Nugens NC-A24P-25B User Manual

All-in-one rotatable touch pc
Hide thumbs

Advertisement

Table of Contents

All-in-One Rotatable Touch PC
Model: NC-A24P-25B / NC-A24P-25W
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NC-A24P-25B and is the answer not in the manual?

Questions and answers

Summary of Contents for Nugens NC-A24P-25B

  • Page 1 All-in-One Rotatable Touch PC Model: NC-A24P-25B / NC-A24P-25W User Manual...

  • Page 2: Base Installation

    1) Installation a) Bracket and Screen Installation Place the screen face down on a clean table, align the stand with the two upper clips, then push the button upward, lower the stand, and release the button to lock it in place. b) Base Installation Align the pins on the stand and base, insert them, then tighten the screw at the bottom of the base in the "Close"...

  • Page 3: Power Connection

    c) Power Connection Connect the power adapter to the power cord and plug it into the socket. connect the other end to the DC IN port at the bottom of the computer. press the power button to turn it on and wait for the system to start.

  • Page 4: Product Introduction

    2) Product Introduction a) Appearance Touch Screen ii) Adjustable Angles...
  • Page 5 I/O Interfaces Introduction Headphone Jack SD Card Reader Type-C 2.0 USB 2.0 Brightness Anti-Theft Adjustment Lock Hole Fingerprint Reader Power Button 2.5” SSD Expansion Port...

  • Page 6: Initial Setup

    3) Initial Setup When you start the computer for the first time, a series of screens will guide you through setting up the Windows 11 operating system. A. Press the power button located next to the right bezel and wait a few minutes until the setup is complete.

  • Page 7: Shut Down Pc

    • Network • Settings • Your account E. Once the setup is complete, the Windows 11 desktop will be displayed. 4) Shut Down PC "Shutting down" means closing all open programs, including the operating system, and then turning off the computer. Please shut down the computer in any of the following situations: •...

  • Page 8: Specification

    Although you can turn off the computer using the power button, it is strongly recommended to use the Windows shut down function to ensure the system runs properly the next time you start it. 5) Specification Specifications Model NC-A24P-25B / NC-A24P-25W Operating System Windows 11 Pro Version 23H2 Processor Intel Core i5-11400H (Core 6, 2.2GHz, with...
  • Page 9 I/O Interface DC*1 (Bottom) HDMI OUT 2.0 *1 VGA OUT *1 USB 3.0 *4 RJ45 *1 MIC IN *1 LINE OUT *1 Brightness Botton *2 I/O Interface Headphone Jack *1 (Left) SD Card Reader *1 Type-C 2.0 *1 USB 2.0 *2 I/O Interface Fingerprint Reader (Right)

  • Page 10: Daily Maintenance

    Product Weight 6.9 KG 6) Daily Maintenance • When using, please pay attention to heat dissipation, especially the following points: Do not expose the computer to direct sunlight. Do not place the computer near heat sources. During use, do not block the computer's ventilation holes with other objects.
  • Page 11 7) Warning Excessive use may harm vision: ⚫ Take a 10-minute break after 30 minutes of use. Children under 2 years old should not look at screens, and children over 2 years old should not use screens for more than 1 hour a day.

This manual is also suitable for:

Nc-a24p-25w
