Operation and Service Manual
for HERMetic Sampler GT-Strd
Portable Closed Sampling Device
Note: before using the instrument
please read this book.
This document is subject to changes without notice.
Check updates on
www.tanksystem.com
or contact us at
tanksystem@honeywell.com
50404/SGT/2110
1
HERmetic Samplet GT
Advertisement
Table of Contents
Related Manuals for Honeywell HERMetic GT-Strd
Summary of Contents for Honeywell HERMetic GT-Strd
- Page 1 Operation and Service Manual for HERMetic Sampler GT-Strd Portable Closed Sampling Device Note: before using the instrument please read this book. This document is subject to changes without notice. Check updates on www.tanksystem.com or contact us at tanksystem@honeywell.com 50404/SGT/2110 HERmetic Samplet GT...
-
Page 2: Table Of Contents
1 Table of contents TABLE OF CONTENTS RECOMMENDATION FOR SAFE USE GENERAL INFORMATION 3.1 S HIPMENT NOTE 3.2 I NITIAL INSPECTION 3.3 D OCUMENTATION DISCREPANCIES 3.4 W ARRANTY 3.5 C ERTIFICATION 3.6 S PARE PARTS 3.7 S ERVICE AND EPAIR 4. - Page 3 DRAWINGS & DECLARATION OF CONFORMITY 9.1 S AMPLER 9.2 V ALVES 9.3 D ECLARATION OF ONFORMITY 50404/SGT/2110 HERmetic Samplet GT...
-
Page 4: Recommendation For Safe Use
2 Recommendation for safe use According to TSB_7031_E , Issue 3 of October 3, 2019 1. This Operation and Service Manual is a guide in order to help the user to operate the device safely and correctly. 2. Nevertheless the maker disclaims all responsibility and liability for damage resulting from the use of the equipment regardless of the cause of the damage. - Page 5 9.2.2.1. The instrument is properly grounded and earthed before the probe is inserted into the tank and remains earthed until the probe has been removed from the tank. 9.2.2.2. The apparatus is not introduced into a tank until at least 30 minutes have elapsed after completion of any loading operation or stopping the injection of inert gas.
-
Page 6: General Information
3 General information Shipment note When returned to Enraf Tanksystem SA or agreed Service Stations The following parts should be included in the equipment must be contamination-free. If it shipment: determined that Purchasers equipment is contaminated, it will be - 1 instrument; returned Purchaser - 1 Allen key 1.3 mm;... -
Page 7: Certification
: +41-26-91 91 500 Telefax : +41-26-91 91 505 Web site www.tanksystem.com E-mail Tanksystem@honeywell.com Spare parts Substitution of components may impact safety. Use only original spare parts. When ordering spares identify the spare part by TS number and description. Refer to section “Drawings”. -
Page 8: Service Request Form
Service Request Form Goal of this document: To give to the service team all information for a safe, fast and economical handling of your service request. Please fill it out and join this document with the goods to repair. RMA* n°: QN n°... - Page 9 COUNTRY ADDRESS TELEPHONE / FAX / E-MAIL HONEYWELL ENRAF TANKSYSTEM SA Tel : +41-26-91 91 500 SWITZERLAND Rue de l’Industrie 2 Fax : +41-26-91 91 505 1630 BULLE E-mail : tanksystem@honeywell.com Tridente Brasil Tel : +55 21 2233 1489 BRAZIL Rua Jeronimo de Mendonça, 186...
-
Page 10: Description
5 Description 5.1 General The HERMetic Samplers are designed for closed sampling of liquids or chemicals, which present a Fire-, Health- or Air pollution Hazard. The gas tight construction of these units avoids a pressure release from the tank and exposure to fumes during operation. The equipment is designed and certified for use in potentially explosive atmospheres area. -
Page 11: Sampling Principle
5.3 Sampling principle 5.3.1 Connection and grounding system All HERMetic products are easy to connect. Indeed, all HERMetic devices are equipped with a quick coupler for connection on a HERMetic ball valve. Place the unit on the appropriate valve and activate the locking system. Depending on the locking system, either rotate the collar and actuate the lever or pull on the sleeve. -
Page 12: Sampling Method
5.3.2 Sampling method The sample is taken by a vertical move of the bottle inside the fluid. The bottle is linked with a graduated tape. A reading window allows to monitor the bottle location. For complete explanation of sampling procedures, please refer to §6 “Operation”. Important note: to avoid contamination of the sample taken by the sampler itself, check and clean the unit and the bottle prior to use. -
Page 13: Operation
6 Operation 6.1 Checking before use Before using the sampler : • Check the good state of the device. • Check the proper operating of the crank handle. Ensure the locking finger of the crank handle is operated freely by its spring and is placed in a locking position. •... - Page 14 6.2 OPERATING SAMPLER GT with ZONE SAMPLING BOTTLE : DESCRIPTION 30329 10380 Zone Bottle 0,43 l. Viton assy Install sampler with sampling bottle on top of 2” valve by means of quick connect coupling. (In case air in sampler housing could cause contamination in tank it is recommended to purge sampler after it has been installed).
- Page 15 6.3 OPERATING SAMPLER GT with BOTTOM SAMPLING BOTTLE: DESCRIPTION 20246 20124 Bottom bottle 0.40 l FKM assy Install sampler with sampling bottle on top of 2” valve by means of quick connect coupling. (In case air in sampler housing could cause contamination in tank it is recommended to purge sampler after it has been installed).
- Page 16 6.4 OPERATING SAMPLER GT with SPOT SAMPLING BOTTLE: DESCRIPTION 20255 20137 Spot bottle 0.40 l. FKM Install sampler with sampling bottle on top of 2” valve by means of quick connect coupling. (In case air in sampler housing could cause contamination in tank it is recommended to purge sampler after it has been installed).
- Page 17 6.5 OPERATING SAMPLER GT with RUNNING SAMPLING BOTTLE: DESCRIPTION 20254 20138 Running bottle 0.40 l. FKM Calibration plug on top of running bottle has to be adjusted according Calibration to liquid to be sampled. The plug is properly set up when the Plug transferred quantity of liquid falls between 70 and 85% of the capacity of the sampling bottle, i.e.
-
Page 18: Care And Maintenance
7 Care & Maintenance 7.1 Safety warning As this equipment has been certified as non-electrical equipment for potentially explosive atmospheres. Specific precautions have to be taken regarding maintenance of the device. The user can exchange parts and modules if following points are observed : 1. -
Page 19: Cleaning Of The Sampler
7.3 Cleaning of the sampler It is required to fit the cleanliness level with the sample goals. Having friction between parts, metallic dust may be generated. Assess its potential impact on the sample taken. To limit it and ensure an easy winding/unwinding of the tape, consider the periodical maintenance operation of section 7.4 Winding action becoming stiff. -
Page 20: Bearings
7.7 Bearings Bearings are involved in the electrical safety of this device. In case of exchange, use only original spare parts. 7.8 Storage of HERMetic devices For a proper storage of HERMetic products (UTImeter, Sampler, Thermometer and related spare- parts…), we recommend: Clean the devices after use, Remove batteries for prolonged storage, Store batteries in a dry and cold location,... -
Page 21: Specifications
8 Specifications General Specifications Tape length up to 35 m/115 ft Tape graduation Metric/English Tape resolution 1 mm / 1/16” Tape accuracy ±6.3mm/35 m (±1/4”/115 ft approx.) Maximum tank pressure Atmospheric pressure ±0.3 bar (4.4 psi) Liquid density up to 8kg/dm³ Ambient temperature range -20°C to 80°C (-4°F to 176°F) Maximum liquid temperature... -
Page 22: Valve
9 Drawings & Declaration of Conformity These documents are enclosed in following pages. 9.1 Sampler O = Option, according to specific order. DESCRIPTION 20189 10047 Sampler 2” GT Viton assy 30235 10358 Plug Viton assy 20280 10315 Carter winder FKM assy 30592 10317 Body assy... - Page 27 5(9,6,216 0RGLILFDWLRQ 'DWH 9LVD 0pFDQRVRXGp! IRQWH LQR[ $7(; &HUWLILHG 3URGXFW 1R PRGLILFDWLRQV SHUPLW WHG ZLWKRXW WKH DSSURYDO RI WKH DXWKRULVHG SHUVRQ ,WHP 4W\ :HLJKW 'HVFULSWLRQ 0DWHULDO &UDQN FDVWHG &)0 )LQJHU %HDULQJ [ [ %URQ]H %DOO ¡...
- Page 34 ATEX Certified Product No modifications permit- ted without the approval of the "authorised person" Item Qty Weight Description Material 113.1 Seat 1.4435 20049 40592 24.7 Bottom valve PTFE 20050 41062 4.2 Valve screw PVDF 20051 40593 0.3 O-Ring ø 34.65 x 1.78 20539 TOLERANCES UNLESS OTHERWISE SPECIFIED Weight:...
-
Page 44: Eu Declaration Of Conformity
Declaration of Conformity Issue: 6 TSB_7021_E.docx Author: QD December 18, 2020 1 of 3 EU DECLARATION OF CONFORMITY EU-KONFORMITÄTSERKLÄRUNG / DÉCLARATION UE DE CONFORMITÉ Product: HERMetic Sampler Type GT / GT Chem / GTX Chem Produkt: / GTN Chem / A4 / GT4 Produit: Object of the declaration: Gegenstand der Erklärung:... - Page 45 Declaration of Conformity Issue: 6 TSB_7021_E.docx Author: QD December 18, 2020 2 of 3 Certificate(s): ATEX: KEMA 06ATEX0027 Bescheinigung(en): Certificat(s): Vertalingen Traducciones Product Producto Voorwerp van de verklaring Objeto de la declaración Naam en adres van de fabrikant Nombre y dirección del fabricante Het hierboven beschreven voorwerp is in overeenstemming de El objeto de la declaración descrita anteriormente es conforme con la desbetreffende harmonisatiewetgeving van de Unie...
- Page 46 Declaration of Conformity Issue: 6 TSB_7021_E.docx Author: QD December 18, 2020 3 of 3 The Technical Construction File required by these Directives is maintained at: Die von den Richtlinien erforderten technischen Dokumentation wird archieviert in: ENRAF TANKSYSTEM SA Le dossier technique de construction nécessaire pour ces directives est maintenue à: Het technisch constructie dossier vereist door deze richtlijnen wordt bewaard in: Rue de l’Industrie 2 El expediente técnico de construcción requerido por dichas Directivas se mantiene a:...
