- Page 1 OPARATING INSTRUCTIONS PLANO 3D GREEN LINE LASER solafl ex.com...
- Page 2 OPERATING INSTRUCTIONS PL ANO 3D GREEN ABOUT THIS MANUAL Congratulations on the purchase of your new PLANO 3D GREEN! You have acquired a SOLAFLEX measurement instrument, which can make your work easier, faster and more preci- se. To utilize the complete functionality range of this measurement instrument, and to ensure a safe operation, please observe the following instructions: Please read this operating manual before commissioning the device.
-
Page 3: Table Of Contents
CONTENTS General Information Description Technical Data 4. Safety Instructions Laser Safety / Classifi cation Getting Started Operation 8. Checking the Accuracy Maintenance, Storage and Transportation 10. Troubleshooting 11. Disposal 12. Manufacturer’s Guarantee 13. EC Declaration of Conformity solafl ex.com... -
Page 4: General Information
1. GENERAL INFORMATION 1.1 SIGNAL WORDS AND THEIR MEANING DANGER For an imminent danger that could lead to serious injury or death. WARNING For a possibly dangerous situation that could lead to serious injury or death. CAUTION For a possibly dangerous situation that could lead to slight injury or property damage. NOTE For application notes and other useful information. -
Page 5: Description
4. Battery compartment cover 2.2 INTENDED USE The PLANO 3D GREEN is a line laser that enables a single person to level and align items horizontally and vertically. The device is designed to be preferably used indoors. For outdoor applications, it must be ensured that the ambient conditions are similar to those indoors. -
Page 6: Technical Data
3. TECHNICAL DATA 3. TECHNICAL DATA 3.1 PLANO 3D GREEN LINE LASER Working range laser lines r = 30 m* recipient r = 80 m* Max. measurement tolerance laser lines ± 3 mm** Protection class IP54 Leveling range (typical) ± 3°... -
Page 7: Safety Instructions
Inadequate safeguarding at the installation site. 4.3 EINSATZGRENZEN The PLANO 3D GREEN is suitable for continuous use in an atmosphere which can be inhabited by humans. Do not operate the product in explosion-prone or corrosive environments. Inform the local safety authorities and safety experts before working in hazardous environ- ... - Page 8 4.4 USAGE HAZARDS 4.4.1 GENERAL WARNING Missing or incomplete instructions may result in improper or incorrect use. This can cause accidents with serious damage to persons, property, assets and the environment. Follow the manufacturer’s and operator’s safety instructions. Protect equipment and accessories from being accessed by children. ...
- Page 9 WARNING Using charging devices from other manufacturers can damage the Li-ion batte- ries. This can lead to a fi re and explosion hazard. Only use original SOLAFLEX accessories.. WARNING If disposed of improperly third parties can possibly be seriously injured and the environment polluted.
-
Page 10: Electromagnetic Compatibility (Emc)
Although the product meets the strict requirements of the relevant directives and standards, SOLAFLEX cannot completely exclude the possibility of interference with other devices (for example, when using the product in combination with third-party devices, such as fi eld com- puters, personal computers, wireless devices, mobile phones, certain cables or external batteries). -
Page 11: Laser Safety / Classifi Cation
5. L ASER SAFE T Y / CL ASSIFICATION 5. L ASER SAFE T Y / CL ASSIFICATION The PLANO 3D GREEN emits one 360° horizontal line and two 360° vertical lines. The product corresponds to laser class 2 according to DIN EN 60825-1:2014. -
Page 12: Getting Started
6. GE T TING STARTED 6.1 BATTERIES Open the battery compartment cover. 2. Insert batteries in the adapter with the correct polarity. 3. Close the battery compartment cover (audible click of the cover). Only use type 18650 3.6 V Li-ion batteries (3450 mAh). Remove the batteries if the instrument is not used for an extended period. -
Page 13: Operation
The REC LGD0 receiver can be used to detect the laser lines at even greater distances or in un- favorable environmental conditions. Pulse mode is active on the PLANO 3D GREEN when the MODE button is pressed. The laser lines fl ash three times to indicate the change... - Page 14 7.1.3 CREATING INCLINATIONS BEYOND THE RANGE OF AUTOMATIC LEVELING Turn the on/off switch, transport lock to the left (OFF position). Hold down the MODE button for at least 5 seconds. To indicate that the self-leveling is switched off, the lines will blink every 4 seconds. Hold down the MODE button for at least 5 seconds.
-
Page 15: Checking The Accuracy
7.2.3 90° ANGLE 7.2.4 INCLINATION 7.2.5. WORKING AT DISTANCES 8. CHECKING THE ACCURACY Check the accuracy of the PLANO 3D GREEN before each measurement. Before starting the check, let the device acclimatize to the ambient conditions.. solafl ex.com... -
Page 16: Checking The Accuracy Of The Vertical Line
Position the device approx. 3 m in front of the plumb line. Switch on the PLANO 3D GREEN and project the vertical laser line onto the plumb line. If the deviation is greater than 4 mm, the device must be readjusted. -
Page 17: Maintenance, Storage And Transportation
9. MAINTENANCE, STORAGE AND TRANSPORTATION 9. MAINTENANCE, STORAGE AND TRANSPORTATION 9.1 CLEANING Wipe off the dirt with a soft damp cloth. Check the outlet openings of the laser regularly, and thoroughly clean them if necessary. Do not touch the glass with your fi ngers. Do not use aggressive cleaning agents or solvents. -
Page 18: Troubleshooting
Only dispose of batteries when discharged. LI-ION BA LI-POLY DO NOT LOA Observe the country-specifi c disposal requirements. PACKAG MAX 60° For mo Your SOLAFLEX dealership will accept returned batteries as well as old equipment, and will ensure proper disposal. solafl ex.com... -
Page 19: Manufacturer's Guarantee
ONLY FOR EU COUNTRIES >1/4 s Electric tools must not be disposed of with household waste! According to European Directive 2002/96/EC on Waste Electrical and Elect- LI-ION B LI-POL ronic Equipment and its transposition into national law, electrical and elec- DO NOT LO PACKA MAX 60°... -
Page 20: Ec Declaration Of Conformity
Mag. Wolfgang Scheyer CEO Götzis, 04/2018 D I G I T A L M E A S U R I N G Solaflex GmbH I Unteres Tobel 25, A-6840 Götzis, Austria | +43 (0) 5523 57707 | info@solaflex.com solafl ex.com...
