Summary of Contents for nova hüppe Trend 200
- Page 1 Nova Hüppe Trend 200 - multisectional Instructions for assembly and electric installation...
-
Page 2: Table Of Contents
Trend 200 UGM multisectional Instructions for assembly and electric installation Contents 1. Safety instructions ..............................2 2. Before going to the construction site ........................2 3. Tools required for assembly ............................. 2 4. Qualifications ................................2 5. Transport................................... 3 6. Lifting using ropes ..............................3 7. -
Page 3: Safety Instructions
Should one of these qualifications not be available, a specialised company must be commissioned. Electrical works: Electrical fixed installation must be carried out by an authorised electrician according to VDE 100. The enclosed installation instructions for the provided electrical appliances must be followed. Nova Hüppe GmbH Trend 200 multisectional Page 2 of 16... -
Page 4: Transport
Fastening elements, such as screws, discs and bolts, are not within the scope of delivery of the awning. The awning meets the requirements of the wind resistance class stated in the CE conformity marking (see operating manual). Nova Hüppe GmbH Trend 200 multisectional Page 3 of 16... -
Page 5: Mounting Brackets
To that end, unscrew the clamp bolts (1) by 2-3mm, so that the rail can engage. Make sure the guide rail holding clamps are aligned. You can laterally adjust them if required. Nova Hüppe GmbH Trend 200 multisectional Page 4 of 16... -
Page 6: Mounting The Awning Casing
• Unscrew the base and put it aside. Boden • Loosen the set screws (6) of the coupling and pull the coupling apart. (Only for two awnings with one motor) Nova Hüppe GmbH Trend 200 multisectional Page 5 of 16... - Page 7 • Carefully mount the awning casing. • Attach the supplied cranks to the drive rods, or connect the motor to a sensing wire. • Let the front rail extend some 10cm Nova Hüppe GmbH Trend 200 multisectional Page 6 of 16...
-
Page 8: Coupling Of Awnings (Only For 2 Awnings With 1 Motor)
(2). • Insert the wheels (3) of the front rail pins into the provided groove of the guide rails (4). Nova Hüppe GmbH Trend 200 multisectional Page 7 of 16... -
Page 9: Mounting The Pull Straps
In order to unlock the pull straps, remove the small plugs (5) from the side caps, insert a screwdriver into the lower opening of the roller units and press it up. Close the openings using the plugs. Caution: Pull straps are under tension! Nova Hüppe GmbH Trend 200 multisectional Page 8 of 16... -
Page 10: Fitting Of Guide Rails (Guide Rail Holding Clamps)
(3) using a Torx screw driver of size 9. • Clip the shell sleeve (4) into the groove of the base. • Proceed in the same way with the next base. Nova Hüppe GmbH Trend 200 multisectional Page 9 of 16... -
Page 11: Support Wire Tensioner
Tighten the clamp screws (7) using a 2.5mm Allen key. Use the tensioners evenly on the right and left on the screws of the support wire brackets. Successively turn the tensioners until the support wire is taut. Nova Hüppe GmbH Trend 200 multisectional Page 10 of 16... -
Page 12: Test Run
When awnings are operated by more than one user, a priority switched locking device (controlled external power interruption) that prevents any extension or retraction of the awning must be installed. Nova Hüppe GmbH Trend 200 multisectional Page 11 of 16... -
Page 13: Contusion- And Shearing Points
Switches for awning motors must under all circumstances be electrically and mechanically locked. Never connect more than one motor to a single-pole switch! Only group controls allow the operation of more than one motor with one switch. Nova Hüppe GmbH Trend 200 multisectional Page 12 of 16... -
Page 14: Control Instructions For Tube Motors
All damages brought about by the described causes usually occur after a certain operating period, as the limiting switches resist the stresses a few times only. All these points are taken into account with regard to the supplied controls. Nova Hüppe GmbH Trend 200 multisectional Page 13 of 16... -
Page 15: What If
The front rail is bent Possible causes are: Tension is too high on both sides. Solution: Check the tension (see point 19) Remove one winding of the pull straps from the belt disc. Nova Hüppe GmbH Trend 200 multisectional Page 14 of 16... - Page 16 Solution: Readjust the stop point of the motor according to the supplied adjustment instructions. Beyond a certain projection and width a support wire should be used. Solution: Fit the support wire as described in points 14, 17 and 22. Bespannung Nova Hüppe GmbH Trend 200 multisectional Page 15 of 16...
-
Page 17: Exploded View
33.Exploded view Kupplung Kupplung Motor innen 33.74.000 33.75.000 33.74.010 33.74.010 82.92.306 82.92.306 33.74.100 82.97.304 33.30.100(R) 82.92.306 33.30.105(L) 32.74.100 33.50.000 82.45.402 33.50.010 82.97.304 82.84.301 82.92.306 33.30.105 32.30.170 33.30.005 82.92.306 33.60.010 33.20.000 32.72.000 33.90.xxx 33.70.000 33.30.100 33.30.000 74.80.600 33.60.020 33.20.000 74.80.200 22.75.050 82.93.103 32.11.000 22.75.060... - Page 18 www.novahueppe.de Nova Hüppe GmbH Sun protection systems Schmiedeweg 4+6 26135 Oldenburg info@novahueppe.de...
