FunTech Innovation Ideao DC400 Quick Start Manual

4K Visualizer / Document Camera
Quick Start Guide
Getting started with DC400
(1) Push a finger through an opening at the base of the DC400
to slightly tilt up the camera.
(2) Lift the other side of the arm, then pull and flip the camera
head in the sequence and direction indicated by arrows
below.
Adjustable
DC400
,
a document camera with built-in mic, is compatible
with a variety of software that support UVC & UAC protocol. It
works out of the box with most UC software such as Zoom,
Google Meet, Microsoft Teams, and more. Ideao's VisualCam
software greatly enhances your lessons and presentations by
unlocking DC400's extensive features set such as video
recording, snapshot, picture-in-picture, whiteboard, and
annotation.
For more information please visit:
Ideao VisualCam
https://funtechinnovation.com/software/ideao-visualcam/
IdeaoCam
https://funtechinnovation.com/software/ideaocam/
Package Contents
Visualizer
Carry Bag USB Cable & User Manual
cable organizer
(3) Adjust the camera head until it is horizontal to the shooting surface.
Fully extend the arm to capture maximum shooting area of A3.
After adjusting shooting height,
press the AF button to refocus
(4) Plug in USB cable and attach the cable organizer to the arm.
c d
Protection sticker
Make sure to rip o the protection sticker before using it.
DC400 Overview
(5) For using DC400 as a webcam, long press the AF button to
rotate the image
rotate 180°
webcam mode
Specifications
Camera
3840x2880 @15fps (To Capture A3 Image)
Max. Output Resolution
3840x2160 @30fps
& Frame Rate
1920x1080 @60fps
Video Compression MJPG / YUY2
Focus On demand (AFS)
Minimum Focus Distance 10cm / 3.9"
Maximum Shooting Area 420x297mm / 16.5x11.7" (A3 size)
Viewing Angle 82°
Sensor 13 Megapixel 1/3" CMOS
a Autofocus / Flip Button
Press once: autofocus / Long press: flip image 0/180°
b LED Light Button
Press to turn on LED light. Three levels brightness.
c Micro USB Port
d Status Indicator
h
e Microphone
Camera
f
g
LED Light
h Hinge screws
Camera
F-Number F2.2 ± 5%
G-Sensor No
LED Lighting Yes, 3 level
Pan / Tilt / Zoom Yes, 10 digital zoom by software
Image Rotation 0° / 180°
Support Power Line
50/60 Hz
Frequency
Micorphone
Built-in Microphone Omnidirectional Microphone
Sensitivity S 94dB SPL @1KHz Min-29 Typ-26
Microphone Specifications
Max-23 dBFS SNR 64dB
Others
Connectivity Micro USB to Type A 2.0
Powered By USB 2.0 5V/500mA
Protocol UVC; UAC; Plug-and-play
Windows 11, 10
Operating System macOS 10.15 or above
Chrome OS
Folded (LxWxH):
Product Dimensions
195 x 66 x 13 mm / 7.7 x 2.6 x 0.5"
Net Weight 380g/ 13.4 oz
DC400,
Quick start guide,
Package Contents USB cable (Micro USB to A),
Cable organizer,
Carry bag,
a
b
If the hinge appears loose
after some use, use a
screwdriver to
tighten it.
h
