MUV

REBEL

USER MANUAL

UNLOCK THE FULL

POTENTIAL OF YOUR

WAY TO MUV.

Table of Contents

Need help?

Do you have a question about the REBEL and is the answer not in the manual?

Questions and answers

Summary of Contents for MÜV REBEL

Page 1 REBEL USER MANUAL UNLOCK THE FULL POTENTIAL OF YOUR WAY TO MUV.
Page 2 CONGRATULATIONS ON YOUR NEW MUV E-BIKE! Welcome to the MUV AUSTRALIA family! We’re a proud, family-owned business passionate about creating top-quality electric bikes that prioritize safety, innovation, exceptional ride experiences. We’re always evolving to bring you the best products and excellence in customer service As a new MUV eBike owner, you’ll be pleased to know we offer a great warranty for your peace of mind (see our Terms and Conditions for...
Page 3: Table Of Contents
USER MANUAL TABLE OF CONTENTS Diagram of e-bike specific components Specification Display How to use Battery Charger Important Notice Before Riding Initial Assembly and Monthly Maintenance Checklist WARNING Terms & Condition WARRANTY...
Page 4: Diagram Of E-Bike Specific Components
DIAGRAM OF E-BIKE SPECIFIC COMPONENTS Tyre Handlebar Battery Display Controller Front fork Saddle Motor SPECIFICATION Frame: 20 Inch aluminium-alloy Brake: F/R hydraulic Disc Brake Motor: 250W brushless Charger: AC 110V-240V Smart Charge Battery: Lithium battery 48V 15.6Ah Charge time: 4-6 hours Display: LCD with 5 mode Max speed: 25km/h Sensor: Speed sensor 1:1...
Page 5: Display
DISPLAY 1. LCD INSTRUCTIONS The figure of LCD display see below: 1.1 Head light USB charging remind Braking condition 1.2 Battery capacity 1.3 ODO: total distance Trip: DST trip distance Pow: digital voltage Time:riding time 1.4 Mode: 6km push Cruise control 1.5 Speed MAX:max speed AVG: average speed...
Page 6: Functional Description
DISPLAY 2. FUNCTIONAL DESCRIPTION 2.1POWER ON/OFF Press and hold button for 1 second can turn on/off the display. The display will automatically shut down when there is no operate & ride for 5 minutes. 2.2 PAS OPERATING Short press button can change the PAS level. Top PAS level is 5, 0 for neutral.
Page 7: How To Use
HOW TO USE THE PROCESS OF OPENING AND WORKING. A. Make sure the battery assemble correctly and battery is alive. B. Turn on the “M” switch button on the display and turn to a level of power which you like and then ride it. C.
Page 8: Battery
BATTERY 1.1.IMPORTANT SAFETY NOTES CONCERNING THE BATTERY WARNING To prolong battery life, store the Ebike in garage to prevent low temperatures and affect the battery performance. - Do not dismantled or dispersed the battery cells. - Keep away the battery from children. -Do not connect cathode and anode of charger during charging and discharge process.
Page 9 BATTERY 2. PROTECTION To extend the battery life and be Intelligent Use of li-battery, here are the regula- tions: FIRSTLY: REQUIREMENTS ON CHARGING AND DISCHARGING A. CHARGE: The charger must be the assorted one . First, connect the power to charger.
Page 10 BATTERY THIRDLY: MAINTENANCE When you test the voltage of the single piece of the battery-cell, you have to test the cell directly ,not by the wire. By doing that, it can avoid the voltage decline. You have to wear the gloves or clip the finger nails before you take out the single piece of the battery.
Page 11: Charger
CHARGER 1. CHARGER FUNCTION Trouble shooting: Should there be any difficulties with charging please check if: - The power cable is connected properly. - The charger plug or the battery socket is damaged. - The battery shows any damage on the surface. The power socket works and whether the correct voltage is provided.
Page 12 CHARGER 2. IMPORTANT SAFETY NOTES CONCERNING THE CHARGE Before you first use the charger please read the following notes regarding safety carefully! WARNING DO NOT OVERCHAGE THE BATTERY. Overcharging a lithium-ion battery can cause overheating, pressure buildup, and thermal runaway, potentially leading to fire or explosion. It also shortens battery life and degrades capacity over time - Keep the charger away from children! - In order to prevent any possible injury this charger should only be used for the...
Page 13 CHARGER - Make sure the charge is always placed on a flat surface when in use. - Please make sure that the charger is always unplugged tand removed from the power socket when not in use. - Before using the charger, always make sure that the plug and the cables are not damaged.
Page 14: Important Notice Before Riding
IMPORTANT NOTICE BEFORE RIDING - If you’re unsure how to assemble your new bike, we recommend seeking assistance from your local bike store. - Your safety is our top priority. Please follow all safety and maintenance instructions outlined in this manual and in the MUV AUSTRALIA PTY LTD Terms and Conditions available on our website.
Page 15 INITIAL ASSEMBLY MONTHLY MAINTENANCE CHECKLIST 3. Pedals Installation Check for the “L” and “R” markings on the pedals. • “L” pedal goes on the LEFT side. • “R” pedal goes on the RIGHT side. Important: The left pedal is reverse threaded, meaning it tightens in the opposite direction.
Page 16 INITIAL ASSEMBLY MONTHLY MAINTENANCE CHECKLIST Remove the plastic protector from the front disc brake. Insert the front hub into the wheel and position the wheel onto the fork dropout, ensuring the disc brake is properly aligned and the front hub is securely tightened. 5.
Page 17: Battery Charging
INITIAL ASSEMBLY MONTHLY MAINTENANCE CHECKLIST 6. Position the rear light towards the end of the rear rack. 7. Install the Mid Basket with 4 screws, 2 in each side 8. Attach the footrest by first removing the screw from the bottom of the rear suspension.
Page 18: Handlebar Components
INITIAL ASSEMBLY MONTHLY MAINTENANCE CHECKLIST • Brake disc rotor bolts (front & rear) • Brake callipers (front & rear) • Handlebars • Forks • Crank • General bike bolts Handlebar Components: Ensure brake levers, display, buttons, and bells are secure. Avoid overtightening plastic components, as this may cause damage.
Page 19: Weather Conditions
INITIAL ASSEMBLY MONTHLY MAINTENANCE CHECKLIST Load Capacity: Do not exceed the bike’s maximum load capacity of 180 kg. Weather Conditions: Avoid riding in adverse weather conditions such as rain, strong winds, or extreme temperatures above 45°C. Terrain Usage: This bike is not designed for mountain terrain. Avoid surfaces that may cause extreme vibrations to the battery pack.
Page 20: Warning
WARNING Improper assembly or use of this electric bike may result in serious injury or death. Always ride responsibly and wear appropriate safety gear. By purchasing and operating a MUV electric bike, you agree to our Terms and Conditions of Service. To review the full terms,visit: www.muvaustralia.com.au Safety Guidelines: Health &...
Page 21: Terms & Condition
TERMS & CONDITIONS ACCEPTANCE OF TERMS By purchasing from MUV AUSTRALIA PTY LTD, you and anyone you represent agree to be bound by this Agreement. You affirm that you have the authority to accept these terms on behalf of yourself and any other party you represent. If you do not accept these terms or lack the necessary authority, you may not purchase products from MUV AUSTRALIA PTY LTD.
Page 22 TERMS & CONDITIONS The only recourse under any implied warranty is the replacement or repair of defective parts, which will be of equal or greater value, at the discretion of MUV AUSTRALIA PTY LTD. Except where explicitly prohibited by law, MUV AUSTRALIA PTY LTD shall not be held liable for any property damage, personal injury or death, fire-related incidents, loss of use, opportunity, contracts, goodwill, business interruption, profits, cause and effect losses, or any other consequential, direct, indirect, incidental,...
Page 23: Shipping Policy
TERMS & CONDITIONS Shipping Policy We assure you that your order will be delivered. In the event of a lost item, we will send a replacement at no additional cost. However, we are not liable for dispatch delays, or any delayed or unscheduled deliveries For bike deliveries, a signature is required upon receipt.
Page 24 TERMS & CONDITIONS purchase. If we cannot verify that the requestor is a legitimate buyer of our products, service may be denied. If you are purchasing a second-hand bike, please ensure you obtain the original proof of purchase from the previous owner. User-Submitted Content By submitting thoughts, customer reviews, images, videos, testimonials, technical issues, or service tickets, you grant us and our authorized partners a royalty-free...
Page 25 TERMS & CONDITIONS Force Majeure Event We will make every effort to ensure the supply and delivery of products and services. However, performance may be subject to variation or cancellation due to a Force Majeure Event beyond the Supplier’s control, or an inability to procure materials except at increased prices due to such events.
Page 26: Warranty
WARRANTY Our warranty terms and conditions cover all customers, regardless of whether the products are purchased directly, through dealers, third parties, or second-hand. If any original component is found to be defective in workmanship within its warranty period, we will repair or replace it. The warranty period for MUV AUSTRALIA PTY LTD is as follows: •...
Page 27 WARRANTY A bicycle operates under real-world conditions and is subject to various impacts, shocks, vibrations, extreme temperatures, accidents, water exposure, and salt splashes. Such damages are not considered manufacturing faults and are therefore not covered under the warranty. Tyre punctures are not covered by this warranty. Your electric bike and its components are water-resistant under normal damp or wet conditions.
Page 28: Warranty Claims
WARRANTY If a warranty extension is available for any of our products, you may pay the applicable fees to receive coverage under the same terms and conditions. Applications for the extension must be submitted up to one day before the standard warranty period expires.
Page 29 UNLOCK THE FULL POTENTIAL OF YOUR WAY TO MUV. Shop 07, 84 Rajah Road, Ocean Shores, CEP 2483, NSW phone +61 447 065 486 @muv_electric www.muvaustralia.com.au...
