  • Page 1 Owner’s Manual...

  • Page 2: Specifications

    Thank you for supporting small manufacturing in the USA by purchasing the all-new 5th Generation Rhodan GPS Anchor. Since the development of our first GPS Anchor System in 1994, our goal has always been to provide our customers with quality tools to enhance their time on the water.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SYSTEM FEATURES ............4 POWERING UP THE UNIT ........... 4 HMI DISPLAY ..............5 DEPLOYING THE UNIT ............6 STOWING THE UNIT ............6 MODES OF OPERATION ............. 7 1. MANUAL MODE ............. 7 2. ANCHOR MODE ............. 8 3.

  • Page 4: System Features

    The system is equipped with a “Tilt” sensor that prevents the propeller from running in the stowed position. Rhodan Marine Systems • 1290 Sarasota Center Blvd • Sarasota, Florida 34240...

  • Page 5: Hmi Display

    HMI DISPLAY The display panel on the system will keep you up to date with important status information. This device uses electronic paper display technology to enhance visibility in direct sunlight while wearing polarized sunglasses. To maximize the display durability and image quality, the display will periodically flash a black/ white screen.

  • Page 6: Deploying The Unit

    Rhodan Marine Systems • 1290 Sarasota Center Blvd • Sarasota, Florida 34240...

  • Page 7: Modes Of Operation

    MODES OF OPERATION 1. MANUAL MODE The system will automatically be in manual mode when placed in the deployed position or the “M” or “STOP” buttons are pressed. The unit will emit 1 “beep” to indicate that it has entered Manual Mode. In the Manual Mode the GPS ANCHOR system behaves much like a conventional trolling motor, by allowing the user to control the direction and thrust level using the directional controls on the wireless fob.

  • Page 8: Anchor Mode

    The unit will emit a 1 second “beep” to indicate that the anchor site has been successfully saved. Rhodan Marine Systems • 1290 Sarasota Center Blvd • Sarasota, Florida 34240...
  • Page 9 RECALLING A STORED ANCHOR SITE From any mode, while holding down the “A” button, press and release the appropriate directional button. The “A” button can then be released and your boat will navigate in a straight line directly to that location and anchor at the selected, previously recorded site.

  • Page 10: Track Mode

    In this mode, the steering is automatic, but the thrust level is user selected. In extreme wind or current it is necessary for the user to select a speed setting with adequate thrust to overcome the disturbances and remain “on-track”. Rhodan Marine Systems • 1290 Sarasota Center Blvd • Sarasota, Florida 34240...

  • Page 11: Route Mode

    4. ROUTE MODE STORING (OR OVER WRITING) A ROUTE From any mode, simultaneously press and hold either the “M” or “T” button and one of the directional buttons for 5 seconds. The buttons can then be released and the system will now be in the function corresponding to the button you selected “M”...

  • Page 12: Appendix A: General Information

    Press the center button to select the highlighted option. Press the stop button to exit the current menu level. • CALIBRATIONS Highlight the desired calibration option and press the center button to initiate. • BACKLIGHT Rhodan Marine Systems • 1290 Sarasota Center Blvd • Sarasota, Florida 34240...
  • Page 13 Highlight the desired setting and press the center button to initiate. • STORE ANCHOR Highlight the desired memory location and press the center button to store the current coordinates. • LOAD ANCHOR Highlight the desired memory location and press the center button to recall. If the stored coordinates are within one mile of the present location, the system will make a beeline for the anchor location.

  • Page 14: Appendix C: Installation Checklist

    5. The system should now be secure on the mount and can be moved between the front and rear detent positions, but not beyond the travel limit stops. Rhodan Marine Systems • 1290 Sarasota Center Blvd • Sarasota, Florida 34240...

  • Page 15: Appendix E: Physical Installation

    6. Connect the power cable and (optionally) any NMEA2000 or Rhodan network cables. REMOVAL 1. Disconnect power and data cables.
  • Page 16 Once in position, use the marking pen to draw a line on the deck around the back of the quick release bracket. 24” CLEARANCE Rhodan Marine Systems • 1290 Sarasota Center Blvd • Sarasota, Florida 34240...
  • Page 17 4. Remove the system from the boat. Place the included mounting template on the deck and align it with the marks made in the previous steps. Use your pen to mark the locations of the mounting holes on the deck. 5.

  • Page 18: Appendix F: Electrical Installation

    Please make sure that the plug you install is rated for 60A, 48V, 36V or 24V (depending on model). Should you have dif- ficulty locating the appropriate plug, please contact Rhodan Marine Systems, and we will do our best to assist you.
  • Page 19 Once the appropriate plug is obtained, it will need to be installed on the power cord. Depending on the location of the socket relative to your system it may be appropriate to trim the main power conductor to a shorter length. If shortening the power cable, be sure to leave adequate length to complete the connection to the plug and allow for the plug to be inserted with a small amount of slack remaining.

  • Page 20: Appendix G: Propeller Installation

    4. Tighten the propeller nut using a 9/16” socket to 5 ft-lbs. 5. Be sure to periodically check the prop nut to ensure it is tight. Rhodan Marine Systems • 1290 Sarasota Center Blvd • Sarasota, Florida 34240...

  • Page 21: Appendix H: Calibrations

    APPENDIX H: CALIBRATIONS CENTERING CALIBRATION Note: This procedure is required and is normally only completed once at the time of the installation. It should also be performed every time the system is transferred to another boat or after a compass calibration. 1.
  • Page 22 8. The system will return to Manual Mode. The rotation may now be stopped. 9. A centering calibration may also need to be performed again to center the motor with the keel depending on the new compass calibration. Rhodan Marine Systems • 1290 Sarasota Center Blvd • Sarasota, Florida 34240...

  • Page 23: Appendix I: Fob Features

    APPENDIX I: FOB FEATURES REPLACING A WIRELESS FOB BATTERY The batteries in the wireless FOB should be capable of lasting a full fishing season or longer under normal usage conditions. If your system is powered up yet fails to respond to a FOB, or if you noticed decreased wireless range, try replacing the battery.

  • Page 24: Appendix J: Preventative Maintenance

    Failure to properly maintain the unit may void the warranty and can result in system damage, personal injury, and property damage. AFTER EACH USE 1. Remember to unplug and remove ALL electrical power sources from your Rhodan GPS Anchor prior to conducting maintenance or charging your battery system.

  • Page 25: Warranty

    WARRANTY This Limited Warranty (“Warranty”) is a voluntary manufacturer’s warranty by Rhodan Marine Systems of Florida, LLC. This Warranty applies to you only if you are the original purchaser of a Rhodan Marine Systems trolling motor (the “Product”) and you purchased the Product directly from Rhodan Marine Systems or an authorized Rhodan Marine Systems dealer.

  • Page 26: Important Safety Information

    3 years from the date of original purchase of the Product. Rhodan Marine Systems will either repair the defective part(s) or, at Rhodan Marine Systems’ option, replace the defective part(s) with the new or refurbished part(s), at Rhodan Marine Systems’ discretion, free of charge.

  • Page 27: How To Obtain Warranty Service

    Rhodan Marine Systems factory located in Sarasota, FL. Rhodan Marine Systems is not responsible for the removal or re- installation of the Product on your vessel. If the Product or any part is to be replaced, it must be returned to Rhodan Marine Systems before the replacement will be provided.

  • Page 28: Customer Service

    1-941-706-4578 Rhodan Marine Systems 1290 Sarasota Center Blvd Sarasota, Florida 34240 ©2025, Rhodan Marine Systems. All rights reserved. Rev. 051225 w w w . r h o d a n m a r i n e . c o m...
