Installer Guide
SG810ZB Slim Profile Gateway
1 INTRODUCTION 2 FEATURES 3 LED INDICATOR STATUS
4 INSTALL THE APP
7 SET TO WIFI 8 CHECKING SYSTEM CONFIGURATION
Read these instructions before installing and using the Gateway.
Verify compatibility with your connected home system before installation.
Follow all instructions provided by your connected home manufacturer regarding
the addition of devices to your connected home system. An authorized, qualified
installer may be required.
Salus accepts no responsibility for damage caused by not following these
instructions.
5 INSTALLATION 6 SCAN FOR DEVICES
9 FACTORY RESETTING THE DEVICE
Store this manual for future reference
SG810ZB-110-02
Advertisement
Table of Contents
Related Manuals for Salus SG810ZB
Summary of Contents for Salus SG810ZB
- Page 1 Follow all instructions provided by your connected home manufacturer regarding the addition of devices to your connected home system. An authorized, qualified installer may be required. Salus accepts no responsibility for damage caused by not following these instructions. Store this manual for future reference...
- Page 2 1. INTRODUCTION The Slim Profile Gateway is the key product for the SALUS Smart Home and supports cloud integration to AWS IoT and other cloud platforms with firmware customization. This will offer you an ideal solution for connecting multiple Zigbee wireless devices to the cloud in a smart home system by using your smartphone or your computer via Internet.
-
Page 3: Led Indicator Status
Gateway is connected to the LAN/WiFi internet Gateway is not connected to the LAN/WiFi internet As the SG810ZB is being provisioned, the LEDs will have different patterns to show the current connection and operational status. See details in the INSTALLATION section. User Guide... -
Page 4: Install The App
4. INSTALL THE APP This product requires the SALUS Smart Connect application. Download and install the SALUS Smart Connect App. Download the App from the Google Play or Apple Store. A desktop version is also available at https://us.salussmartconnect.com/ Follow the instructions in the app to sign up for an account. -
Page 5: Installation
5. INSTALLATION Online mode - using Ethernet cable (with Internet connection via SALUS Smart Connect app) Apply power Connect Ethernet cable After the gateway has been connected to the router and powered up, please wait until all the LEDs are green. - Page 6 Search for and Add a Gateway Launch the App and Sign In Tap ‘Hamburger Tap ‘Devices’ Tap ‘Add a Tap ‘Connect via menu’. Tap ‘Gateways’. gateway’. LAN’. Tap the Gateway Tap ‘Search for Tap ‘Allow’. button (~1s). Gateway’. 1 Sec Zigbee LED will blink.
- Page 7 Fill in all the fields. Tap ‘Activate my Once activated, the Gateway’. * three LEDs will be solid green. * This process may take up to 6 minutes Once the gateway is activated, the application will automatically go to the Dashboard.
- Page 8 Installation in Online mode - using Bluetooth (with WiFi connection via SALUS Smart Connect app) Allow Gateway to boot. LEDs should appear as below. Apply power to the Gateway. Once the Gateways has booted, Sign In to the App, then Add a Gateway.
- Page 9 Tap the Gateway Tap ‘Setup with Tap ‘Pair’ to allow button (~1s). Bluetooth’. Bluetooth pairing. 1 Sec Zigbee LED will blink. Tap desired WiFi Enter WiFi password. Allow Gateway to network. Tap ‘Provision’. complete set up. User Guide...
- Page 10 Fill in all the fields. Tap ‘Activate my Once activated, the Gateway’. * three LEDs will be solid green. * This process may take up to 6 minutes Once the gateway is activated, the application will automatically go to the Dashboard.
- Page 11 Note: Refer to individual device manuals before starting the installation process. To replace or add new devices, repeat the steps above. If you want to change Offline mode to Online mode, you must use the SALUS Smart Connect Application to scan for the equipment.
-
Page 12: Scan For Devices
6. SCAN FOR DEVICES (Using the SALUS Smart Connect App) Add devices to the SALUS mesh network using either the mobile or desktop SALUS Smart Connect Application. • Launch the App. • Sign In. • The App will open to the dashboard. - Page 13 Be patient as the Gateway scans for devices set for Pairing mode. Gateway is scanning Tap ‘checkboxes’ to for devices. select devices to add. Give each device a Tap ‘Finish’ to complete meaningful name. Tap the intstallation. Next to save. User Guide...
- Page 14 7. SET TO WIFI To change the connectivity from LAN to WiFi, follow the below steps. • WiFi SSID: the name of your network (Case sensitive) • WiFi Password: the password of your network • Note: The WiFi Internet connection might not be as stable as the one on cable. User Guide...
-
Page 15: Checking System Configuration
To check which devices are paired with your system and have been configured correctly, you can use Identify mode. Press the button to activate Identify mode. The SG810ZB gateway will put all equipment that is connected to your system into Identify mode. Identify mode will time out after 10 minutes. -
Page 16: Factory Reset
9. FACTORY RESET Restoring factory settings in the SG810ZB gateway will delete all settings and devices paired with it from its memory. To do this, use paper clip or a pin to press and hold the button for about 10 seconds until all LED’s glows orange and release Online: Offline:... - Page 17 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 18: Limited Warranty
Braeburn Systems LLC 2215 Cornell Avenue Montgomery, IL 60538 Braeburn Systems LLC 2215 Cornell Avenue • Montgomery, IL 60538 Technical Assistance: www.braeburnonline.com Call us toll-free: 866-268-5599 (U.S.) 630-844-1968 (Outside the U.S.) User Guide ©2024 Braeburn Systems LLC All Rights Reserved. SG810ZB-110-02 Ä...
