Evident FV31-AUXOUT Instructions Manual

Universal analog output unit
Hide thumbs

Advertisement

Table of Contents

Instructions
FV31-AUXOUT
Universal analog output unit
Notes
This instruction manual is for the FV31-AUXOUT (Universal analog output unit).
To ensure safety, obtain optimum performance and to familiarize yourself fully with the use
of this product, we recommend that you study this manual thoroughly before operating this
product, and always keep this manual at hand when operating this product.
Optical Microscope Accessory
Retain this instruction manual in an easily accessible place near the work desk for future
reference.
AX9299

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FV31-AUXOUT and is the answer not in the manual?

Questions and answers

Summary of Contents for Evident FV31-AUXOUT

  • Page 1 Universal analog output unit Notes This instruction manual is for the FV31-AUXOUT (Universal analog output unit). To ensure safety, obtain optimum performance and to familiarize yourself fully with the use of this product, we recommend that you study this manual thoroughly before operating this product, and always keep this manual at hand when operating this product.
  • Page 2 In accordance with European Directive on Waste Electrical and Electronic Equipment, this symbol indicates that the product must not be disposed of as unsorted municipal waste, but should be collected separately. Refer to your local Evident distributor in EU for return and/or collection systems available in your country. Research Use Only This system is categorized as FCC Part15 Class A exempt system.

  • Page 3: Table Of Contents

    - ....1 Be sure to read this section for safe use of the equipment. 1 Features and specifications of FV31-AUXOUT (universal analog output unit) ..3 2 Setting procedures (Maintenance) ..................4 3 Output timing by scan mode (Operation) ................. 6 Synchronizing signal output timing by scan mode ..................6...

  • Page 4: Safety Precautions

    FV31-AUXOUT IMPORTANT - Be sure to read this section for safe use of the equipment. This product is used for FV3000(confocal laser scanning microscope). Safety precautions If the product is used in a manner not specified by this manual, the safety of the user may be imperiled. In addition, the product may also be damaged.

  • Page 5: Handling Precautions

    Also, if you use a Class B product or equipment intended to be used for residential environment together with this system, malfunction may occur. · Before disposing of this product, check your local laws, rules, and regulations and follow them accordingly. Contact Evident for any questions.

  • Page 6: Features And Specifications Of Fv31-Auxout (Universal Analog Output Unit)

    FV31-AUXOUT Features and specifications of FV31-AUXOUT (universal analog output unit) Features Two types of signals can be outputted by synchronizing them with operations of this system. Specifications Item Specifications Synchronization signal Output channel number: 2ch (ANALOG, DIGITAL) output specifications For details on the synchronization signal, [3 Output timing by scan mode (Operation)].

  • Page 7: Setting Procedures (Maintenance)

    · Do not change the settings of the DIP switch on the surface opposite to the surface with output connectors. Connection Be sure to turn OFF the powers of FV31-AUXOUT (universal analog output unit) and external devices before connecting devices. The power of FV31-AUXOUT (universal analog output unit) is automatically turned OFF when FV31-PSU (power...

  • Page 8: Output Timing By Scan Mode (Operation)

    FV31-AUXOUT Output timing by scan mode (Operation) Synchronizing signal output timing by scan mode The relation between the scan operation and the synchronizing signal output in each mode is illustrated below. XY (Region) scan Scanner trajectory Imaging (or stimulation) zone...
  • Page 9 FV31-AUXOUT Resonant XY scan Scanner trajectory Imaging zone Start SCAN 1 Line 1 Frame Last frame 7usec 6usec 12usec DIGITAL...
  • Page 10 FV31-AUXOUT Line scan Scanner trajectory Imaging (or stimulation) zone Start SCAN 1 Line 10usec 2usec DIGITAL...
  • Page 11 FV31-AUXOUT Free line scan Scanner trajectory Imaging (or stimulation) zone Start SCAN 1 Line 10usec 2usec DIGITAL...
  • Page 12 FV31-AUXOUT Point scan Scanner trajectory Imaging (or stimulation) zone Start SCAN Point 2usec 10usec DIGITAL DIGITAL...
  • Page 13 FV31-AUXOUT Multi point scan Scanner trajectory Imaging (or stimulation) zone Start SCAN 1 Cycle DIGITAL 10usec DIGITAL The settings of the number of pulses and the pulse width can be changed per point by FV31S-SW.
  • Page 14 FV31-AUXOUT Tornado scan Stimulation zone Start SCAN DIGITAL 10usec 20usec DIGITAL DIGITAL...

  • Page 15: Specifications

    FV31-AUXOUT Specifications Item Specifications FV31-AUXOUT Dimension 250 (D) x 240 (W) x 68 (H) mm (excluding protrusions) Weight 2.1 kg Universal analog output unit Operating environment • Indoor use • Altitude : Max. 2,000 meters • Ambient temperature : 18 to 28 °C Fluctuation range : ±2.5 °C •...
