FLINT HILL FHG25VR Instruction Manual

FHG25VR
Adjustable
Ball Mount
Instruction Manual
Application
Maximum Capacity
Hitch Pin required to at-
tach Ball Mount shank to
tow vehicle's receiver
Hitch Ball Opening
READ AND UNDERSTAND THIS ENTIRE MANUAL BEFORE ASSEMBLING,
INSTALLING, OPERATING, OR SERVICING THIS PRODUCT. SAVE THIS MANUAL.
Copyright © 2022 by Flint Hill Goods. All rights reserved. No portion of this manual or any artwork contained herein
may be reproduced in any shape or form without the express written consent of Flint Hill Goods. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for assembly and
maintenance may not be included.
LIT-00408, Rev -
Fits 2"x 2" Receivers;
Class III
Rise: 3-3/4" to 8-1/4"
Drop: 5" to 9-1/2"
5,000 Lbs. Gross Trailer
Weight;
500 Lbs. Tongue Weight*
5/8" Diameter Steel with
R-Shaped Safety Clip -
both not included
1" Diameter; Hitch Ball
sold separately
Too much tongue weight exerted on the hitch ball can lower the tow
vehicle in the back and overload tow vehicle's rear tires, resulting in
traction, steering and braking problems.
Not enough weight on the trailer tongue can reduce tow vehicle's rear
tires, resulting in traction, steering and braking problems.
Do not exceed the maximum weight ratings shown in the Specifcations
table above.
Do not exceed the rating of the lowest rated component in the
vehicle/trailer set-up.
Safety chains between the towing vehicle and the trailer are
always required.
Tongue Weight is the static force the
trailer toungue exerts on the hitch ball.
Loading a trailer correctly to maintain a
proper trailer tongue weight is critical for
towing safety and good trailer handling.
Do not exceed 500 Lbs. Tongue Weight
Capacity while using this Adjustable Ball
Mount. Read additional instructions on
Page 5 for determining the tongue weight
of your loaded trailer.
