- Page 1 Installation Instructions W35 Indoor/Outdoor Lockable Wall Box W35XXX00-UB...
- Page 2 W35 Indoor/Outdoor Lockable Wall Box Before installing or adjusting this product, please read these instructions carefully. Please keep this guide for future reference. Safety Precautions General Precautions Personnel must be thoroughly familiarized with all applicable Occupational Health and Safety (OH&S) regulations, local regulations, and your company safety practices and policies.
-
Page 3: Optional Accessories
W35 Indoor/Outdoor Lockable Wall In the Box Item Item Number Splice Protectors Wall Anchor (03) ST 5x40 Screws (02) Wall Anchors (01) Splice Protectors ST 5x40 Screw Cable Tie Spiral Tubing (06) Fiber Protection (04) Cable Ties (05) Spiral Tubing... -
Page 4: Cable Installation
Route fiber anti clockwise round the fiber Secure Strength Member in Clamp storage area Protect the fiber with spiral tubing before Enter the splice tray on the left-hand side and feeding into base of tray cable tie if required © AFL. All rights reserved... - Page 5 W35 Indoor/Outdoor Lockable Wall Cable Installation Feed incoming fiber around the back of the splice Route fiber anti clockwise round the tray tray Connector and Pigtail Installation 10. Insert Pigtails and store fiber anti clockwise around Install the required adapters maintaining the...
- Page 6 11. Enter the pigtails to back side from the right-hand side on top 2 12. Route the fiber clockwise round the tray 13. Prepare fiber for the splice and splice and place the fiber according Mounting Sleeves Installation Mounting sleeves © AFL. All rights reserved...
- Page 7 W35 Indoor/Outdoor Lockable Wall Notes © AFL. All rights reserved...
- Page 8 Thank you for choosing AFL AFL reserves the right to make changes to this Installation Instruction at any time without notice AFLW35100624...
