1. GENERAL INTRODUCTION
1.1. Document Purpose
This document provides general information for the 97-VAK3000LAPTR and 97-4000LAPTR laptop tray kits for CUBE enclosures.
Figure 1 shows the laptop tray.
Hereafter, the Charles 97-VAK3000LAPTR and 97-4000LAPTR laptop tray kit will be referred to as the "kit."
1.2. Product Purpose
The kit is a foldable laptop tray that is mounted on the inside of the CUBE door.
The 97-VAK3000LAPTR kit can be mounted on any CUBE that is equipped with the VAK-3000 3500W HVAC system.
The 97-VAK4000LAPTR kit can be mounted on any CUBE that is equipped with the VAK-4000 4000W HVAC system with economizer.
©Copyright 2022 Charles Industries LLC. All rights reserved. Printed in the United States of America.
Availability of features and technical specifications herein are subject to change without notice.
Charles is a registered trademark of Charles Industries.
Charles Laptop Tray Kit
General Description and Installation
-NOTE-
LT-VAKLAPTOPTR
st
1
Printing, March 2, 2022
Figure 1
Laptop Tray
Page 1 of 4
