Summary of Contents for Phoenix DUAL ZONE
- Page 1 Detailed Step By 240 VOLTS Step Manual ONLY NL | PL | DZ Models www.phoenixphaseconverters.com...
- Page 2 • Load Summation • Diversity Factors • NEC Adjustments and Examples 7. 230 Volt Model Specific Notes • Exclusions for Dual Zone Models • Sizing Summary 8. Single Phase Input Connection • Terminal Labeling: L1, L2 • NEC Code Compliance Notes www.phoenixphaseconverters.com...
- Page 3 • Terminal Assignments: L1, L2, L3 10. Completed Panel Wiring • Labeling and Function • Safety Enhancements (Grounding, Disconnects, Startup Warning) 11. Dual Zone Configuration • Independent & Combined Idler Output Options • Flexible Load Application 12. Product Overview: GP10NLA Converter •...
- Page 4 Installation Location Recommendation For optimal performance, the phase converter should be installed as close to the power supply as possible. It is recommended to keep the single-phase supply line under 50 feet in length. If a longer distance is necessary, increase the wire size by one gauge for every additional 50 feet to minimize voltage drop and ensure reliable operation.
-
Page 5: Service Requirements
SERVICE REQUIREMENTS SINGLE-PHASE POWER REFERENCE CHART (KVA TO AMPS @ 240V) USE THIS CHART TO DETERMINE THE MAXIMUM AMPERAGE AVAILABLE FROM A SINGLE-PHASE POWER SUPPLY AT 240 VOLTS, BASED ON KVA RATINGS FROM YOUR UTILITY. FORMULA USED: AMPS = (KVA * 1000) / 240 NOTE: THE KVA NUMBER FROM THE POWER COMPANY SHOULD NOT EXCEED THE HP RATING OF THE ROTARY PHASE CONVERTER YOU ARE TRYING TO START. - Page 6 MOUNTING THE PHASE MOUNTING THE PHASE CONVERTER PANEL CONVERTER PANEL Mount the enclosure first, to a non-vibrating surface, there are two options provided for mounting, next install the back plate with the four nuts provided, Mounting the phase converter panel near the breaker panel is recommended as short as possible.
- Page 7 Datasheet and Specifications www.phoenixphaseconverters.com...
- Page 8 CONNECTING THE CONTROL PANEL TO THE MOTOR. NOTE Do NOT use wire nut on the idler motor, even just if it is just temporary, use polaris plugs or bolt down lugs. Wiring Diagram www.phoenixphaseconverters.com...
- Page 9 Make sure to follow the diagram on the motor. CLICK TO WATCH VIDEO CLICK TO WATCH VIDEO www.phoenixphaseconverters.com...
- Page 10 TYPES OF BREAKERS What is a Motor Load Breaker? �� A motor load breaker, often called a motor protection circuit breaker (MPCB) or motor circuit protector (MCP), is a specialized type of circuit breaker designed specifically to protect electric motors from: Overloads Short circuits Phase loss (in 3-phase systems)
- Page 11 BREAKER SIZES AND WIRE SIZES 230 VOLT MODELS Do NOT use this chat for Dual NOTE Zone Phase Converters Selecting the right size circuit breaker depends on whether you're powering a single piece of equipment or multiple machines together. Below is a breakdown to guide you through both scenarios: Add a little 1.
- Page 12 BREAKER SIZES AND WIRE SIZES 230 VOLT MODELS DUAL ZONE PHASE NOTE CONVERTER ONLY Selecting the right size circuit breaker depends on whether you're powering a single piece of equipment or multiple machines together. Below is a breakdown to guide you through both scenarios: Add a little 1.
- Page 13 CONNECTING YOUR SINGLE PHASE WIRE Single Phase Input To connect your single-phase power supply, run both hot conductors (commonly referred to as Line 1 and Line 2 from your single-phase electrical panel and connect them to the terminals marked L1 and L2 on the phase converter input.
- Page 14 CONNECTING YOUR IDLER MOTOR Once you have securely connected the wiring at the idler motor, run a total of four conductors—three power lines and one ground wire— from the idler motor to the terminal block. Terminate the three power conductors at the terminals labeled L1, L2, and L3, ensuring they are tightened properly and making solid electrical contact.
- Page 15 Load 3 PHASE OUTPUT POWER 1 PHASE INPUT 230V (LOW) Completed Panel Wiring IDLER MOTOR 3 PHASE 230V (LOW) This diagram illustrates a completed panel wiring setup for a rotary phase converter. The connections are clearly labeled for the following: Load Output (3 Phase Output): Delivers three-phase power to your machinery.
-
Page 16: Wiring Diagram
WIRING DIAGRAM READ MANUAL BEFORE INSTALLING www.phoenixphaseconverters.com... - Page 17 240 VOLTS www.phoenixphaseconverters.com...
- Page 18 CONNECTING YOUR IDLER MOTOR Once you have securely connected the wiring at the idler motor, run a total of four conductors—three power lines and one ground wire— from the idler motor to the terminal block. Terminate the three power conductors at the terminals labeled L1, L2, and L3, ensuring they are tightened properly and making solid electrical contact.
- Page 19 Load 3 PHASE OUTPUT POWER 1 PHASE INPUT 230V (LOW) IDLER MOTOR 3 PHASE 230V (LOW) Completed Panel Wiring This diagram illustrates a completed panel wiring setup for a rotary phase converter. The connections are clearly labeled for the following: Load Output (3 Phase Output): Delivers three-phase power to your machinery.
- Page 20 240 VOLTS T2 T1 Three Phase Output LOAD THREE PHASE BREAKER PANEL www.phoenixphaseconverters.com...
- Page 21 240 VOLTS www.phoenixphaseconverters.com...
- Page 22 Connect Single Phase Input www.phoenixphaseconverters.com...
- Page 23 240 VOLTS...
-
Page 24: Single Phase
CONNECTING YOUR IDLER MOTOR Idler Motor #2 Idler Motor #1 Single Phase Once you have securely connected the wiring at the idler Input motor, run a total of four conductors on each idler —three power lines and one ground wire—from the idler motor to the terminal block. - Page 25 Idler Motor #2 Idler Motor #1 Input Connecting Your Load – Dual Zone Flexibility This system allows for flexible load connection options. The primary output load is typically connected to the left power block, utilizing the combined power of both idler motors.
- Page 26 Standard Feature TEFC (Totally Enclosed Fan Cooled) Generator and Cast Iron Frame. Our Highly Reliable Motors: At Phoenix Phase Converters we use the best components that last a lifetime. The 10 HP rotary phase converter - GP10NLA single phase to three phase converter features a totally enclosed fan cooled and cast iron frame motor.
- Page 27 Standard Feature TEFC (Totally Enclosed Fan Cooled) Generator and Cast Iron Frame. Our Highly Reliable Motors: At Phoenix Phase Converters we use the best components that last a lifetime. The 10 HP rotary phase converter - GP10NLA single phase to three phase converter features a totally enclosed fan cooled and cast iron frame motor.
-
Page 28: Warranty
DIY panel manual for further details. If any component is found to be defective within the warranty period, Phoenix Phase Converters will either repair or replace it (at our discretion) at no cost. Warranty services for the control panel must be conducted exclusively at a Phoenix Phase Converters authorized facility.
