surfaces. - Page 17 Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 18 DON’T BE SO ANTISOCIAL Facebook.com/outdoortechnology Twitter & Instagram: @outdoortech Questions, comments, complaints, secret desires, or just to say what’s up: email info@outdoortech.com K bye. outdoortech.com...
