- Page 1 ALIBUS series intelligent switch driver Installation instruction manual V1.0 Jiangsu Acrel Electric MFG. Co., Ltd.
- Page 2 Declare All rights reserved, without the written permission of the company, any paragraphs and chapters in this manual shall not be extracted, copied, or spread in any form, otherwise all the consequences shall be borne by the violators. The company reserves all legal rights. The company reserves the right to modifications to the product specifications described in this manual without notice.
-
Page 3: Table Of Contents
Contents 1. Summary ....................1 2.Product model ..................1 3.Main technical parameters ............... 1 4. Installation and wiring ..............2 5. Use the operational guidelines ........... 5 6. Functional application ..............12 6.1 The heartbeat message ............12 6.2 General functions ..............12 6.3 Scene function ................. - Page 4 7.3.4 Event record address table ........23 8. Common fault analysis and troubleshooting ......25 9. matters need attention ..............25...
-
Page 5: Summary
1. Summary ASL2XX series switch driver (module for short) is the control module of Acrel ALIBUS intelligent lighting control system. This module connects with other devices (such as smart panel, sensor, etc.) to establish a complete set of lighting control system to realize intelligent management of large public buildings lighting systems. -
Page 6: Installation And Wiring
2 Passive dry contacts On-off signal data input 2 passive normally open contacts，AC 220V/1A ，DC 30V/1A On-off signal data Output ALIBUS、Modbus-RTU Communication Installation Standard 35mm DIN rail mounting Operating temperature：-10℃-+55℃；Humidity：≤95% Environmental requirements -20℃-+70℃ Temperature range Button+LCD display Local operation display Voltage Current 、... - Page 7 ASL220Z-S12/16 288mm ASL220Z-S16/16 360mm ASL220Z-S20/16 432mm ASL220Z-S24/16 504mm 4.2Electric wiring diagram ASL220Z-Sx/16（ASL220-Sx/16） Figure3 ASL220Z-Sx/16 schematic diagram of the switch driver wiring Figure 3 shows the wiring diagram of the 4-way switch driver. In practical use, the 4,8,12,16,20,24 switch driver wiring is similar, which are not listed here. ①...
- Page 8 ⑥ Running indicator ⑦ Button:menu button MENU, left button , right button , enter button and turn page button in turn ⑧ ALIBUS terminal ⑨ RS485 Communication and DI/DO terminal...
-
Page 9: Use The Operational Guidelines
⑩Voltage measurement terminal:The ASL220Z series switch drive is unique 5. Use the operational guidelines Figure5 Schematic diagram of panel 5.1 Indicator definition 5.1.1 Light lingt of main module... - Page 10 ASL220Z-Sx/16（ASL220-Sx/16） Running indicator Flash （when the module is on working， the flashing frequency is about once a second） （green） Flash （ module indicator flashes once during ALIBUS Communication communication） indicator（green） Eternal light（when the bus is crowd） DI（red） Eternal light（detect DI signal input ） DO（red）...
- Page 11 In the control mode, short press can make the channel fully closed or fully Short press opened Press and hold the button for 3s to enter the control mode; Press and hold for 3s again to exit the control mode Long press It will automatically exit the control mode after 15s of no operation 5.3 LCD display...
- Page 12 interface. You can control the connecting and disconnecting of the channel of the slave module. The interface displays the channel to be controlled and the control status. After the test, press the MENU menu button to exit. Note: Channel 00 represents all channels, channel 01 represents the first channel, and so on. 5.3.2 Information query In the status display interface, press the page turn button to enter the information query interface, press the left or right button to switch records, and press the Enter button to enter.
- Page 13 to enter the next menu for setting. After entering password correctly, press Enter button to enter In the Time Setting interface, you can modify or set the year, month, day, week (Sunday is represented by 0), time, time zone, longitude and latitude; press the left or right button continuously After setting, press the MENU buttonto return until when ask you whether to save the...
-
Page 14: Press The Enter Button
connecting, and off indicates timing to channel disconnecting); The second interface can set or modify the channel to be controlled (1 means to enable the channel, 0 means not to enable the channel change the state). After setting, press the MENU button to return until whether to save the setting interface. At this time, press the left or right button to select whether to save the data. - Page 15 connecting, and channel state when reciving signal. If you only need to enable the linkage function of some channels, you need to enter the second interface to set the channels to be controlled (1 means channel is enabled to change, 0 means channel is disabled to change).
-
Page 16: Functional Application
ALIBUS. Press the left or right button 3）Other settings Press the MENU button to enter the programming password interface: press the page turning button and the left or right button to enter the user password (the default password is 0001), and then press the Enter button to enter. -
Page 17: Newsletter Guide
Time control group address can be set in 3, range: 0-65535 7. Newsletter guide 7.1 Interface Overview The switch drive supports RS485 communication and uses Modbus-RTU to communicate with our EMS integrated energy efficiency management system or third-party platform protocol. Default communication settings: address is 001 and port rate is 9600. -
Page 18: Introduction To The Function Code
7.2 Introduction to the function code 7.2.1 Function code 03H: Read register This function allows the user to obtain the data collected and recorded by the device and the system parameters. There is no limit to the number of data requested by the host at a time, but it cannot exceed the defined address range. -
Page 19: Drive Parameter Address Table
The following example is a small power switch driver with address 001 and baud rate 9600, channel 1-16 writes closed operation, namely 0009H writes FFFF. transmit informat Return from the return Host sent machine information transmit ter data address code address code high high... - Page 20 address is reserved The 0-6 stands for Sunday- 0x0003 high -Saturday week uint8 level Note: Series 210 this address is reserved 0x0003 low obligate uint8 level No input for bit0=0, and With bit0=1, DI1 has input 0x0004 on-off input No input for bit1=0, and uint16 that for DI2 Bit 1 = 1, and DI2 has...
-
Page 21: Parameter Setting Address Table
and so on The bit0-bit7 indicates the channel 17 – 24 and the maximum channel 24 0x000A Bit 0 = 0: channel 17 Write to the 11-12 points uint32 fractional state bits and the like bit0-bit15 indicates channel 0x000B 1-16; bit0 = 0: channel 1; and so on 0 points, 1 close, 0xFFFF means that the loop is not... - Page 22 not enabled Bit 0 = 1: Enable channel 17 and the like Bit 0-bit15 indicates channel 1-16; bit0 = 0: Channel 1 is not enabled 0x0106 Bit 0 = 1: Enable channel 1 and the like The bit0-bit7 indicates the channel 17-24; the maximum channel 24 Bit 0 = 0: channel 17 0x0107...
-
Page 23: Timing Address Table
Bit 0 = 0: Channel 1 is not enabled Bit 0 = 1: Enable channel 1 and the like Note: Series 210 this address is reserved The bit0-bit7 indicates the channel 17-24; the maximum channel 24 Bit 0 = 0: channel 17 points 0x010C Bit 0 = 1:10 close the... - Page 24 (points) The bit0-bit7 indicates the channel 17-24; the maximum channel 24 0x1006 Bit 0 = 1:17 channel enabled timing Bit 0 = 0: Channel 17 does Timing task 1 not enable by analogy uint32 circuit setting Blot 0-bit15 indicates lanes 1 –...
- Page 25 63-66 0x103E-0x1041 The specific register meaning can refer to the timing task 1 67-70 0x1042-0x1045 The specific register meaning can refer to the timing task 1 71-74 0x1046-0x1049 The specific register meaning can refer to the timing task 1 75-78 0x104A-0x104D The specific register meaning can refer to the timing task 1 79-82...
- Page 26 (points) Timing task 1 Operation 0x1104 low level operate setting: 00: minutes / 01: uint8 close Appointment timing task 2 Please refer to the reservation timing 6-10 0x1105-0x1109 task 1 Appointment timing task 3 Please refer to the reservation timing 11-15 0x110A-0x110E task 1...
- Page 27 116-120 0x1173-0x1177 Appointment timing task 24 Please refer to reservation timing task 1 7.3.4 Event record address table 7.3.4.1 Record address table of opening machine Note: 210 Series this feature is not available number address parameter Read / scale type write 0x1200 high level year...
- Page 28 7.3.4.2 DIDO Record address table Note: 210 Series this feature is not available number address parameter Read / scale type write 0x1300 high level year 0-99 uint8 0x1300 low level moon 1-12 uint8 0x1301 high level 1-31 uint8 0x1301 low level time 0-23 uint8...
- Page 29 0 Points, 1 0x1404 low level uint8 When the control command comes from the ALIBUS, representing the control group address Control group 0x1405 uint16 0x0001 represents the address control group address 1; 0xFFFF represents the control group address 65535; and so on 7-12 0x1406-0x140B Switch record 2.
- Page 30 Amendant record Revised edition Revision time Revised terms V1.0 2023/11 The new version was released...
- Page 31 Address: No.253 Yulv Road Jiading District, Shanghai，China TEL.: 0086-21-69158338 0086-21-69156052 0086-21-59156392 0086-21-69156971 Fax: 0086-21-69158303 Web-site: www.acrel-electric.com E-mail: ACREL008@vip.163.com Postcode: 201801 Manufacturer: Jiangsu Acrel Electrical Manufacturing Co., LTD. Address: No.5 Dongmeng Road,Dongmeng industrial Park, Nanzha Street,Jiangyin City,Jiangsu Province,China TEL：0086-510-86179966 Fax：0086-510-86179975 Web-site: www.jsacrel.com Postcode: 214405...
