The document is intended for use by end-of-life recyclers or treatment facilities. It provides
the basic instructions for the disassembly of LG products to remove components and
materials requiring selective treatment.
Product Identification
Type of Product
Model name
Displays must be stored in accordance with the requirements stipulated in Appendix VII (1)
or (2) of Directive 2012/19/EU and must, amongst other things, be stored in a
weatherproof manner. Containers with covers must be used when storing and transporting
the Displays.
Contents
Dismantling information
Notebook
16Z90TL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 16Z90TL and is the answer not in the manual?

Questions and answers

Summary of Contents for LG 16Z90TL

  • Page 1: Table Of Contents

    Dismantling information The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions for the disassembly of LG products to remove components and materials requiring selective treatment. Product Identification Type of Product Notebook Model name...
  • Page 2: Materials And Components For Selective Treatment

    1. Materials and components for Selective Treatment Displays may contain hazardous substances like Pb which are covered by exemptions under the RoHS directive. However, the majority is present in the PCB assembly. In order to reduce emissions as much as possible, a complete disposal of the old appliance is required.
  • Page 3: Tools Required

    2. Tools Required List the type that would typically be used to disassemble the product to a point where components and materials requiring selective treatment can be removed. Tool Description Tool information Screw driver Nipper Plastic Hera Jig Hair Dryer...
  • Page 4: Product Disassembly Process

    3. Product Disassembly Process 1) Batteries Batteries can easily be removed from the PCB Assembly once the back cover of product has been removed. open D cover after remove screw sheet 7EA, rubber 2EA and screw 9pcs Remove battery after disconnect cable connector 1EA and remove screw 7pcs Cable...
  • Page 5 3. Product Disassembly Process 2) PCBs / SSD / Speaker / Fan / Power Button Remove screw with screw driver to disassembly SSD Disconnect connector 2EA to disassembly Speaker Cable Cable Disconnect connector 2EA and remove screw 3cs to disassembly Fan Cable Cable...
  • Page 6 3. Product Disassembly Process 2) PCBs / SSD / Speaker / Fan / Power Button Remove screw 5pcs with screw driver to disassembly heat pipe Disconnect connector 7EA and remove screw 5pcs to disassembly Main PCB Cable Cable Cable Cable Disconnect connector 3EA and remove screw 2cs to disassembly Sub-PCB &...
  • Page 7 3. Product Disassembly Process 3) Plastics containing Brominated Flame Retardants Plastic of speaker, cable connector, fan may contain brominated flame retardants, remove them all using a common available tool. 4) LCD module Remove screw 6pcs with screw driver to disassembly display assy Remove Bezel with disconnect hook and tape...
  • Page 8 3. Product Disassembly Process 4) LCD module Remove screw 3pcs with screw driver and disconnect hook to disassembly Hinge Cap Remove tape 4EA to disassembly LCD module Disconnect LCD connector 1EA Remove LCD panel to disassembly LCD module...
  • Page 9 3. Product Disassembly Process 5) Power cord and signal cables US/Canada Korea , EU Japan, Taiwan Type-C Cable (Charging Only) Adaptor 6) Capacitors > 25 mm Capacitors > 25 mm is no located in product.
  • Page 10: Disassembly Of External Enclosure

    4. Disassembly of External enclosure 1) Bottom case Tool Information open D cover after remove foot rubbers and screws...
  • Page 11 4. Disassembly of External enclosure 2) Key board deck Tool Information Remove battery after disconnect cable connector 1EA and remove screw 7pcs Disconnect connector 2EA to disassembly Speaker Cable Cable Disconnect connector 2EA and remove screw 3cs to disassembly Fan Cable Cable...
  • Page 12 4. Disassembly of External enclosure 2) Key board deck Tool Information Remove screw 5pcs with screw driver to disassembly heat pipe Disconnect connector 7EA and remove screw 5pcs to disassembly Main PCB Cable Cable Cable Cable Disconnect connector 3EA and remove screw 2cs to disassembly Sub-PCB &...
  • Page 13 4. Disassembly of External enclosure 2) Key board deck Tool Information Remove screw 6pcs with screw driver to disassembly display assy...
  • Page 14 4. Disassembly of External enclosure 3) Display Front Case Tool Information Remove front case with disconnect hook and tape Disassemble front case slowly using Hera to disassemble the Display Front Case...
  • Page 15 4. Disassembly of External enclosure 4) Rear Case Tool Information Remove screw 3pcs with screw driver and disconnect hook to disassembly Hinge Cap Remove tape 4EA to disassembly LCD module...
  • Page 16 4. Disassembly of External enclosure 4) Rear Case Tool Information Disconnect LCD connector 1EA to disassembly LCD module Remove cable to webcam for detaching camera module And remove screws to disassembly Hinges, LCD Cable, Antenna Cable...
  • Page 17: Exploded Diagram Of Parts

    5. Exploded Diagram of Parts 1) Keyboard deck 2) adaptor 3) Rear case...
