LI-ION CORDLESS MINI CHAIN SAW

INSTRUCTION MANUAL

SAVE THIS MANUAL !

You will need this manual for safety instructions, operating procedures and warranty.

Put it and the original sales receipt in a safe dry place for future reference.

20V

LITHIUM-ION

Table of Contents

Need help?

Do you have a question about the MP20V 87366 and is the answer not in the manual?

Questions and answers

Summary of Contents for TOLSEN TOOLS MP20V 87366

Page 1 87366 LI-ION CORDLESS MINI CHAIN SAW INSTRUCTION MANUAL LITHIUM-ION LITHIUM-ION SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
Page 2: Important Safety Information
SAFETY IMPORTANT SAFETY INFORMATION General Power Tool Safety Warnings WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, ﬁre and/or serious injury. WARNING: This appliance is not intended for use by persons (including children) with reduced, physical or mental capabilities or lack of experience or knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Page 3: Personal Safety
SAFETY Personal safety 1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the inﬂuence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
Page 4: Chainsaw Safety Warnings
SAFETY Service 1. Have your power tool serviced by a qualiﬁed repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. 2. Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer or authorized service providers.
Page 5 SAFETY Additional safety instructions for one hand power saw 1. The one hand power saw is designed for cutting branches. Only use the one hand power saw as indicated in this manual for cutting wood. The machine has not been designed for continuous, professional use. 2.
Page 6: Battery Charger Safety
SAFETY Battery Safety WARNING This battery can only be used in the machines included in the TOLSEN MP20V lithium-ion power platform system. This battery can only be used cooperatively with the designated battery charger. Li-lon batteries, if incorrectly used, stored or charged will cause a ﬁre, burn and explosion hazard. Failure to follow these instructions may cause overheating or ﬁre.
Page 7 SAFETY Note: Symbology CE conformity Read the instruction manual before using Wear hearing protection while operating the tool Wear hand protection Always use breathing apparatus when machining materials which generate dust. Wear ear protection. Operating environmental temperature Max 45 º Do not incinerate battery pack Do not expose to water Keep all bystanders at least 50 feet away.
Page 8: Specifications
SETUP SPECIFICATIONS Rated voltage 20VDC Output power 400W Guide bar length 8"(200mm) Chain speed 7.5m/s Chain pitch 1/4" Oil can 35ml Net weight 2.6kg(5.7lbs) FUNCTIONS Front guard Guide bar Oil tank cap Saw chain Chain cover Machine body Safety lock button Switch button Operating handle Battery pack installation slot...
Page 9: Installation
SETUP INSTALLATION WARNING Do not change or make accessories that are not recommended by the manufacturer. WARNING Do not install battery pack until you assemble all the parts. Unpack the machine WARNING Make sure that you correctly assemble the machine before use. WARNING •...
Page 10: Install The Battery Pack
SETUP Install the battery pack WARNING • If the battery pack or charger is damaged, replace the battery pack or the charger. • Stop the machine and wait until the motor stops before you install or remove the battery pack. •...
Page 11: Operation
SETUP OPERATION NOTE: Remove the battery pack and keep hands clear of the lock out button when you move the machine. IMPORTANT: Examine the chain tension before each use. Examine the chain oil NOTE: Use bar and chain oil that is only for chains and chain oilers. a.
Page 12 SETUP Fell a tree Recommendation that the ﬁrst-time user should, as a minimum practice, start cutting logs on a saw-horse or cradle. Before you start to fell a tree, make sure that • The minimum distance between the areas of bucking and felling is two times the height of the tree.
Page 13 SETUP SETUP Limb a tree Limbing is the removal of the branches from a fallen tree. 1. Keep the larger lower branches to hold the log oﬀ the ground (8). 2. Remove the small limbs (9) in one cut. 3. Limb the branches with tension from the bottom to top. 4.
Page 14: Maintenance
MAINTENANCE MAINTENANCE CAUTION: Do not let brake ﬂuids, gasoline, petroleum-based materials touch the plastic parts. Chemicals can cause damage to the plastic, and make the plastic unserviceable. CAUTION: Do not use strong solvents or detergents on the plastic housing or components. Remove the battery pack from the machine before maintenance.
Page 15: Adjust The Chain Tension
MAINTENANCE Adjust the chain tension The more you use a chain the longer it becomes. It is therefore important to adjust the chain regularly to take up the slack. Tension the chain so that it can only just be pulled away from the bar at its center point.
Page 16: Guide Bar Maintenance
MAINTENANCE Guide bar maintenance NOTE: Make sure that it is turned over periodically to keep symmetrical wear on the bar. 1. Lubricate the bearings on the nose sprocket (if present) with the syringe (not included). 2. Clean the bar groove with the scraping hook (not included). 3.
Page 17: Transportation And Storage
TRANSPORTATION AND STORAGE TRANSPORTATION AND STORAGE Before you move the machine, always • Remove the battery pack from the machine. • Keep hands clear of the lock-out button. • Put the scabbard on the guide bar and the chain. • Before you put the machine into storage, always Remove all residual oil from the machine. •...
Page 18: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING...
Page 19 TROUBLESHOOTING TROUBLESHOOTING...
Page 20: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product 87366 LI-ION CORDLESS MINI CHAIN SAW Complies with the essential health and safety requirements of the following Directices: council directive 2006/42/EC Standards and technical speciﬁcations referred to: EN 62841-1:2015 "EN 62841-4-1:2020 and essential safety requirements of Machinery Directive...
