Suntop XHP Series Instructions

Flashlight Instruction
XHP Series
Product Specifications:
-- Lifespan of the LED lamp: 50,000 hours
-- Mode: 5 Mode or 3 Mode
5Mode: Low/Middle/High/Turbo and hidden Strobe
3 Mode: Low/ High/ Strobe
-- Range: 200 to 400 meters
-- Waterproof case: IPX65 waterproof case
-- Overload protection, over-discharge
-- High quality, hard anodized, abrasion resistant surface
-- Power by: 18650 button battery or 26650 button battery
-- Switch on / o : Push button
-- Charging time: 6 hours (approximately)
-- Material: Aluminum alloy
-- Zoom: zoomable
Usage and Maintenance
● Please do not disassemble the sealed head, doing so can cause damage to
the flashlight and will void the warranty.
● If Batteries are attached in the flashlight when received, please remove the
insulation sheet in the flashlight before using.
● High-power light should use battery with high current discharge capability;
we suggest using high quality battery to increase the run time of this high-in-
tensity light.
● Please take out the battery if the flashlight will not be used for a long time, or
it may cause damage from electrolyte leakage or battery explosion.
● Please clean the contacts of your light from time to time, especially if the
light flickers or does not light up. There may be several reasons for a flickering or
not working light:
Reason A: The battery needs replacing.
Solution: Replace the battery (Please confirm the correct installation of anode
and cathode)
Reason B: The threads PCB board contact or other contacts are dirty.
Solution: Clean the contact points with an alcohol soaked cotton swab.If the
above methods don't work, please contact the distributors and refer to the
warranty policy.
◆ Battery Replacement
● Unscrew the light head to insert the battery with anode (+) toward the light
head, screw the light to test. Please DON'T INSERT the battery incorrect way,
otherwise it will short circuit and CAUSE A FIRE！
● Please clean the contacts of your light from time to time, especially if the
light flickers or does not light up. There may be several reasons for a flickering
or not working light:
Reason A: The battery needs replacing.
Solution: Replace the battery (Please confirm the correct installation of anode
positive electrode and cathode)
+
◆ Battery Replacement
● Unscrew the light head to insert the battery with anode (+)
toward the light head, screw the light to test. Please DON'T
INSERT the battery incorrect way, otherwise it will short circuit
and CAUSE A FIRE！
◆ Product Warranty
We will replace products if a icted with manufacturing
defects within 15 days of purchase and repair a light
free of charge within 3 months of purchase if
-
problems develop with normal use; If repair is
negative electrode
required after 3 months from the date of
purchase, we will charge for parts.
The total repair fee is dictated by the
cost of the replaced materials.
◆ Warning
The led flashlight is a high-inten-
sity lighting device capable of
causing eye damage. Avoid
shining the light directly
into the eyes.
5 Modes
Models:1161,
1162,1116,
XHP50
1167, other
3 Modes
Models:1194, other
XHP70
5 Modes
Models:1170, 1173, 1184, 1178,
XHP70
other
5 Modes
Models:1188, 1117, 1192, 1108,
XHP90
other
5 Modes
Models:1197, other
XHP99
